EAW EP2 Dimensions

NOTES:

1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (FLYTRACK).
2. SYMBOL INDICATES 3.00 X 1.35
FLYTRACK.
3. SYMBOL INDICATES CENTER OF BALANCE.
4. WEIGHT APPROX 130 LBS.
5. SHIPPINF WEIGHT APPROX. 145 LBS.
19.75
27.00

GRILLE PARTIALLY SHOWN

FRONT
30°
14.39
11.50
11.00
TOP HAT
BOTTOM
ONLY
C L
(11.00)
BOTTOM

DIMENSIONS APPLY

TO TOP & BOTTOM
2X HANDLE
1.53
22.74
2.13
VIEW A-A
DIMENSIONS APPLY
TO BOTH SIDES
A
8.56
11.00
A
PRODUCTION
6.44
6.12
8.75
13.75
3.48
5.52
EP2

POWER AMPLIFIER

2.13
C
L
22.74
AMPLIFIER
VENT INTAKE

BACK

EASTERN ACOUSTIC WORKS
