Summary of Contents for Invacare Kiwi Lite
-
Page 1: Front Cover
Kiwi Lite Owners Manual... -
Page 2: Table Of Contents
Owners Manual Index Description Front cover Page 1 Index Page 2 Introduction Page 3 Getting acquainted with your wheelchair Page 4 Folding and unfolding your wheelchair Page 5 Cross bracing Page 5 Anti tippers Page 5 Armrests and height adjustment Page 6 Leg rest and adjusting Page 7... -
Page 3: Introduction
A New Zealand manufactured product, which has been designed with your needs in mind. With proper care and maintenance your Kiwi Lite will provide you with years of trouble free service. Please take the trouble to carefully read this owners manual and if you have any queries whatsoever, contact your healthcare professional or Invacare New Zealand. -
Page 4: Getting Acquainted With Your Wheelchair
Getting acquainted with your chair 1. Handgrip 2. Back cane. 3. Height adjustable armrests, desk or full. 4. Flip back armrests. 5. Wheel locks/brakes. 6. Leg rest upper. 7. Back upholstery. 8. Seat upholstery. 9. Crossing bracing. 10. Lower leg rests and footplate. 11. -
Page 5: Folding And Unfolding Your Wheelchair
Folding and unfolding your wheelchair To open the chair; Take a position at one side of the wheelchair. (with rear wheels on) Take hold of the handgrip nearest to you and lean the chair toward you, so that the front castor and rear wheel on the opposite side leave the ground by 150mm (6’’) Whilst retaining a grip on the handgrip, place your hand on the seat rail nearest to you and push down, the chair will partially open. -
Page 6: Armrests And Height Adjustment
Flip back armrest Armrests are supplied in desk length (shown) or full length. To adjust armrest height; 1. lever (1), pull out to adjust height of arm pad Tear drop by lifting or lowering, once height is determined release lever and move armrest slightly up and down, the tear drop lever pin will settle in the nearest locking point. -
Page 7: Leg Rest And Adjusting
Leg rests assembly Leg rests are supplied in pairs one left one right. To install; From the side take the leg rest and insert onto the locking pins (1) located at the front of the chair, swing the leg rest to the front, the leg rest will lock into position, the footplate should be on the inside of the chair. -
Page 8: Wheel Locks
Wheel lock/Brake SIDE VIEW TOP VIEW Each chair is supplied with two wheel locks. To apply wheel locks; Whilst sitting in the chair push the brake handle (1) forward until the brake locks against the wheel tyre. To release wheel locks; Whilst sitting in the chair pull the brake handle (1) to the rear until the brake releases from the wheel tyre. -
Page 9: Castor
Castor/Upholstery Castor The castors are a sealed unit and require little or no maintenance If maintenance is required, it is recommended that a trained technician performs this task. Upholstery. With proper care your upholstery should give you years of troublefree service, It is important that you read the following. -
Page 10: Wheels And Axles
Wheels and axles Self-propelling wheels (quick release axles) 1 To remove the large rear wheels (1) it is necessary to depress the button and hold (3) on the quick release axle whilst pulling on the wheel. The wheel with the axle should part from the chair. 2 Once both wheels have been removed, the chair is now ready for transporting or storage. -
Page 11: Accessories, Seating & Backs
Accessories Available Invacare Seating Elevating legrests Cushions Stump/Amputee supports Single density cushion One piece footplates Essential cushion Angle depth adjustable footplates. Comfort mate xtra Toe loops Infinity flo gel cushion Heel loops Brake extensions Full or desk armrests Backs Wide profile castors... -
Page 12: Warranty
This warranty is extended only to the original purchaser/user of our Products. Invacare NZ Ltd warrants its product to be free from defects in materials and workmanship for a period of no less than (1) year from date of purchase except upholstered materials, padded materials and tyres/wheels. -
Page 13: Safety Summary Pages
NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall NOT be liable for bodily injury and the warranty will be voided immediately. - Page 14 After mastering the techniques of tilting the from those described in this manual. wheelchair, use this procedure to tackle kerbs, Invacare recognizes and encourages each short stairs, etc. individual to try what works best for him/her in overcoming architectural obstacles that they may METHOD 1 - WHEELCHAIR WITH STEP encounter.
- Page 15 TRANSFERRING TO AND FROM OTHER SEATS to move an occupied wheelchair up or down WARNING stairs. Invacare recommends using two (2) BEFORE attempting to transfer in or out of the assistants and making thorough preparations. wheelchair, every precaution should be taken to Make sure to use ONLY secure, non-detachable reduce the gap distance.
- Page 16 The approximate reach-limit values shown in the accompanying graph were derived on the basis of a sample of 91 male and 36 female subject wheelchair users. Note the difference between the maximum and the comfortable reach limits, a subjective but important consideration in design.
- Page 17 WARNING Keep hands and fingers clear of moving parts to avoid injury. Opening: 1. Open the wheelchair by grasping the push handle of the wheelchair closest to you. 2. Tilt the wheelchair towards you (raising the opposite wheel and castor off the ground/floor).
- Page 18 SAFETY INSPECTION CHECKLIST Note: Twice a year take your wheelchair to a qualified dealer for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any other vehicle.
- Page 19 TYRES (Page 10) 1. Inspect for flat spots and wear. If pneumatic tyres, check for proper inflation. CAUTION: As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced when necessary. REAR WHEELS (Page 10) No excessive side movement or binding when...
-
Page 20: Troubleshooting
SUGGESTED MAINTENANCE PROCEDURES Before using your Invacare wheelchair, make sure all nuts and bolts are tight. Check all parts for damage or wear and replace. Check all parts for proper adjustment. The wheels and tyres should be checked periodically for cracks and wear, and should be replaced when necessary by your authorised dealer or by a qualified technician. - Page 21 Invacare NZ Ltd P O Box 62124 Mt Wellington Auckland New Zealand...
