- Page 1 OWNER’S MANUAL 110V EDGE BANDING KIT 60-410 Should you require assistance, please have available your: Model no.: __________________ Serial no.: __________________...
- Page 2 The manufacturer warrants its machines to be free from defects in workmanship and materials for a period of 2 years from the date of the original purchase for Steel City shop machines or for a period of 1 year for Titanium production machines;...
-
Page 3: Table Of Contents
The drawings, illustrations, photographs, and specifications in this user manual represent your machine at time of print. However, changes may be made to your machine or this manual at any time with no obligation to Steel City. PRODUCT SPECIFICATIONS 60-410 Overall dimensions 13,4”... -
Page 4: Safety
SAFETY This manual is not totally comprehensive. It does not and can not convey every possible safety and operational problem which may arise while using this machine. The manual will cover many of the basic and specific safety procedures needed in an industrial environment. WARNING All federal and state laws and any regulations having jurisdiction covering the safety requirements for use of this... - Page 5 22. DO NOT operate any machine or tool if under the 4. Prevent electrical shock. Follow all electrical and safety codes, including the National Electrical Code (NEC) and influence of drugs, alcohol, or medication. the Occupational Safety and Health Regulations 23.
-
Page 6: Product Safety
PRODUCT SAFETY CAUTION - HOT SURFACES ◊ INHERENTLY UNSTABLE OPERATION Touching hot parts can cause severe Using a portable edgebander requires great care and burns. Always hold the machine by the attention. handles. Pay attention to liquid glue which is very hot (200°C). Wear adequate protective gloves and safety glasses. -
Page 7: Electrical And Grounding Instructions
ELECTRICAL AND GROUNDING INSTRUCTIONS WARNING IMPROPER ELECTRICAL CONNECTION equipment-grounding conductor can result in risk of electric To reduce the risk of electric shock, follow all shock. The conductor with the green insulation (with or electrical and safety codes, including the without yellow stripes) is the equipment-grounding National Electric Code (NEC) and the conductor. -
Page 8: Features Identification
FEATURES IDENTIFICATION Tape insert guide Control panel Thickness adjustment knob Switch Speed control Fuse Feed rollers Clamping lever Guiding plate 10. Glue pot cover 11. Glue volume dialing knob 12. Rollers Page 8... -
Page 9: Unpacking And Inventory
Bare metal surfaces have been coated by a rust prevention compound at the factory. Protected surfaces Please report any damaged or missing part to your must be cleaned prior to assembly and installation. Steel City dealer immediately. Use appropriate cleaner and follow relevant safety measures. Portable edge-bander... -
Page 10: Controls
CONTROLS ◊ EDGEBANDER Following illustrate the various controls of the edgebander : Front view Rear view 1. Main switch: powers on the tool Feed roller (does not activate the glue pot) Glue distribution dial 2. Control panel (see functions next) Heated pressure plate 3. -
Page 11: Control Panel Functions
Setting nOTE: will be input to machine 3 seconds after The SCM 60-410 features two Hibernate states, to prevent the ‘beep’ sounds. glue from cooking from long term standby mode. After pressing the glue pot heating switch, the Ready to operate light will turn ON once the temperature reaches 120°C (250°F). -
Page 12: Preparation
Hot melt glue brands such as Kleiberit VP929657, Dorus KS224/2 or Jowat 280.30 , should be compatible Loosen the tape insert guide knob (fig. 1). with the SCM 60-410. Please refer to glue performance guide of each brand thoroughly. The SCM 60-410 is suitable for edge-banding on straight edges and on outside and inside curves. - Page 13 Refer to the width displayed by the measuring wing (fig. 3). (FIG.3) and adjust the guiding plate (fig. 4) to the same edgebanding width by loosening the lock lever and adjust the guide plate position using the guide plate height scale. (FIG.5) (FIG.4) After the guide plate angle is correctly adjusted, check...
- Page 14 ◊ gluE adJusTMEnT We adjust the amount of glue applied according to the edge banding width by mean of the glue volume dial (FIG.8) (a). This controls the amount of glue applied to the glue roller (fig. 6). Adjust the glue volume dial (fig. 9) to increase or Then we adjust the thickness of the banding by mean decrease the amount of glue provided to the glue roller.
-
Page 15: Operation
OPERATION ◊ OvErviEW For circular shaped workpieces, as we finish close to the starting point, maintain the guide plate against the After preparation, adjustments and run test are done, surface of workpiece while moving edgebander away machine operating temperature, from the edge just before the tape ends (fig. 13). edgebanding operation can start. -
Page 16: Accessories
ACCESSORIES ◊ vacuuM claMps sET iMpOrTanT nOTE during OpEraTiOn: • The suction force and the suction period of time might A set of vacuum clamps is supplied with the edge be affected by the quality, smoothness and flatness of bander: the workpiece, the dust on it and the size and weight of the workpiece. - Page 17 ◊ TriMMEr ◊ sTaTiOnary cOnvErsiOn TablE This small router has micro-adjustment for accurate Offered as an option, a conversion table allows removal of the excess edge banding, and the guide mounting of the SCM60-410 edge bander to become a bearing allows the use on inside curves with radius of stationary edge banding machine, with a tape 1’’.
-
Page 18: Maintenance
MAINTENANCE ◊ clEaning ◊ ErrOr MEssagE Keep the machine clean at all times. The SCM60-410 is built with error detect function. There are 4 error messages that can display: Remove glue from the outfeed side of the base and from the feed rollers. Bring the machine to normal working temperature to soften the glue and use a soft Voltage error: input voltage is different from machine setting. -
Page 19: Circuit Diagram
CIRCUIT DIAGRAM Page 19... -
Page 20: Parts List
PARTS LIST Page 20... - Page 21 S6041001A S6041005B S6041001A-1 S6041006B S6041001A-2 S6041006B-1 S6041001A-3 S6041006B-2 S6041001A-4 S6041006B-3 S6041002A S6041006B-4 S6041002A-1 S6041007A S6041002A-2 S6041007A-1 S6041002A-3 S6041007A-2 S6041003A S6041008C S6041004E S6041009C S6041004E-1 S6041010A S6041004E-2 S6041011B S6041004E-3 S6041011B-1 S6041004E-4 S6041011B-2 S6041004E-5 S6041011B-3 S6041004E-6 S6041011B-4 S6041004E-7 S6041011B-5 S6041004E-8 S6041012B S6041004E-9 S6041013A S6041004E-10 S6041014B S6041004E-11...
- Page 22 S6041014B-5 S6041018B-1 S6041026A S6041040A-1 S6041014B-6 S6041018B-2 S6041028A S6041040A-2 S6041014B-7 S6041018B-3 S6041029A S6041041A S6041015B S6041018B-4 S6041030A S6041045A S6041015B-1 S6041018B-5 S6041032A S6041046B S6041015B-2 S6041018B-6 S6041032A-1 S6041046B-1 S6041015B-3 S6041018B-7 S6041032A-2 S6041046B-2 S6041015B-4 S6041018B-8 S6041033C S6041046B-3 S6041015B-5 S6041019B S6041033C-1 S6041046B-4 S6041016B S6041020A S6041033C-2 S6041047B S6041016B-1 S6041021B S6041033C-3 S6041047B-1...
- Page 23 S6041026A S6041040A-1 S6041040A-1 S6041028A S6041040A-2 S6041040A-2 S6041029A S6041041A S6041041A S6041030A S6041045A S6041045A S6041032A S6041046B S6041046B S6041032A-1 S6041046B-1 S6041046B-1 S6041032A-2 S6041046B-2 S6041046B-2 S6041033C S6041046B-3 S6041046B-3 S6041033C-1 S6041046B-4 S6041046B-4 S6041033C-2 S6041047B S6041047B S6041033C-3 S6041047B-1 S6041047B-1 S6041033C-4 S6041047B-2 S6041047B-2 S6041033C-5 S6041047B-3 S6041047B-3 S6041033C-6 S6041048A S6041048A S6041033C-7 S6041048A-1 S6041048A-1...
- Page 24 NOTES Page 24...
