Operating Instructions • Warning Information • Parts Breakdown
SPECIFICATIONS
Performance Rating: ................................ Heavy Duty
Max. Free Speed ...................................... 1000 RPM
Orbital Stroke .................................................. 5 MM
Pad Size ............................................................... 6"
Air Inlet ................................................... 1/4" NPTF
Min. Air Hose Size ......................................... 3/8" ID
Recommended Air Pressure ........................... 90 PSI
Height ............................................................. 4.25"
Length ........................................................... 10.5"
Weight ....................................................... 3.5 LBS.
Air Consumption ............................................. 3 CFM
Sound Level ..................................................82 dBA
WARNING
RATED RPM OF THE ACCESSORY USED
MUST EXCEED THE MAXIMUM TOOL
RPM SHOWN
ALWAYS READ
INSTRUCTIONS BEFORE
USING POWER TOOLS
ALWAYS WEAR
DUST MASK
OR RESPIRATOR
WEAR HEARING
PROTECTION
AVOID PROLONGED
EXPOSURE TO VIBRATION
AVOID PROLONGED
EXPOSURE TO VIBRATION
Some dust created by power sanding, sawing, grinding, drilling, and other con-
struction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that
are specially designed to filter out microscopic particles.
CAT650HD
WARNING
6" Gear Driven
Copyright © Professional Tool Products, 2013
1
CAT650HD
Sander
All rights reserved.
01/04/13
Advertisement
Related Manuals for Cornwell Tools CAT650HD
Summary of Contents for Cornwell Tools CAT650HD
- Page 1 Some dust created by power sanding, sawing, grinding, drilling, and other con- struction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: CAT650HD • lead from lead-based paints, 6" Gear Driven • crystalline silica from bricks and cement...
- Page 2 • DO NOT USE SANDING DISC OR ACCESSORIES set-up. ABOVE THEIR MAXIMUM RATED RPM. • Air powered tools can vibrate in use. Vibration, repetitive motions or uncomfortable positions over extended periods of time may be harmful to your hands and arms. Discontinue use of tool if discomfort, tingling feeling or pain occurs. Seek medical advice before resuming use. CAT650HD 01/04/13...
-
Page 3: Air Supply
SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS, LOST PROFITS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY TO USE THE CORNWELL PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary by state. Repair kits and replacement parts are available for many Cornwell products, regardless of whether or not the product is still covered by a warranty plan. 667 Seville Road • Wadsworth, OH 44281-1094 Cornwell Quality Tools Company • CAT650HD 01/04/13... - Page 4 PARTS BREAKDOWN - CAT650HD 9 10 12-1 31-1 CAT650HD 01/04/13...
- Page 5 PARTS BREAKDOWN - CAT650HD Ref. No. Part No. Description Qty. Ref. No. Part No. Description Qty. RS650HD01 Housing RS246534 Motor Shaft Balancer RS786002 Cone Muffler 31-1 RS246535 Housing Cover RS786003 Muffler Body RS246536 Screw 04-1 RS246502 Screw RS246537 Faceplate RS246002 O-Ring (3.5 x 1.4)
