  • Page 1 MSPA-MP METAPACK SERVICE MANUAL • Gecko Electronics Inc. • Visual step-by-step guide to easily identify & correct technical problems!
  • Page 2: Table Of Contents

    Replace The Heater (Horizontal Front/Back; Vertical/Side) Adjust The Pressure Switch Miscellaneous Parts List Wiring Diagrams Professional Repair Kit Info Note: For spa repairs and troubleshooting with Pocket-tek technology, please refer to Pocket-tek User's Manual available from Gecko and at www.pocket-tek.com.
  • Page 3 In an attempt to make this manual as useful as possible, it has been presented in two formats. Problem-solving solutions are described with Troubleshooting Flow Charts and also with Step-by-Step Procedures. The two formats together should provide an overall complete explanation, with flow charts providing an overview of specific problems, and step-by-step procedures giving more detailed information.
  • Page 4: Tools And Parts

    Pressure switch MSPA-MP system board Fuses (or complete spa pack) Top side control (keypad) Gecko Electronics Inc. sells Professionnal Repair Kits that include everything needed for MSPA-MP Metapack servicing. For more information, go to the last page of this manual.
  • Page 5: Electrical Wiring

    Electrical Wiring Correct wiring of the electrical service box, GFCI box and pack terminal block is essential. Electrical Box GFCI Pack Terminal Block 1• Carry out a visual inspection to check for signs of miswiring. Refer to supplied wiring diagrams. Call an electrician if necessary.
  • Page 6: Gfci Instructions & Flow Chart

    GFCI Flow Chart If GFCI trips, follow Troubleshooting Flow Chart below to identify the problem: Is GFCI properly connected? Verify Wiring Diagram and reconnect it. Unplug everything, including heater and light cord wires. Is GFCI still tripping? Reconnect one component at a time until GFCI starts to trip.
  • Page 7 GFCI Trips! If all connections are made, but nothing seems to be working, you probably have a power supply problem. Carry out the following tests to identify and correct the problem: Note that for new installations, GFCI trippings due to miswiring are common. If breaker is wired properly, GFCI trippings may occur when total amount of current drawn by spa exceeds breaker rating.
  • Page 8 GFCI Trips! If GFCI continues to trip even after having replaced the transformer, carry out the following tests to correct the problem: 1• Disconnect incoming power lines. If GFCI still trips, there must be a cable problem. Call an electrician! 2•...
  • Page 9: Jumper Positions

    Jumper Positions Certain MSPA-MP spa pack parameters can be modified by changing the position of jumpers on the board. Remove MSPA-MP power box cover to access jumpers. (See "How to Replace the Board" section of this manual). Jumper functions may differ from information below. Please check wiring diagram on inside pack cover to verify specific functions for our pack.
  • Page 10: Low Level Programming

    Low Level Programming Certain system operating parameters can be configured from the keypad. This is normally done by Gecko or the spa installer, but may be done any time. Low level programming: To access low level programming, press and hold On/Off key for 20 seconds, after which the first parameter code should appear on the display.
  • Page 11 MSPA-MP Metapacks Service Manual...
  • Page 12 Flashing Dots Flow Chart If 3 flashing dots appear on keypad display, follow Troubleshooting Flow Chart below to identify the problem: 3 flashing dots appear on the display! Remove pack cover. Is board LED on? Make sure jumper is Follow flashing dots set properly for circulation pump and...
  • Page 13 Flashing Dots Displayed Three flashing dots error condition indicates a pressure switch problem. There must be enough water in the spa for normal operations. System may detect error condition if spa filter is dirty or if something restricts flow of water in piping. The heater will automatically shut down when error condition occurs.
  • Page 14 Flashing Dots Displayed 6• Ensure adequate water flow in the heater and short two pressure switch terminals with jumper cable. 7• If the three dots disappear, first make sure there is no blockage of water or air lock and check water valve.
  • Page 15 Flashing Dots Displayed Power may remain On while the following steps are carried out. 10• If you have continuity on pressure 11• If error condition persists, remove switch, follow these steps: plastic cover and replace pressure switch cable. Disconnect pressure switch cable for 5 seconds and reconnect it.
  • Page 16: Error Conditions

    Flashing dots and LED Flow Chart If error condition occurs (potential Hi-Limit sensor or temperature probe problem), follow Troubleshooting Flow Chart below to identify the problem: Turn breaker off then on again to reset the system. If Hi-Limit condition no longer persists, check for blockage of water in the piping.
  • Page 17: Flashing Dots & Led Displayed

    Flashing Dots & LED Displayed The three flashing dots and LED error condition is related to the Hi-Limit sensor or temperature probe. Turn breaker off then on again to reset the system. If 3 flashing dots and LED disappear, wait until they are displayed again on keypad. Power may remain On.
  • Page 18 Flashing Dots & LED Displayed If keypad display isn't showing correct temperature, carry out the following tests: 1• Verify if temperature probe is in contact with water and if cold air from the back could be affecting readings. Use foam to isolate probe from cold air if that is the problem.
  • Page 19 MSPA-MP Metapacks Service Manual...
  • Page 20 Display Flashing Flow Chart On MSPA-MP-NE packs, if system detects temperature at 112°F or higher, the display will start flashing. Follow Troubleshooting Flow Chart below to identify the problem: Press any key. A power failure has occurred. Has display stopped flashing? System works fine.
  • Page 21: Display Is Flashing

    Display Is Flashing If digital thermometer water temperature reading is 112°F or higher and keypad display indicates correct temperature, carry out the following tests: If display stops flashing after pressing a key, this means that a power failure has occurred. System works fine.
  • Page 22 Display Is Flashing If digital thermometer water temperature reading is 112°F or higher and keypad display isn't showing correct temperature, carry out the following tests: 1• Verify if temperature probe is in contact with water and if cold air from the back could be affecting readings.
  • Page 23 MSPA-MP Metapacks Service Manual...
  • Page 24 Wrong Temperature Flow Chart On MSPA-MP-NE packs, if system detects that temperature is not within normal limits, wrong temperature will be displayed. Follow Troubleshooting Flow Chart below to identify the problem: Check if regulation probe is properly connected. Unplug probe connector and clean pins on the board (even a small coating of film may cause a bad...
  • Page 25 Wrong Temperature Displayed Wrong temperature on keypad display indicates a problem with regulation sensor. The system is constantly verifying if temperature probe reading is within normal limits. Note that water temperature must be over 35°F in order to carry out the following steps. Power can remain On.
  • Page 26: Flo

    FLO Flow Chart If FLO error condition occurs (problem with the pressure switch: pump is on but no water pressure detected), follow Troubleshooting Flow Chart below to identify the problem: There must be adequate water in spa for normal use. Ensure circulation pump jumper is set properly (see Jumper Section).
  • Page 27 FLO Error Condition An FLO error condition indicates a pressure switch problem. If system does not detect any pressure when pump is manually or automatically turned on, an FLO error condition will occur. There must be enough water in the spa for normal operations. System may detect an FLO error condition if spa filter is dirty or if something restricts flow of water in piping.
  • Page 28 FLO Error Condition 5• Ensure adequate water flow in the heater and short two pressure switch terminals with jumper cable. 6• If FLO error condition disappears, perform the following steps: If the installation is older than 2 years, replace the pressure switch and re- calibrate it.
  • Page 29 MSPA-MP Metapacks Service Manual...
  • Page 30: Flc

    FLC Flow Chart If FLC error condition occurs, follow Troubleshooting Flow Chart below to identify problem (usually pressure switch problem - pump is off but water pressure is detected): First ensure jumper position for circulation pump is set correctly (see Jumper Section). Disconnect pressure switch cable.
  • Page 31 FLC Error Condition An FLC error condition indicates a pressure switch problem. If the system detects any pressure when the pump is off, an FLC error condition will occur. Power may remain On while the following steps are carried out. 1•...
  • Page 32: Prr

    Prr Flow Chart If Prr error condition occurs (potential regulation sensor problem), follow Troubleshooting Flow Chart below to identify the problem: Pressing any key after each step resets the system. Note that water temperature must be over 35°F to operate spa. In systems manufactured after 98, Prr error status is ignored during first hour after initial power up to allow...
  • Page 33 Prr Error Condition The Prr error condition indicates a problem with regulation sensor. The system is constantly verifying if temperature probe reading is within normal limits. Note that water temperature must be over 35°F in order to carry out the following steps. Pressing any key after each step resets system.
  • Page 34 HL Flow Chart If HL error condition occurs (potential Hi-Limit sensor or temperature probe problem), follow Troubleshooting Flow Chart below to identify the problem: Turn breaker off then on again to reset the system. Take water temperature with a digital thermometer. Is water temperature 112°F or higher? Are you getting correct...
  • Page 35 HL Error Condition The HL error condition is related to the Hi-Limit sensor or temperature probe. Turn breaker off then on again to reset the system. Power may remain On. 1• Take water temperature with a c- If HL error condition continues digital thermometer.
  • Page 36 HL Error Condition If digital thermometer water temperature reading is at 112°F or higher and keypad display indicates correct temperature, carry out the following tests: If weather is very hot: 1• Remove spa cover (even during the night). Start blower if spa is equipped with one.
  • Page 37 HL Error Condition If digital thermometer water temperature reading is at 112°F or higher and keypad display isn't showing correct temperature, carry out the following tests: 1• Verify if temperature probe is in contact with water and if cold air from the back could be affecting readings.
  • Page 38 Smart Winter Mode Chart If pumps have started up on several occasions and "Filter Cycle" indicator is flashing on keypad, follow this Troubleshooting Flow Chart to identify the problem: Is the water temperature of the spa lower than the desired temperature? Do you read 240 VAC to the...
  • Page 39: Smart Winter Mode

    Smart Winter Mode If pumps have started up several times and "Filter Cycle" indicator is flashing, the system has detected water cold enough to freeze the pipes and has gone into the protective Smart Winter Mode. An irregularly flashing "Filter Cycle" indicator means that the system has stopped filtering after 3 hours because water temperature exceeds set point by more than 2˚F.
  • Page 40 "Nothing Seems to Work" Flow Chart If nothing seems to work, follow Troubleshooting Flow Chart below to identify the problem: Do you get a ≈240 VAC reading between line 1 & line 2, Verify if ≈120 VAC There is keypad is an electrical between connected...
  • Page 41: Nothing Seems To Work

    Nothing Seems to Work! If everything is connected, but nothing seems to work, there is probably a power supply problem. Carry out the following tests to identify and correct the problem: 3• Measure voltage between line 2 1• On the terminal block, measure and neutral.
  • Page 42 Nothing Seems to Work! If you are getting good voltage readings, but nothing seems to work, carry out the following tests to correct the problem: 1• Verify if keypad is correctly 3• If nothing works, clean transformer connected to the board. orange connector pins.
  • Page 43 MSPA-MP Metapacks Service Manual...
  • Page 44 "Spa Not Heating" Flow Chart If the spa does not seem to be heating the water, follow Troubleshooting Flow Chart below to identify the problem: Any error conditions (flashing dots, FLO, FLC, etc.) on keypad display? Refer to Ensure temp. specific section set point is referred to...
  • Page 45 Spa Not Heating! If the spa does not appear to be heating the water, carry out the following tests to correct the problem: 1• Check for an error condition on If "Heater" indicator does not light up! keypad display. If there is one, Make sure system is not in an Economy refer to section indicated by the mode cycle (10-key keypad configuration...
  • Page 46 Spa Not Heating! If "Heater" indicator appears on the display, but spa is still not heating, carry out the following tests to correct the problem: If "Heater" indicator lights up on the display: 2• If voltage reading is correct, verify 1•...
  • Page 47 MSPA-MP Metapacks Service Manual...
  • Page 48 Pump Flow Chart If Pump 1 or Pump 2 is not working, follow Troubleshooting Flow Chart below to identify the problem: Have any error conditions (flashing dots, FLO, FLC, etc.) appeared on keypad display? Refer to specific section indicated by error condition.
  • Page 49: Pump 1/Pump 2 Does Not Work

    Pump 1 Does Not Work! If Pump 1 is not working, carry out the following tests to correct the problem: To increase the life of the relay, we use a "snubber" circuit on the pump relay. With this type of circuit, if no pump is connected to an output and relays are open, the voltmeter will continue reading around 60 volts.
  • Page 50 Pump 1 Does Not Work! If Pump1 does not work in any speed, carry out the following tests to correct the problem: Pump 1 fuse 1• If Pump 1 does not work in either 3• Turn Pump 1 to high speed and speed, replace Pump 1 fuse.
  • Page 51 Pump 2 Does Not Work! If Pump 2 is not working, carry out the following tests to correct the problem: To increase the life of the relay, we use a "snubber" circuit on the pump relay. With this type of circuit, if no pump is connected to an output and relays are open, the voltmeter will get a reading of around 60 volts.
  • Page 52 Pump 2 Does Not Work! If Pump 2 is not working in any speed, carry out the following tests to correct the problem: Pump 2 fuse 1• If Pump 2 does not work in either 3• Turn Pump 2 to high speed and speed, replace Pump 2 fuse.
  • Page 53 MSPA-MP Metapacks Service Manual...
  • Page 54 Blower Flow Chart If blower isn't working, follow this Troubleshooting Flow Chart to identify the problem: Does "Blower" indicator appear on keyboard display Verify blower when you press low level Blower key? programming (see Low Level Section). Do you Replace read ≈120 VAC for keypad.
  • Page 55: Blower Does Not Work

    Blower Does Not Work! If blower is not working, carry out the following tests to correct problem: To increase the life of the relay, a "snubber" circuit is used on the blower relay. With this type of circuit, if no blower is connected to an output and relays are open, the voltmeter will continue to get a voltage reading of around 60 volts.
  • Page 56 Blower Does Not Work! If "Blower" indicator lights up on control display, but blower still isn't working, carry out the following tests to correct the problem: Blower fuse 1• If indicator lights up on keypad while blower is in high speed, 2•...
  • Page 57 MSPA-MP Metapacks Service Manual...
  • Page 58 Spa Light Flow Chart If spa light does not appear to be working, follow Troubleshooting Flow Chart below to identify the problem: Have you tried replacing the spa light bulb? Try replacing light bulb. Is light still not lighting Does "Light" indicator appear on Verify low level...
  • Page 59: Light Does Not Work

    Spa Light Does Not Work! If spa light is not working, carry out the following tests to correct the problem: It is important to measure voltage when light is connected to the pack. Power must remain On. 1• The first step is to try replacing the spa's light bulb.
  • Page 60 Ozonator Flow Chart If the ozonator is not working, follow Troubleshooting Flow Chart below to identify the problem: If the user turns on a pump, blower or light during a filter cycle, the cycle will be interrupted and will only resume 40 minutes after last active output has been turned off (automatically or manually). This delay is to prevent excessive ozonator activation.
  • Page 61: Ozonator Does Not Work

    Ozonator Does Not Work! If ozonator isn't working, carry out the following tests to correct the problem: To increase the life of the relay, a "snubber" circuit is used on the ozonator relay. With this type of circuit, if no ozonator is connected to an output and relays are open, the voltmeter will still get a reading of around 60 volts.
  • Page 62 Circulation Pump Flow Chart If circulation pump does not appear to be working, follow Troubleshooting Flow Chart below to identify the problem: Verify if low level programming has been programmed properly (see Low Level Section). Increase set point to 2° above actual water temp. to start circulation pump.
  • Page 63 Circulation Pump Not Working! If your MSPA-MP has a defective circulation pump, carry out the following tests to correct the problem: To increase the life of the relay, a "snubber" circuit is used on the circulation pump relay. With this type of circuit, even if no circulation pump is connected to an output and relays are open, the voltmeter will continue to get a volt reading around 60.
  • Page 64 Keys Flow Chart If any of the keys on the keypad display do not seem to be working, follow Troubleshooting Flow Chart below to identify the problem: Verify Jumper #2. Make sure system is set for a 8- or 10-key keypad configuration.
  • Page 65: Replace The Board

    Keys Aren't Working! If any of the keys do not seem to be working, carry out the following tests to correct the problem: 1• Verify Jumper #2. Make sure system is set for a 8- or 10- key keypad configuration. 2•...
  • Page 66 How To Replace The Board When replacing an MSPA-MP board, it is important to make sure to turn power off before proceeding. 1• Loosen 4 screws holding spa pack 3• Insert the end of a flat screw- cover and remove. Disconnect driver into the slots at the top power input cables.
  • Page 67 How To Replace The Board 5• Disconnect high limit sensor 8• The circuit board is supported by a and pressure switch cable. metal plate, with the entire assembly being held in place by 5 screws (one attached to ground wire). Remove screws and disengage the defective board/plate assembly (Note: trans- former remains attached to board.)
  • Page 68 How To Replace The Heater Follow instructions below to replace an MSPA-MP pack heater configured for standard horizontal/front/bottom position. Note: Make sure to turn power to the pack off before proceeding. Pressure Heater Ground High limit Heater Heater switch connectors connector wing nut lock nut...
  • Page 69 How To Replace The Heater Instructions to replace MSPA-MP pack heater configured for standard horizontal/front/bottom position. 5• Remove two remaining nuts at 3• Use a wrench to loosen the two ground cable nuts (one on top of opposite ends of blue plastic the other), and disengage ground heater support plate, thus enabling you to free heater from spa pack.
  • Page 70 Any bending or twisting may cause damage to ceramic. Note: We recommend the use of an adjustable torque wrench (17 lb/in) to screw the top nut sufficiently. For more details, log on to: www.metapacks.com/a_tn.htm (Gecko's Tech News #9906) MSPA-MP Metapacks Service Manual...
  • Page 71 How To Replace The Heater Follow instructions below to replace an MSPA-MP pack heater in the vertical/side position. Note: Make sure to turn power to the pack off before proceeding. Ground connection Heater connections High-limit Lock nut wing nut (attaches and plate heater to pack)
  • Page 72 (17 lb/in) to screw the top nut sufficiently. For more details, log on to: www.metapacks.com/a_tn.htm 4• Use a wrench to remove the ground (Gecko's Tech News #9906) cable nut and disconnect the ground cable wire. MSPA-MP Metapacks Service Manual...
  • Page 73 How To Replace The Heater Instructions to replace an MSPA-MP pack heater configured for horizontal/back/bottom position. Note: Make sure to turn power to the pack off before proceeding. Pressure Heater Ground High limit Heater Heater switch connectors connector wing nut lock nut lock nut &...
  • Page 74: Adjust The Pressure Switch

    How To Adjust The Pressure Switch When a voltmeter is not available: 1• Turn Pump 1 off. 2• Decrease the pressure switch setting to 0.5 P .S.I. or until three flashing dots are displayed. 3• Start increasing pressure switch setting by very slowly turning adjustment screw clockwise until three flashing dots disappear, then another full turn.
  • Page 75 How To Adjust The Pressure Switch When a voltmeter is available: 1• Set voltmeter to "Ω" (while both probes are touching one another, voltmeter should beep to show there is continuity). 2• Turn Pump 1 off. 3• Do you have continuity on pressure switch? If you have no continuity, go to step 4.
  • Page 76: Parts List

    Parts List We recommend that field service technicians keep the items identified with an * in stock. Ref.: Part Number Description Suggested Retail U.S. 530AB0061 Tail piece for 2" heater 5.39 7.33 530AB0042-P5 Gasket for 2" tail piece (package of 5) 8.00 10.88 530AB0055...
  • Page 77 Parts List We recommend that field service technicians keep the items identified with an * in stock. Ref.: Part Number Description Suggested Retail U.S. Assembly board & plate MSPA-MP (cable included) 531.77 744.48 430AC0092-P10 Fuses for the transformer (package of 10) 11.14 15.15 9917-100169...
  • Page 78 Wiring Diagram (Vertical) The wiring diagram below provides a general idea of MSPA-MP wiring, but it is impor- tant to note that it may not apply to all systems. The wiring diagram including on inside power box cover is the one to be used as main reference for the spa you are servicing. Pump 1 Blower Circulation Pump...
  • Page 79 Wiring Diagram (Horizontal) The wiring diagram below provides a general idea of MSPA-MP wiring, but it is impor- tant to note that it may not apply to all systems. The wiring diagram including on inside power box cover is the one to be used as main reference for the spa you are servicing. Pump 1 Blower Circulation Pump...
  • Page 80 Professional Repair Kit All you need in one case! Gecko's professional repair kit contains all you need to service and repair Gecko's line of Metapacks. • Top side controls (keypads) • Temperature probes • Pressure switch cables • Flow switches •...
  • Page 81 Part Replacement Instructions Heater cover plate • & More Mounting base Gecko Electronics Inc., 450 des Canetons, Quebec City (QC) G2E 5W6 Canada, 1.800.78.GECKO, Fax: 418.872.0920 419 S. Las Posas Rd, San Marcos, CA 92069 USA, 1.877.78.GECKO, Fax: 760.736.3697 www.gecko-electronic.com 9919-100232...
