Connecting an antenna or cable TV (no box) ...9 Connecting a cable TV box with a coaxial cable ...9 Connecting a cable TV box with a standard AV cable ...10 Connecting a VCR with a standard AV cable...10 Connecting a VCR with an S-Video cable...11 Connecting a component video device ...11...
Page 3
Contents Resetting all locks...19 Adjusting other functions ...19 Using the DVD player...20 Playable discs ...20 Playing a disc...20 Controlling disc playback ...20 Playing a JPEG disc...20 Selecting a subtitle language ...20 Repeating a section of a disc...21 Creating a playback loop...21 Selecting a viewing angle...21 Using a DVD main menu ...21 Using a DVD title menu...21...
• Follow all instructions supplied by the TV and wall mount manufacturers. • If you have any doubts about your ability to safely wall mount your TV, get help from a professional installer. • Make sure that the wall where you are mounting the TV is appropriate.
TV/DVD combo to its normal operation. • If your TV/DVD combo has been dropped or damaged in any way. • When your TV/DVD combo exhibits a distinct change in performance.
TV/DVD combo components Front panel and top buttons Note: The buttons are on the top of your TV/DVD combo. INPUT MENU VOL- VOL+ Component Description INPUT button Press to select the video input source. MENU button Press to open the main menu.
VCR with an S-Video cable” on page 11 or “Connecting a VCR with a standard AV cable” on page 10. Connect headphones to this jack. (headphone) 10 ANT IN Connect a TV antenna or cable TV to this jack. Remote control Button POWER INPUT...
Page 8
MUTE Press to turn off the sound. Press again to restore the sound. 10 ZOOM In TV mode, press to select the aspect ratio. For more information, see “Selecting the TV aspect ratio” on page 15. 11 DISPLAY Press to display channel information.
To use the remote control: • Point the remote control at the remote control sensor on the front of your TV. The remote control’s range is 30° to each side of the remote sensor, 15° above and below the sensor, and within 26.25 ft.
3 Turn on your TV/DVD combo and the cable TV box. 4 Press INPUT, press CH+ or CH– to select VIDEO, then press ENTER. 5 Use the cable TV box controls or the cable TV box remote control to change channels. Setting up your TV/DVD combo...
To connect a VCR with an S-Video cable: 1 Make sure that your TV/DVD combo and the VCR are turned off. 2 Connect an S-Video cable (not included) to the S-VIDEO jack on the back of your TV/DVD combo, then connect the other end of the cable to the S-VIDEO OUT jack on the VCR.
VGA jack on the computer. 4 Connect an audio cable (not included) to the PC AUDIO IN jack on the back of your TV/DVD combo, then connect the other end of the cable to the AUDIO OUT jacks on the computer.
Channel Function Lock Channel Scan When the scan is complete, your TV/DVD combo displays the first channel in the channel list. Selecting the video input source To select the video input source: 1 Press INPUT to open the Select Source menu, then press CH+ or CH–...
4 Press VOL+ or VOL– to adjust the option. Adjusting PC picture settings When you are using a PC with your TV, a special PC option becomes available that lets you optimize your TV’ s picture settings for use with the PC.
To select mono, stereo, or SAP: • Press MTS/SAP repeatedly to select Mono, Stereo, or SAP. Setting the sleep timer You can select the amount of time you want your TV/DVD combo to wait before it automatically turns off. To set the sleep timer: •...
Time Setup Lock Closed Caption Default CH+/- Function Select EXIT Back VOL+/- CH+ or CH– to select Time Setup. Time Zone Central Video Date/Time Sleep Timer Audio Channel Function Lock CH+/- Time Setup Select EXIT Back VOL+/- Using the TV...
5 Press CH+ or CH– to select the option you want to change. You can select: • Auto—Sets the correct time for your area automatically. Select On or Off. This option only works with TV channels that transmit time information. • Date—Sets the correct date.
Page 18
5 Press CH+ or CH– to select a parental option. You can select: • Parental Guide—Blocks U.S. TV programs based on ratings. For more information, see “U.S. TV program ratings” on page 18. • MPAA Rating—Blocks movies based on ratings. For more information, see “Movie ratings”...
Using the TV Movie ratings Video Audio PG-13 Channel NC-17 Function Lock Allowed Rating CH+/- MPAA Rating ENTER VOL+/- General audiences. Parental guidance suggested. Some content may not be suitable for children. PG-13 Parents strongly cautioned. Some content may not be suitable for children under 13.
• DPMS—Sets PC Power Management. If you turn this option On, your TV/DVD combo will go into standby after no signal is received from a computer for two minutes. If the computer sends a signal, your TV/DVD combo turns back on.
1 Press REPEAT. Your TV/DVD combo repeats the current chapter. 2 Press REPEAT again. Your TV/DVD combo repeats the current title. 3 Press REPEAT again. Your TV/DVD combo repeats the entire DVD. 4 Press REPEAT again to return to normal playback. Creating a playback loop Note: For discs other than DVDs, this function may work differently.
Wipe the front panel and other exterior surfaces of your TV/DVD combo with a soft cloth lightly dampened with lukewarm water. Never use a solvent or alcohol to clean your TV/DVD combo. Do not spray insecticide near your TV/DVD combo. Such chemicals may cause damage and discoloration to the exposed surfaces.
Troubleshooting Problem Solution No picture, no sound • Make sure that your TV/DVD combo is plugged into a power outlet. • Make sure that the power outlet is supplying power. Try plugging a lamp into the outlet and turning it Blank screen •...
Specifications Design and specifications are subject to change without notice. Dimensions listed in this User Guide are approximate. 19" Model NTSC, ATSC, Clear QAM Picture and sound system ≥ Audio output 3 W + 3 W AV input External input jacks PC input S-Video input PC audio input...
Products and parts replaced under this warranty become the property of Dynex and are not returned to you. If service of products and parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Dynex Product during the Warranty Period.
