Amarey A90 User Manual

Robotic vacuum cleaner
Hide thumbs

Advertisement

Table of Contents

A90 Robotic Vacuum Cleaner User Manual
Please read this instruction carefully before usage and keep it properly

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amarey A90

Summary of Contents for Amarey A90

  • Page 1 A90 Robotic Vacuum Cleaner User Manual Please read this instruction carefully before usage and keep it properly...

  • Page 2: Important Safety Instructions

    • Ensure that Robot cannot get caught on clothing, socks, pull cords for blinds or curtains, power cords, etc. • Only charge the following amarey batteries: maximum 14.4V,2600mAh Lithium-ion battery. Other type of batteries may burst causing injury. Always contact amarey Customer Service Center for the correct replacement of battery.

  • Page 3: Battery And Charging/Information

    the battery pack near any heat source or direct sunlight, Do not incinerate or short-circuit the battery pack. Do not subject batteries to mechanical shock. Battery and Charging/Information Lithium-ion Battery Important: Lithium-ion batteries and products that contain Lithium-ion are subject to stringent transportation regula- tions.
  • Page 4 (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications that not expressly approved by the party responsible for compliance could void the user's authori- ty to operate the equipment.
  • Page 5 2． About Your Amarey A90 ①.Top View ②.Bottom View Infrared Bumper Charging Contact Points Cliff Sensor Camera Swivel Wheel Wi-Fi Indicator Wi-Fi Indicator Start/Pause Start/Pause Side Brushes Wheel Rolling brush Dust Bin Main Power switch (On/Off)
  • Page 6 ③. Dust Bin Primary Filter Primary Filter Filter Lower Cover High Efficiency Filter Sponge Filter Filter Upper Cover Bin Release Button Upper cover of Dust Bin Upper cover of Dust Bin...
  • Page 7 ④.Charging Dock/Adapter Adapter Charging indicator Signal emission Area Charging Contact Points...
  • Page 8 ⑤.What’ s in the Box amarey A90 Charging Base 4 X Side Brush Sponge Filter and Adapter Cleaning Tool High Efficiency Filter...
  • Page 9 3． Using Your Amarey A90 ①.Important Tips Before Using A90 Before robotic vacuum works, please refer to the following guidelines to check the cleaning area. Remove power cords and A90 is not suitable for Anti-fall sensors can prevent Keep A90 away from small objects from the floor...
  • Page 10 ②. Preparations （1） Position the Charging Base on a hard level surface and against a wall. Ensure the place is an open & uncluttered area leaving at least 4ft in the front and 1.6ft on both sides. （2） Connect the round end of the adapter into the power socket on the Charging Connect the round end of the adapter into the power socket on the Charging Dock and the other end into a wall outlet.
  • Page 11 （3） Before usage, Please remove the protective strips. protective strip Protective strip (4) Install the side brushes by pressing them into each slot until you hear the a “click”.
  • Page 12 （5） Turn on the Main Power Switch at the bottom of Robot (1 refer to power on, 0 refer to power off). The robot can start working after startup music. ③. Charging Robot Place robot onto the Charging Dock, ensure the Charging Contact Points on Charging Dock and the bottom of robot are contact well.
  • Page 13 ④. Download and Install APP (1) Download and install app (2) Reset Wi-Fi (2) Reset Wi-Fi Download APP by scanning below QR code. Press the key “ Press the key “ ” for 5S, and you will hear voice prompt ”...

  • Page 14: Auto Cleaning

    ⑤.Clean Mode (1) Auto Cleaning Method 1: Power on robot, after the startup music, press Method 1: Power on robot, after the startup music, press button on panel, auto cleaning will start. button on panel, auto cleaning will start. Method 2: Click the “Start cleaning” button thru APP to start cleaning (press the pause button to pause the current task). Reminder: If power is less than 20%, Robot will not be able to carry out cleaning task, please charge it before next cleaning.

  • Page 15: Schedule Cleaning

    (3) Schedule Cleaning Schedule cleaning can be set thru APP. The robot will automatically start cleaning at the specified time you set and return to the charging base after cleaning. (4) Smart Area 1.Area cleaning After Smart Map generated successfully, the user can divide the map into different areas according the cleaning needs.

  • Page 16: Docking Mode

    • The boundary area may be invalidated due to moving the charging base or furniture. So please do not to move or interfere the robot during cleaning. Due to APP updating, the functions and details may have some changes, please refer to the actual version. (5) Docking Mode Auto mode：...

  • Page 17: Product Maintenance

    4． Product Maintenance Tip: Before maintenance of the robot and spare parts, please turn off the main switch at the bottom. ①.Dust Bin Press Bin Release Button to remove dust bin and clean it. Tip: Please empty the dust bin after each usage.
  • Page 18 ②.Filters （2） Clean the Dust Bin and filters with provided Cleaning Tool. （1） Take the filters out from the Dust Bin. （3） Put the filters back together in the Dust Bin. Tip: Clean the filter once a week and replace it every 2 months.
  • Page 19 ③. Rolling Brush Remove brush cover, take out the rolling brush, clean the vacuuming aisle by a cloth. If the rolling brush has hairs winded, please cut them down with the knife on cleaning tool. � � � �...
  • Page 20 ④.Side Brush ⑤.Swivel Wheel Pull out the side brushes, use the knife on cleaning Clean the swivel wheel with a cloth. tool to cut winded hairs, and then use cloth to clean it. Tip: Please clean the rolling brush and side brushes once a week, change the side brush every 3 months, and change the rolling brush every 6 months.
  • Page 21 ⑥.Cliff sensor Use a dry cloth to clean cliff sensors to ensure the sensitivity.

  • Page 22: Troubleshooting

    5． Troubleshooting Problems Causes Solutions Charging Dock has no electricity. Ensure the charging cord is plugged into the dock and wall outlet, and the light on the Charging Dock is white. Robot cannot Clean the charging connection points on both Charging Dock and The poor connection of the charged bottom of the Robot with dry cloth.
  • Page 23 Left / right wheel The left / right wheel may be Check left / right wheel for entanglement and clean the side wheel. entangled. abnormal The Dust Bin is full Empty Dust Bin Weak suction Filter clogged or wet Clean and dry the filter or replace it with a new one. The Main Power Switch on the Turn on the Main Power Switch at the bottom of Robot.

  • Page 24: Specifications

    6． Specifications A90 Robotic Vacuum Cleaner Robot Vacuum Charging Dock Dimensions 325*325*80mm Dimensions 170*137*95mm Battery 2600mAH Adapter Input Voltage AC 100-240V Wireless connection 2.4GHz Wi-Fi Rated Output 19V/600mA Rated Power Rated Frequency 50/60Hz Rated Voltage 14.4V Charging Time Working Hours 120min 7.Amarey Customer Care...
  • Page 25 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
