SECTION 1: GETTING STARTED
You will need to do the following to use your machine:
1) Remove it from the crate
2) Connect it to power and your computer (and the chiller for 50 & 100 watt)*
3) Connect the exhaust system*
4)
Configure your computer
*You may need a contractor to install the exhaust(all models) and the 208-240 volts (50
& 100 watt only). This must be done PRIOR to the arrival of the Epilog Installation
technician.
1) Cut the strapping around the box, and remove it. Some machines will have additional
boxes on top. Remove these.
2) Cut the tape on the top of the box. Open the flaps and remove as much packing foam as
you can.
3) With a friend, lift the box up over the machine. PLEASE do not throw away the box, you
may need it later. Remove the plastic bag over the machine.
4) On the pallet (the wooden platform the machine is sitting on) locate the edge that is secured
with two wing nuts. Loosen and remove the wing nuts, and remove the wooden 2"x2".
5) Under the machine (all the way under), locate the ramps. They will be wrapped in plastic.
Remove them and place the metal hooks into the slots on the pallet. These ramps will
allow you to roll the machine off the pallet. There is a left and a right ramp. The raised
edges must be on the outside, not facing each other.
6) Locate the four wooden blocks located under the machine. The machine is supported by
these blocks, and the blocks will need to be pulled out. With a friend, lift one side of the
machine just high enougn to remove two of the blocks. Do the same with the other side to
remove the remaining two blocks.
7) With a friend helping, carefully roll the machine off the pallet and down the ramps. You
may need to unlock the front casters before the machine will roll freely.
8) Open the door and cut the black plastic straps holding the cardboard accessory box to the
table. Remove the box.
9) Inside the cabinet, locate and remove eleven ½" diameter RED shipping locks. There are
two on the left side of the carriage and one on the right. There are eight holding the table
in place. Turn the screws counterclockwise to remove. Please save them.

CONNECTING POWER AND CONNECTING THE COMPUTER

1) Locate the printer cable from your accessory kit. The connection point on the Radius is on
the back panel of the machine, on the right side. The connector is recessed in a small

UNPACKING YOUR MACHINE
