EAW MK5266 Dimensions

19.73
MK5266
12.00
C L
6.80
8.32
30°
TOP

DIMENSIONS APPLY

TO TOP AND BOTTOM
18.71
30.00

GRILLE PARTIALLY SHOWN

FRONT

A

NOTES:

1. SYMBOL
3/8-16 THREADED HOLE (NUT PLATE).
2. SYMBOL
3/8-16 THREADED HOLE (PI ANGLE).
15°
A
(19.00)
(6.09)

VIEW A-A

DIMENSIONS APPLY
TO BOTH SIDES

PROTOTYPE

INDICATES MOUNTING POINT,
INDICATES MOUNTING POINT,
(8.88)
5.25
C L

INPUT

26.10
7.25
5.07

BACK

1.95
EASTERN ACOUSTIC WORKS
26.07
13.03
1.97
