  • Page 1 INSTRUCTION MANUAL 160 / Integrated Mixer/ Amplifiers...
  • Page 2: Table Of Contents

    There are many factors to be considered when installing professional sound reinforcement systems, including mechanical and electrical considerations, as well as acoustic coverage and performance. EAW Commercial strongly recommends that this equipment be installed only by a professional sound installer or contractor. TABLE OF CONTENTS 1.
  • Page 3: Introduction

    The CAM160 has a 160 watt power amplifier, and the CAM80 has 80 watts. Apart from this difference in power output, the two models are identical in details and operation.
  • Page 4: Front Panel Features

    10 kHz. Turn it counter-clockwise to cut the level. In the detented center position, there is no change in level. The maximum boost and cut is 12 dB. – CAM160 / CAM80 5. MASTER VOLUME Use this volume control to adjust the sound output level to your speakers.
  • Page 5: Rear Panel Features

    Mic Level Mic Level DIP 6 DIP 7 Enabled DOWN DOWN DOWN Enabled DOWN see table see table Enabled RESULT No Ducking - 10 dB Duck threshold - 20 dB Duck threshold - 30 dB Duck threshold CAM160 / CAM80 –...
  • Page 6: Dip Switches

    Chime 1 or Chime 2 prepares the circuit. Closing the switch actuates the Chime. – CAM160 / CAM80 INPUTS 3, 4, 5, 6 Inputs 3, 4, 5 and 6 have identical connections and controls. (Input 3 is shown here.)
  • Page 7 This external connector can be used to connect to an external device to initiate a “fault” action as dictated by the user. Additionally, the “fault” LED on the front of the amplifier will light. CAM160 / CAM80 –...
  • Page 8: Output Connectors

    80% of the rated power of the amplifier being used (CAM160: 128 watts, CAM80: 64 watts). For example, for the CAM160, you could use a maximum of 12 speakers with 10 watt taps (12x10 = 120 watts). For further...
  • Page 9 Use Class II wiring: 100V 8. AC Power The CAM160 and CAM80 are fitted with a detachable IEC socket for AC input. Each unit is fitted with a universal power supply, allowing it to operate from any AC mains supply from 100 to 240 VAC, 50-60 Hz.
  • Page 10: Xlr Connectors

    Pin 1 = Shield Pin 2 = Hot (+) Pin 3 = Cold (–) – CAM160 / CAM80 1/4" TRS Phone Plugs and Jacks “TRS” stands for Tip-Ring-Sleeve, the three connections available on a stereo 1/4" or balanced phone jack or plug.
  • Page 11: Typical Hookup Diagram

    7. TYPICAL HOOKUP DIAGRAM CAM160 / CAM80 –...
  • Page 12: Specifications

    80 W @ 100 V 80 W @ 70 V 80 W @ 25 V 80 W @ 4 Ω CAM160 Output Power at 1% THD @ 1 kHz: 160 W @ 100V 160 W @ 70V 160 W @ 25 V 160 W @ 4 Ω...
  • Page 13: Block Diagram

    CAM160 / CAM80 –...
  • Page 14: Service Information

    9. SERVICE INFORMATION In the event that your CAM160 or CAM80 should require servicing, please follow these instructions: 1. Call EAW Commercial Tech Support at 1-800-992-5013, 7 am to 5 pm PST (Monday-Friday), to verify the problem and obtain a Return Authorization (RA) Number. Be sure to have the serial number of the unit when you call.
  • Page 15: Eaw Commercial Warranty

    Exterior defects in or damage to the exterior appearance are specifically excluded from this warranty. EAW Commercial distributors shall not be liable for incidental or consequential damages resulting from the use of EAW Commercial products. Repairs and/or modifications by other than an Authorized EAW Commercial Distributor automatically voids this warranty.
  • Page 16 EAW Commercial A LOUD Technologies Inc. Company EAW Commercial | One Main Street | Whitinsville, MA 01588 USA | TEL toll free within US/Canada 800-992-5013 TEL outside US 508-234-6158 | FAX 508-234-8251 | www.eaw.com © 2007-2008 LOUD Technologies Inc. All Rights Reserved.
