- Page 1 PVB S AYPRO ERIES OLLEGIATE YSTEM Installation and Operating Instructions Applicable Part Numbers/Models: PVB-1500: Steel Collegiate Net System PVB-4500/PVB-5000: Featherlite Collegiate Net system...
-
Page 2: Table Of Contents
PVB Series Collegiate Net System Instructions Table of Contents Safety ........................ 2 Specifications ....................2 Introduction ..................... 2 Required Tools ....................3 Included Hardware & Components ............4 5.1 System Components ................4 5.2 Hardware ....................5 Assembly ......................6 Maintenance .................... -
Page 3: Safety
These instructions assume that the appropriate ground sleeves have been correctly installed: NCAA and NFHS rules require that the upright standards must be installed at least 3’3” (1m) outside the court boundaries. Jaypro recommends 36’ spacing on center to satisfy both regulations. -
Page 4: Required Tools
PVB Series Collegiate Net System Instructions Figure 3-1: Correct Ground Sleeve Dimensions Required Tools Before continuing, please verify that you have the following tools required to complete the installation and setup of your PVB Series Collegiate Net System. Adjustable wrench Hex keys – 3/16”, 5/16”... -
Page 5: Included Hardware & Components
Before continuing, please open all packages to verify that you have all the required hardware for installation and setup. If any of the following items are missing, contact the Jaypro Sports customer support team, Monday through Friday, 8:30AM to 5:00 PM (EST), at 1-800-243-0533. -
Page 6: Hardware
PVB Series Collegiate Net System Instructions Figure 5-5: Flex-Net (PVBN-6, 1X) Figure 5-6: Antennae and Net Tapes (VBA-4, 1 pair) Figure 5-7: Anchor Strap (PVB-604, 1X) 5.2 Hardware Figure 5-8: Button Head Cap Screw (HS5098, 1X) Figure 5-9: Button-Head Cap Screw (HS5201, 1X) -
Page 7: Assembly
PVB Series Collegiate Net System Instructions Assembly WARNING: Uprights are heavy. Do not attempt to lift or install without assistance. 1. Install each upright into the ground sleeves. 2. Follow instructions included with winch to set the winch clamp to the correct upright diameter (3-1/2”). - Page 8 PVB Se eries Collegiate Net System Ins tructions . Install the anchor stra p to the upr right without the winch ( Figure 6-2). Figure 6- -2: Install anchor stra . Set the he eight of the u uprights usin g the installe ed height ad djust pin (Fig...
- Page 9 PVB Se eries Collegiate Net System Ins tructions . Attach on ne end of ne et to anchor strap, then attach othe er end to win ch strap (Figure 6-4 Figure 6- 4: Attach net to strap . Adjust the e length of th he anchor st trap as nece...
-
Page 10: Maintenance
3. Install pad ds around ea ach upright. Maintena Your PVB Series C Collegiate Ne et System is d designed to provide yea ars of play; h owever, it is recom mmended th...
