DRIVE - INSTRUCTION MANUAL
SDS Drive
DC-PWM Compatible
No part of this publication may be reproduced
or translated, even in part, without prior written
permission from WITTUR.
Subject to change without notice!
www.wittur.com
PM.2.004923.EN
Code
2020-07-22
Edition
Version
811-000-000
SEM ID
info@wittur.com
www.wittur.com
© Copyright WITTUR 2020
A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the sematic DC-PWM Compatible and is the answer not in the manual?

Questions and answers

jurg
July 11, 2025

how to start self lerning?

0

Subscribe to Our Youtube Channel

Related Manuals for WITTUR sematic DC-PWM Compatible

Summary of Contents for WITTUR sematic DC-PWM Compatible

  • Page 1 Code 2020-07-22 Edition DC-PWM Compatible Version 811-000-000 SEM ID No part of this publication may be reproduced info@wittur.com or translated, even in part, without prior written www.wittur.com permission from WITTUR. © Copyright WITTUR 2020 Subject to change without notice! www.wittur.com...

  • Page 3: Table Of Contents

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual Preface ���������������������������������������������������������������������������������������������������������������������������������������������������� 7 What is the Sematic DC-PWM Drive System Compatible? �������������������������������������������������������������������������� 8 © Speed profile ......................................9 General Features ������������������������������������������������������������������������������������������������������������������������������������ 10 Technical information ..................................10 Sematic Drive System Door Controller (DC-PWM) ........................10 ©...
  • Page 4 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 7�5�1 Option “Opening Parameters” ����������������������������������������������������������������������������������������������������� 25 7�5�2 Option “Closing Parameters” ������������������������������������������������������������������������������������������������������� 25 7�5�3 Option “Change Password” ��������������������������������������������������������������������������������������������������������� 25 7�5�4 Option “Reset speed” ����������������������������������������������������������������������������������������������������������������� 25 7�5�5 Option “Input levels logic”...
  • Page 5 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual Confidentiality agreement Disclaimer The software/hardware “Sematic Drive System ” and all the relevant information, ideas, con- © cepts and know-how are confidential and the exclusive property of Sematic. All information relevant to this instruction manual and any other support supplied by Sematic must be kept confidential and proprietary to Sematic and shall not to be copied or reproduced in any form whatsoever.
  • Page 6 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual We care about your integrated solution! COMPONENT SYSTEMS Automatic lift doors • Frame and frameless glass doors • • Enhanced car door operator solutions Complete cabins •...

  • Page 7: Preface

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual PREFACE This manual has been drafted taking into account that the Company installing genuine Sematic products will comply with the following necessary requirements: personnel responsible for the installation and/or maintenance of the doors must be familiar with the General and Specific •...

  • Page 8: Compatible

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual WHAT IS THE SEMATIC DC-PWM DRIVE SYSTEM COMPATIBLE? © The System consists of: a Car Door Operator (1) • a microprocessor-based Door Controller (2) •...

  • Page 9: Speed Profile

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual SPEED PROFILE Opening cycle Opening acceleration Opening hight speed Opening deceleration Closing cycle Closing acceleration Closing hight speed Closing deceleration Door opening Door closing Open Limit Close limit Closing cycle...

  • Page 10: General Features

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual GENERAL FEATURES TECHNICAL INFORMATION MAIN SUPPLY VOLTAGE 90-290 Vac (115 V-20%, 230V+26%), 50-60 Hz TYPICAL POWER CONSUMPTION 200 VA PEAK POWER CONSUMPTION 300 VA MOTOR OVERLOAD PROTECTION @In <15 minutes @2In <3 minutes...

  • Page 11: Signals To/From The Door Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual SIGNALS TO/FROM THE DOOR CONTROLLER SEMATIC DRIVE SYSTEM (DC-PWM) COMPATIBLE CONNECTIONS © DOOR POSITION LC SWITCH STATE RC SWITCH STATE RA SWITCH STATE LA SWITCH STATE Door closed OPEN CLOSED...

  • Page 12: Sematic Drive System Set-Up And Incoming/Outgoing Signals From The Door Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual SEMATIC DRIVE SYSTEM SET-UP AND INCOMING/OUTGOING SIGNALS FROM THE DOOR CONTROLLER © Magnetic switches Safety chains Main Lift Controller Photocells or Detector...
  • Page 13 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual INCOMING SIGNALS FROM THE DOOR CONTROLLER Signal Connector Pins Contact type & normal state Note Opening control Ka Connector pins These connections require dry When the Door Controller is (coming from the Main Lift 5-15...

  • Page 14: Detector/Photocell/Barriers: Signal-Only Connection To The Door Controller (Direct Connection)

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual OUTGOING SIGNALS FROM THE DOOR CONTROLLER Signal Connector Pins Contact type & Normal state Notes Opening limit switch contact La Connector pins These connections provide dry The contact is open when the door 16-17 (voltage free) contact.

  • Page 15: Detector/Photocell/Barriers: Complete Connection To The Door Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual DETECTOR/PHOTOCELL/BARRIERS: COMPLETE CONNECTION TO THE DOOR CONTROLLER Complete Connection means that the device draws its power supply from and sends the re-open signal directly and only to the Sematic Drive System controller.

  • Page 16: Magnetic Switches

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual MAGNETIC SWITCHES Verify that the magnet (1) has the countersink for the self-threading screw on the side of the magnetic switch (2). Open and close the door by means of the controller or manually and make sure that the magnetic switches work correctly. For K1-2-3R For K1-2-3L and K2-4-6 These are the operations of the magnetic switches:...

  • Page 17: Instruction Without Handset

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual INSTRUCTION WITHOUT HANDSET Display in Automatic and Manual Mode AUTOMATIC MODE “AUTO” When the Door Controller is working in automatic mode the “AUTO” red led is on, whereas the other two red leds are off. •...
  • Page 18 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual The following table contains the available parameters, the relevant codes, the description and the allowed modification range: Param. codes Default Parameter Range Note Reversing system choice 00, 01 00->...

  • Page 19: Functions Available

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual FUNCTIONS AVAILABLE REVERSING SYSTEM FORCE SETTING The reverse motion torque parameter sets the sensitivity degree to detect an obstacle during the door closure, thus giving the reopening command.

  • Page 20: Emulation Type

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual is closed in normal conditions and it opens to signal the presence of an obstacle. WARNING: if the selected logic is Kn N/C on obstruction open (contact opens to signal the presence of an obstacle) and is used only one protective device input (15-23) terminals for photocells, 30-31-32-33 terminals for direct connection of protective barriers), the other input must be shorted.

  • Page 21: Alarms

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 6.11 ALARMS The Sematic Drive System controller has the ability to diagnose and record a number of defects; such diagnostics is very helpful to the ©...

  • Page 22: Instruction With Handset

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual INSTRUCTION WITH HANDSET HANDSET (OPTIONAL) Fig. 1 Optional Kit - cod. B147AABX Recommendation! Although the handset (see picture 1) can be directly connected by the installer/maintenance personnel to the door controller on the car’s roof, the ideal situation is to have a connection with the door controller inside the car (see picture 2).

  • Page 23: User Handset Menus And Submenus

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual USER HANDSET MENUS AND SUBMENUS * only for Digidoor Emulation...

  • Page 24: Reversing System Force Setting By Means Of The Handset

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual REVERSING SYSTEM FORCE SETTING BY MEANS OF THE HANDSET • Connect the handset to RJ45 connector If necessary, using keys ã and ä choose the required language and confirm with the “OK” key •...

  • Page 25: Option "Opening Parameters

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual − RESERVED AREA • Using keys ã and ä run through the menu “PROFILE SETTING” and choose the option ADVANCED SETTING Using the “OK” key, confirm the option •...

  • Page 26: Option "Opening Slow Down Delay To Opening Rest Current" (Only For Digidoor Emulation)

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual • Press the "OK" key to confirm levels logic settings For the Digidoor Interface connection verify that: INPUT Ka â L Kc â L Kb â...

  • Page 27: General Option

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual GENERAL OPTION • Connect the handset to RJ45 connector; • If necessary, using keys ã and ä choose the required language and confirm with the “OK” key Using keys ã...

  • Page 28: Activation Of The Car Door Locking Device Setting By Means Of The Handset

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual • Using keys ã and ä, run through the GENERAL OPTIONS and choose the option LIMITED DOOR REVERSAL • Press key “OK” to confirm the choice The following options are viewed on the display: •...
  • Page 29 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual • The following options are viewed on the display: − Emulation F28 Emulation F29 − − Emulation DIGIDOOR 1Nm − Emulation DIGIDOOR 2Nm Emulation LM-DC 2010 −...

  • Page 30: Maintenance Menu - Diagnostics And Alarm Management

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual MAINTENANCE MENU - DIAGNOSTICS AND ALARM MANAGEMENT CONSULTING THE MAINTENANCE MENU WITH THE HANDSET • Connect the handset to the RJ45 connector If necessary, using keys ã and ä choose the required language and confirm with the “OK” key or confirm the suggested language •...

  • Page 31: Controller Software Upgrade

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 10 CONTROLLER SOFTWARE UPGRADE • Connect the handset to the RJ45 connector • If necessary, using keys ã and ä choose the required language and confirm with the “OK” key or confirm the suggested language with “OK”...

  • Page 32: Upgrade From Controllers Previous To F28/F29 Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual UPGRADE FROM CONTROLLERS PREVIOUS TO F28/F29 CONTROLLER (CONTROLLER TYPE: ASC 10/20, ADC10/11, SEM10/11, LMDC 10/11) F28/29 B • Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching transformer •...
  • Page 33 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual Add this bridge to connect the common line for all magnetic switches RA, RC, LA, LC. Pull-up resistors 1K8R 1W (to be mounted only if necessary for the adaptation to inverted input logic) Light curtain connection example in case of PNP output OPERATOR TERMINALS car roof Original connection between LA, LC, and MLC: TO BE REMOVED ABSOLUTELY!!!

  • Page 34: Upgrade From F28/F29 And Lmdc 2010/2011/Digidoor

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 12 UPGRADE FROM F28/F29 AND LMDC 2010/2011/DIGIDOOR Short instruction replacement F28/F29 and LMDC 2010/2011/DIGIDOOR Digidoor 1 Nm LMDC 2010 Digidoor 2 Nm LMDC 2011 Select the correct Emulation type at P22 â...

  • Page 35: Upgrade From F28/F29 Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 13 UPGRADE FROM F28/F29 CONTROLLER • Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching transformer •...
  • Page 36 PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual MAGNETIC BISTABLE SWITCHES SEMATIC SDS Rel. 3 FOR OPENING AND FUNCTION DC COMPATIBILE CLOSING LIMITS 16 IN La Opening limit switch input contact (from the magnetic switch) 17 IN La Opening limit switch COM (from the...

  • Page 37: Upgrade From F28/F29 Controller Rel. 2.0 Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 14 UPGRADE FROM F28/F29 CONTROLLER REL. 2.0 CONTROLLER • Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching transformer •...

  • Page 38: Upgrade From Lmdc 2010/11 Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 15 UPGRADE FROM LMDC 2010/11 CONTROLLER • Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching transformer •...

  • Page 39: Upgrade From Digidoor Controller

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 16 UPGRADE FROM DIGIDOOR CONTROLLER • Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching transformer •...

  • Page 40: Door Operator Maintenance

    PM.2.004923.EN - 811-000-000 SDS DC-PWM Compatible · Edition 22 July 2020 © Drive - Instruction Manual 17 DOOR OPERATOR MAINTENANCE At least once a year complete the following checks: • Clean the doors (tracks, bottom tracks, belts etc.) from dust or debris as this maintains the door good mechanical operation Check the electric connections and their fitting to the connectors •...
  • Page 42 YOUR GLOBAL PARTNER FOR COMPONENTS, MODULES AND SYSTEMS IN THE ELEVATOR INDUSTRY More information about Wittur Group available on-line. a WITTUR brand a WITTUR brand a WITTUR brand...
