LDO-10 MKII FS
User Manual
Version: 08/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDO-10 MKII FS and is the answer not in the manual?

Questions and answers

Summary of Contents for Showlite LDO-10 MKII FS

  • Page 1 LDO-10 MKII FS User Manual Version: 08/2020...
  • Page 2 Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read and understand this manual carefully. PLEASE READ CAREFULLY Please keep this manual in a safe place for future reference. Hand over all documents when passing on the product to third parties.
  • Page 3 All information in this operating manual has been checked to the best of our knowledge and belief. However, neither the author nor the publisher can be held liable for any damages related to the use of this manual. Other product, brand and company names mentioned in this document may be the trademarks of their respective owners.
  • Page 4 Mains voltage If an external power supply unit is required for use, connect it to an outlet with the correct voltage. Do not connect the device to a different mains voltage than that for which your product is intended. Unplug the power cord from the wall outlet when not using the product or when there is a thunderstorm.
  • Page 5: Table Of Contents

    © 2020 This manual is protected by copyright. Copying or reprinting, even in extracts, is only permitted with the consent of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of pictures, also in modified form. Content 1. Connections and operating elements .............. 6 1.1 Front panel controls ..................
  • Page 6: Connections And Operating Elements

    1. Connections and operating elements 1.1 Front panel controls 1. Colour selector switch spot 1-4 12-step 9. Fading speed (fade time) 2. Fader brightness spot 1-4 / 0...100% 10. Stroboscope speed 3. Selection chaser/bank 12-step 11. Blackout/standby (all LEDs off) 4.
  • Page 7: Power Supply And Dmx Cabling

    DMX channel assignment at the selection switch (18) (see below for coding) and switch on the DMX controller with the ON/OFF switch (22). Switch on the connected LED spotlights as well. For Showlite DRGB LED fixtures, which all have the same DMX channel assignment, use standard switch position 5. For fixtures of other brands, please activate the channel assignment according to their user manual.
  • Page 8: Dmx Addressing For The Operation Of Rgb Compact Systems

    2.3 DMX addressing for the operation of RGB compact systems: Set the selector switch for the DMX start addresses (17) to position (1/4/7/10). The unit is also suitable for controlling compact systems with four built-in RGB (RGBD/DRGB) or RGBW (RGBWD/DRGBW) fixtures. Select the appropriate switch position on the selection switch (18). Switch on the DMX controller with the ON/OFF switch (22).
  • Page 9 Switch DMX-Chanel Description Fixture Brigtness Color Chanel-Mode (Startaddress 001) Fader/Control Color-Selector 4RGBWD CH 1 Red Dimmer CH 2 Green Dimmer Spot 1 CH 3 Blue Dimmer CH 4 White Dimmer CH 5 Red Dimmer CH 6 Green Dimmer Spot 2 CH 7 Blue Dimmer CH 8...
  • Page 10: Operation

    3. Operation The Showlite LDO-10 Led Operator works in manual, automatic and music control modes. After switching on, the last operating mode is active (which was activated for at least 10sec before switching off). You select the operating mode by pressing the button Automatic (13) or Music control (14). The corresponding LED displays (green / blue) light up.
  • Page 11: Music Control

    Press the Auto (25) or Music (26) button on the foot control to remotely control the corresponding functions of the DMX operator. The corresponding LEDs on the footswitch and the LDO-10 MKII FS will light up simultaneously. Press the Blackput button (27) to switch off all connected fixtures simultaneously. The red LED on the footswitch lights up and the red LED (Blackout) in the control panel of the LDO 10 MKII FS starts flashing.
  • Page 12: Appendix: Technical Data

    Appendix: Technical Data Power Supply DC 9V 800mA Music control MIC int. / Audio external 6.35mm User Chases 12 chasers of 12 scenes Preset Chases 12 chasers of 12 scenes DMX 512 DMX Output 3pin Colors Dimensions [mm] 240 x 140 x 70 Weight 1.2 kg...
  • Page 13 WEEE declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured with high quality materials and components that are recyclable and can be reused. This symbol means that electrical and electronic devices must be disposed of separately from household waste at the end of their useful life.
