EAW MS63 Dimensions

20.00
C L
6.12
TOP
DIMENSIONS APPLY
TO TOP AND BOTTOM
24.00
16.00
REMOVABLE GRILLE
PARTIALLY SHOWN
FRONT
MS63 LEFT
2.00

NOTES:

1. SYMBOL
7.75
3/8-16 THREADED HOLE (PI ANGLE).
2. SYMBOL
3. WEIGHT APPROX. 87 LBS.
4. SHIPPING WEIGHT APPROX. 93 LBS.
12.50
9.75
L C
8.50
RIGHT SIDE
DIMENSIONS APPLY
TO BOTH SIDES
INDICATES MOUNTING POINT,
INDICATES CENTER OF BALANCE.
INPUT
11.78
3.50
6.00
BACK
PRODUCTION
20.00
11.78
L C
13.81
EASTERN ACOUSTIC WORKS
