- Page 1 0554 9330 WLAN communication module 0554 9320 testo UltraRange communication module 0554 9311 01 / 0554 9311 02 0554 9312 01 / 0554 9312 02 0554 9313 01 / 0554 9313 02 0554 9314 01 / 0554 9314 02 Instruction manual...
-
Page 2: Table Of Contents
Technical data for WLAN module ................. 8 testo UltraRange communication module ......... 8 Use ........................8 Product description ....................9 Commissioning ....................10 Technical data for the testo UltraRange communication module ....... 11 Maintenance ..................12 Cleaning the housing ..................12... -
Page 3: About This Document
1 About this document 1 About this document • The instruction manual is an integral part of the testo Saveris measurement data monitoring system. • Keep this documentation to hand so that you can refer to it when necessary. •... -
Page 4: Safety And Disposal
The product can only be used with other Testo components. Use of the product requires skilled personnel trained in the above areas. If the network ports used are PoE-enabled, power can be supplied to a connected testo 150 data logger module via the Ethernet cable. -
Page 5: Commissioning
6 LAN/PoE0F communication module Ethernet/PoE connection Ventilation slits Fastening screws Positioning aid connector Commissioning Attaching the communication module Remove the protective cap. Testo Communication Interface... -
Page 6: Technical Data For The Lan/Poe Communication Module
Attach the communication module to the testo 150 data logger module using the screws. Close screw openings with rubber plugs. It is not possible to replace communication modules while the testo 150 data logger module is in operation! To replace a communication module, the power supply must be disconnected (remove batteries/pull out mains plug). -
Page 7: Product Description
7 WLAN communication module The product can only be used with other Testo components. Use of the product requires skilled personnel trained in the above areas. Product description Overview Fastening screws Positioning aid TCI connector Commissioning Attaching the communication module Remove the protective cap. -
Page 8: Technical Data For Wlan Module
Attach the communication module to the testo 150 data logger module using the screws. Close screw openings with rubber plugs. It is not possible to replace communication modules while the testo 150 data logger module is in operation! To replace a communication module, the power supply must be disconnected (remove batteries/pull out mains plug). -
Page 9: Product Description
8 testo UltraRange communication module UltraRange communication modules are designed either for combination with testo 150 data logger modules or with the UltraRange Gateway. Use of the product requires skilled personnel trained in the above areas. An UltraRange Gateway is required to transmit data to the Saveris base when testo 150 data logger modules are combined with UltraRange communication modules. -
Page 10: Commissioning
When using wireless modules with external antenna, please ensure that the screw connection between antenna and module has been tightened. It is not possible to replace communication modules while the testo 150 data logger module is in operation! To replace a communication module, the power supply must be disconnected (remove batteries/pull out mains plug). -
Page 11: Technical Data For The Testo Ultrarange Communication Module
8 testo UltraRange communication module provided in the packaging, underneath the testo 150 data logger module. Technical data for the testo UltraRange communication module Feature Value 0554 9311 01 (Region EU, testo 150 Order no. data logger module) 0554 9311 02 (Region EU, UltraRange... -
Page 12: Maintenance
9 Maintenance 9 Maintenance 9.1 Cleaning the housing > If the housing is dirty, clean it with a damp cloth. Use distilled water, or alternatively mild solvents, such as isopropanol. If using isopropanol, please refer to the instruction leaflet for the product. Isopropanol fumes have a slight narcotic effect, and typically cause irritation of the eyes and sensitive mucous membranes. - Page 13 Testo SE & Co. KGaA Testo-Strasse 1 D-79853 Lenzkirch Germany Phone: +49 7653 681-0 Fax: +49 7653 681-7699 Email: info@testo.de www.testo.com 0970 2814 en 01...
- Page 14 Contains IC: 451I-CC3120MOD IC: 6127B-05549320 See IC Warnings Europa + EFTA The EU Declaration of Conformity can be found on the testo homepage www.testo.com under the product specific downloads. EU countries: Belgium (BE), Bulgaria (BG), Denmark (DK), Germany (DE), Estonia (EE), Finland...
- Page 15 IC Warnings including interference that may cause undesired operation Caution: Radio Frequency Radiation Exposure RSS‐Gen & RSS‐247 statement: RF exposure information: To maintain compliance with FCC RF exposure This device complies with Industry Canada licence‐exempt RSS requirements, use the product that maintain a 20cm separation distance standard(s).
