Installation and Owner's Manual
Manual de Instrucciones y del Propietario
Manuel d'Installation et d'Utilisation
Four-Hole Roman Tub Filler Trim
Grifo de Bañera de Romano con Cuatro Agujeros
Garniture de Robinet de Baignoire Romaine pour Quatre Trous
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
(888) 295-8134 or (678) 466-1300 when calling from outside of U.S.A.
Wyeth
™
TB230S
Vivian
®
TB220S1
Vivian
®
TB220S
Silas
®
TB210S
Advertisement
Table of Contents
Related Manuals for Toto Wyeth TB230S
Summary of Contents for Toto Wyeth TB230S
- Page 1 TB210S Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con- tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260...
- Page 2 Rough-In Dimensions .................. 17-20 THANK YOU FOR CHOOSING TOTO! The mission of TOTO is to provide the world with healthy, hygienic and more comfortable lifestyles. We design every product with the balance of form and function as a guiding principle. Congratulations on your choice.
- Page 3 INCLUDED PARTS Spout Assembly* Handle Assembly* (2X) Handshower Mount* Set Screw and Hex Key Pop Up Rod* Handshower* Elbow Handshower Hose Tube for Pop Up Rod * Actual product may vary in appearance depending on model. TB220S model shown. COMMON TOOLS NEEDED (2X) Adjustable Wrench INSTALLATION PROCEDURE - Spout Remove plug...
- Page 4 INSTALLATION PROCEDURE - Spout Insert the tube for pop up rod inside the pre-installed diverter valve. Push firmly until fully seated. Take care not to damage the o-rings. Orient spout assembly as shown and lower onto exposed portion of diverter valve. Use hex key to fasten spout to valve with provided set screw.
- Page 5 INSTALLATION PROCEDURE - Handshower Fasten the handshower mount to the pre-installed rough collar. Place gasket in elbow nut and fasten handshower until completely sealed. NOTE: Only one (1) gasket per location shown, do not add if gasket Gasket/Sieve already present. Elbow Retract handshower hose to seat elbow in the handshower mount.
