MS103 LEFT

20.00
L C
2.00
TOP
DIMENSIONS APPLY
TO TOP AND BOTTOM
24.00
20.00

REMOVABLE GRILLE

PARTIALLY SHOWN

FRONT

NOTES:

1. SYMBOL
THREADED HOLE (PI ANGLE)
3. SYMBOL
11.75
4. WEIGHT APPROX. 105 LBS.
5. SHIPPING WEIGHT APPROX. 115 LBS.
16.75
13.75
9.62
15.75
L C
15.75

RIGHT SIDE

DIMENSIONS APPLY
TO BOTH SIDES
PRODUCTION
INDICATES MOUNTING POINT 3/8-16
INDICATES CENTER OF BALANCE.
20.00
3.50
.13
L C
5.50

BACK

1.00
L C
15.78
6.00

INPUT
