Page 3
The following Step Test Procedures have been provided to troubleshoot and test all of the Keep fingers, arms, Kwikee automatic electric step functions. They are designed to initially check the step's basic functions separately from the RV wiring to determine whether or not the step is malfunctioning.
Page 4
47 Series Operation Manual Page 4 FIGURE 2: Wiring diagram for step with control unit 12 AWG green Not used 12 AWG green ground wire ground to step top must be securely attached to Step Wiring the chassis for step to operate...
Page 5
47 Series Operation Manual Page 5 FIGURE 3: Wiring diagram for steps with door switch only operation 12 AWG green Not used 12 AWG green ground wire ground to step top must be securely attached to Step Wiring the chassis for step to operate...
Page 6
The reading should be 0 volts DC. If the voltage reading is more, the white wire is connected to 12 volts and should be cut. If you have additional questions or need more assistance, contact Kwikee’s Service Representative at 1-800-736-9961.
Page 7
Page 7 47 Series Operation Manual FIGURE 5: Check override switch FIGURE 6: Check door switch 4-way connector (vehicle-side) 4-way connector White (vehicle-side) Brown Ground wire: green ground wire must be attached to vehicle chassis; a good ground is needed...
Page 8
Since it is the responsibility of the owner to verify the original purchase date, downloadable Kwikee recommends that a bill of sale or sales receipt be kept for that purpose. documents. The duration of any implied warranty of merchantability or fitness for a...
