EAW MM60 Specifications

FEATURES
• Multi-enclosure, dual-channel extended range
multimedia system
• 2x JF60 full range satellites plus 2x SB120
subwoofers
• Per JF60: 6.5-in LF/1.3-in tweeter
• Per SB120: 12-in LF/internal passive crossover/filter
network
• Switchable powering: full range passive or biamp
(passive MF/HF)
• For portable use or permanent installation
DESCRIPTION
A 2-channel 3-way extended range system combining 2x JF60
2-way full range systems and 2x SB120ixR subwoofers. Each
JF60 includes a 6.5-in woofer, a 1.3-in tweeter on a Wave
Guide Plate™ and a passive LF/HF crossover. Each SB120ixR
includes a 12-in woofer in a vented enclosure and a passive
sub/full range crossover. Powering mode is switchable: pas-
sive (3-way crossover) or bi-amplified (active sub/full range
with passive LF/HF crossover).
APPLICATIONS
The MM60 delivers extended range output at surprisingly high
levels with flat response. Simple to set up and power with
each subwoofer housing an internal passive crossover/filter
network. Switch allows choice of passive or bi-amp power-
ing. Six year warranty.
Applications include:
Band PA
Ballroom Events
Restaurants
PERFORMANCE
(data reflect per channel, passive crossover mode performance)
Frequency Response (1 Watt @ 1m)
3 db 55Hz to 19kHz
-10 dB 44Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
Extended Range 90
Impedance (Ohms)
Extended Range 5
Power Handling, AES Standard (Watts)
Extended Range 200
Calculated Maximum Output (dB SPL @ 1m)
Extended Range Peak 119.0
Extended Range Long Term 113.0
Recommended High-Pass Frequency
24 dB/Octave 35Hz
Special
Biamped Performance See JF60 and SB120 Datasheets
Nominal Coverage Angle, -6 dB Points (degrees)
Conical 110
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# MM60-888081 (B)/2 pp/5/1/00 • Printed In USA
MultiMedia
Boardrooms
Large Retail
SPECIFICATIONS MM60
Shown as one channel of an MM60 package.
PHYSICAL
Subwoofer
Subsystem 1x 12-in, vented (per SB120)
LF Subsystem 1x 6.5-in cone, sealed (per JF60
HF Subsystem 1x 1.3-in soft dome driver on WGP
Waveguide (per JF60)
Configuration 2 channel, 3-way, extended range,
4 enclosures
Powering Switchable: extended range
(passive sub/LF/HF crossover) or
bi-amplified (passive LF/HF
crossover)
Controls (switches, knobs) Powering mode switch (per sub)
Biamplified Crossover 100Hz
Cabinet Type (shape) JF 60:Trapezoidal
SB120: Rectangular
Enclosure Materials Baltic birch plywood
Finish Black catalyzed polyurethane
Connectors Per JF60:1x Neutrik NL4 Speakon
and 2-terminal barrier strip / per
SB120ixR: 2x Neutrik NL4 Speakon
(1 input, 1 output)
Suspension Hardware JF60: (6) 1/4"-20 threaded
mounting points (1 each top and
bottom, 4 on back for Omnimount
Series 75)/(2) 5/16"-18 threaded
mounting points on bottom for
external ultimate brand support
sstand
Grille Vinyl coated perforated steel
Mounting Bracket JF60 980001 wallmount bracket
