ELCOS LEM-434/45 Quick Start Manual

GB GE/FO240908
EMERGENCY AUTOMATIC PANELS EMERGENCY AUTOMATIC PANELS
FOR THREE-PHASE GENERATING SETS FOR THREE-PHASE GENERATING SETS
TYPE
LEM-434/45
LEM-434/60
LEM-434/80
LEM-434/100 100
This controls and operates a generator set,
keeps the starter battery charged and connects
the power users to either the mains or the generator.
It shows the main parameters of the generating
set on the display.
Kva Contactors capacity
AC1
45 90 A
60 110A
80 140A
200A
Three-phase mains
single-phase generator
voltmetriccontrol.
Automatic monitoring
ofanomalies
EJPFunction
Glow plugs preheating
management
Remote controls (start-
ing-test-stop)
A v a i l a b l e i n p u t f o r
anomaly
Clock for programming
the starting or the stop-
pingofthegenset
Programmable weekly
selftest
Complete with 8 instru-
ments
A n o m a l y h i s t o r i c a l
record (Including data
from the last 100 anoma-
lies).
®
