Prestige 47282 Manual

Prestige 47282 Manual

5l stainless steel model & 7.5l stainless steel model

Advertisement

Quick Links

5L & 7.5L
STAINLESS STEEL

Advertisement

loading
Need help?

Need help?

Do you have a question about the 47282 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prestige 47282

  • Page 1 5L & 7.5L STAINLESS STEEL...
  • Page 2 These instructions cover the following models: 47282 & 47283 - 5L stainless steel model & 7.5L stainless steel model This temperature is dictated by atmospheric pressure and cannot increase no matter how long boiling continues. The weight on your Prestige pressure cooker increases the pressure inside the cooker which See page 6 ‘To fit the lid on the cooker’...
  • Page 3 See page 8 ‘Cleaning the lid’ Regularly check all removable parts and if necessary re-tighten CAUTION: It is important that you read the above instructions carefully before using your pressure cooker.
  • Page 4 See page 3 ‘Do not overfill the cooker’ Using your own containers/heatproof dishes Generally foods cooked in a pressure cooker will take 1/3 of the normal cooking time. Whatever you cook remember not to overfill the cooker and to use cooker.
  • Page 5 15lb (103kPa) Weight Secondary Safety Device (SSD) / VPI Gasket visit us at www.prestige.co.uk IMPORTANT Please note that the gasket and SSD should be replaced every 12 months. Failure to do so may result in boil dry, prolonged cooking times, personal injury or damage to property.
  • Page 6 Nominal operating pressure N.O.P 103 kPA/15 psi Maximum operating pressure M.A.P 160 kPA/23 psi 15lb (103 kPa) weight supplied Place the 15lb (103 kPa)weight onto the vent tube, make sure it clicks into Gasket Release System (GRS) place. If the vent tube and SSD become blocked, pressure inside the cooker will Place the cooker on the heat source and turn the heat to a high setting, ensuring gas flames do not spread up the side walls of your cooker.
  • Page 7 Put the required amount of water in the cooker. Remember if slow release is used the cooking time is increased as the cooker remains at pressure for longer. Stand the cooker in the sink and pour cold running water over the lid. Make sure no water runs into the vent tube or visual pressure indicator Ensure that gas flames do not spread up the side walls of your cooker.
  • Page 8 If you make sure that you always have sufficient liquid, that you do not leave the cooker steaming or cooking for long periods on too high a heat, and you replace the gasket and secondary safety device regularly, your cooker should never boil dry. If the cooker ever does boil dry, the heat must be turned off and the cooker left to cool before moving.
  • Page 9 What to do if Possible Cause Ac on Advice Cooker will not come to pressure Lid gasket leaking See “Gasket leakage”. Lid is not closed properly Ensure the cooker lid is aligned/posi See Page 6. “To fit lid on the cooker” correctly Weight assembly not fi...
  • Page 10 What to do if Possible Cause Ac on Advice Visual Pressure Indicator does not Visual pressure indicator s cking. Gently tap the lid handle. rise. Lid gasket leaking. See “Gasket leakage”. Lid is not closed properly Ensure the cooker lid is aligned/posi correctly See Page 6.
  • Page 11 See “Gasket leakage”. The gasket should be replaced every 12 recommended times? gasket. months regardless of use. Ensure all parts purchased are original Prestige replacement parts. Meat & vegetables are not cut to Always follow recipe recommendation for sizes Visit www.prestige.co.uk...
  • Page 12 What to do if Possible Cause Action Advice Why does liquid seep out while Over-filled with liquid Always follow recipe recommendation for See page 7. “Releasing steam after releasing pressure? liquid content, release of pressure & cooking”. thickening dishes after cooking. Steam was released quickly when Always follow recipe recommendation for See page 7.
  • Page 13 The Weight Assembly Knob and Vent Tube Secondary Safety Device (SSD) This device ensures that pressure is maintained inside the appliance while If the weight assembly knob fails to function due to overload or blockage of cooking at 15lb/psi (103 kPa)above atmospheric pressure. Once the pressure the vent tube, the pressure Inside goes above the nominal level (103 kPa) (15lbs/psi).
  • Page 14 The body and lid of your Pres ge pressure cooker is guaranteed for a period of 15 years from date of purchase to be free from defects in materials andworkmanship under normalhousehold use. The gasket and SSD are guaranteed for only 12 months. The guarantee is invalidated by failure to replace the gasket and SSD and by the use of parts which are not original Pres ge replacement parts.
  • Page 16 Version 2 – Feb 2020 - PU3676A...

This manual is also suitable for:

47283
