I
I
Installing and Setuping the Virtual Modem
This section explains how to use the Pocket PC to simulate a Wireless
Modem. After connecting successfully to the desktop computer through the
infrared (IR) device, you can use the desktop computer to perform tasks, such
as connecting to a network, etc.
1. Supports IrDA port function
2. Microsoft Windows 2000 or XP
Setting up
1. Personal computer side:
(1)
Use the Internet to download and install the PC driver program. Refer to
the documentation and screen instructions to establish a new connection.
(2)
Click
, Settings, Control Panel, and then Network and Dial-up
Connections.
(3)
Look for the new connection you just established and click the right
mouse button. Then, run Dial on the pop-up menu to connect successfully.
n
f
r
a
r
e
d
P
a
n
f
r
a
r
e
d
P
a
PC System Requirements
1
r
t
r
t
Advertisement
Related Manuals for ETen M500
Summary of Contents for ETen M500
- Page 1 Installing and Setuping the Virtual Modem This section explains how to use the Pocket PC to simulate a Wireless Modem. After connecting successfully to the desktop computer through the infrared (IR) device, you can use the desktop computer to perform tasks, such as connecting to a network, etc.
- Page 2 End the ActiveSync connection between the personal computer (desktop or notebook) and the Pocket PC. Under the ActiveSync program on the personal computer, tap File and then Connection Settings. Make sure you did not check “Allow serial cable or infrared connection to this COM port.”...
- Page 3 When your Pocket PC is simulating a modem, you can use the personal computer to access a network. , Programs, Phone, and then Wireless Modem to use the Irda function to connect the personal computer to the Pocket Tap Irda Connect Button: Tap to connect.
- Page 4 Installing Infrared Connection Options Use the Internet to download and install the Wireless Link file, it is a PC driver program. We need to establish a new connection. After your Pocket PC connecting successfully to the desktop computer, you can use the desktop computer to perform tasks, such as connecting to the network, etc.
- Page 5 Refer to the following explanation to set up. 1. Click , Settings, Control Panel, and then Wireless Link. 2. Select the Image Transfer tab, confirm not to check “Use Wireless Link to transfer images from a digital camera to your computer.”...
- Page 6 Refer to the following explanation to set up a virtual modem. 1. Click , Settings, Control Panel, and then Phone and Modem Options. 2. Select the Modems tab and then click Add to add a new virtual modem. 3. Check “Don’t detect my modem;...
- Page 7 5. Select the same COM port you selected earlier using the IrCOMM2k setup program, and then click Next. 6. Click Finish. You have set up a virtual modem successfully.
- Page 8 Refer to the following explanation to set up properties of the virtual modem. 1. Click , Settings, Control Panel, and then Phone and Modem Options. 2. Select the Modems tab and select the virtual modem you have just set up, and then click Properties.
- Page 9 Refer to the following explanation to establish a new connection. 1. Click , Settings, Control Panel, Network and Dial-up Connections, and then Make New Connection. 2. Click Next. 3. Select “Dial-up to the Internet,” and then click Next. 4. Select “I want to set up my Internet connection manually, or I want to connect through a local...
- Page 10 5. Select “I connect through a phone line and a modem,” and then click Next. 6. Do not check “Use area code and dialing rules”. Input *99#” in the Telephone Number field and click Next. 7. Input your Internet account user name and password.
- Page 11 MyConnt 8. Input any name you want to use and click Next. 9. Select No and click Next. 10. Click Finish. You have established a new connection successfully.
- Page 12 Refer to the following explanation to set up properties of the new connection. MyConnt 1. Click , Settings, Control Panel, and then Network and Dial-up Connections. 2. Look for the new connection you just established and click the right mouse button. Select Properties from the pop-up menu.
- Page 13 4. Do not check the following items: Enable hardware flow control Enable modem error control Enable modem compression Enable modem speaker Finally click OK to save. 5. Select the Networking tab and confirm that you have selected “Internet Protocol (TCP/IP),” and click Properties.
- Page 14 7. Do not check “Use IP Header compression.” 8. Finally, click OK. You have finished setting up all properties for this new connection. Now you can exit Network and Dial-up Connections.
