EAW MK5294 Technical Specifications

DESCRIPTION
EAW's MK5294 two-way loudspeaker system provides high
output, low distortion sound reinforcement for a wide range
of permanently installed audio applications.
The 15-in low frequency cone and 1.4-in exit/75mm voice
coil high frequency compression driver provide high output
and low distortion plus enhanced power handling capabili-
ties.
EAW's advanced beamwidth matching crossover selects a
crossover point where the HF horn's beamwidth matches that
of the woofer. The result is more even off-axis frequency
response (power response) for more complete coverage.
The MK5294 is a biamplified loudspeaker requiring the use
of pre-configured MX Series processor settings.
APPLICATION
The MK5294 was designed to support the widest possible
range of permanent installations and was optimized for use
in distributed systems.
Its high output capabilities let it cover a large seating area
in such applications as houses of worship, themed enter-
tainment venues, arenas, stadiums and nightclubs.
The comprehensive system of integral 3/8"-16 threaded
mounting points permit safe, load-rated suspension.
DESCRIPTIVE DATA
Configuration 2-way, Full Range
Powering Biamplified
LF Subsystem 1x 15-in, Vented
HF Subsystem 1x 1.4-in Exit/75mm Voice Coil
Compression Driver on Constant
Directivity Horn
Coverage Angles (h° x v° ) 90 x 45
Cabinet Type (shape) Trapezoidal
Enclosure Materials Baltic Birch Plywood
Finish Wear-resistant Textured Black
Paint
Connectors 2x 2-Terminal Barrier Strip
Suspension Hardware (13) 3/8"-16 Threaded Mounting
Points (3 each on top and bottom,
2 per side, 3 on rear)
Grill Powder Coated Perforated Steel
Dimensions Inches
Height 30.00
Width (front) 18.71
Width (back) 8.88
Depth 19.73
Trapezoid Angle 15 Degrees per Side
Weights Pounds
Net Weight 80
Shipping Weight 92
Acoustic Performance Partnership
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville MA, 01588 USA • Phone 508/234-6158 • Toll Free 800/992-5013 • Fax 508/234-8251 • Web http://www.eaw.com • email info@eaw.com
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. •PUB#888179 MK5294/2p/4/1/00 • Printed In USA
TECHNICAL SPECIFICATIONS MK5294
Millimeters
762
475
226
501
Kilograms
36.3
41.7
Eastern Acoustic Works MK5294
