EASTMAN Kodak X-Omat 270 RA Modification Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Modification Index
Mod
File Name
No.
699611.pdf
1
1c0925.pdf
2
1c0941.pdf
3
1c7063.pdf
4
ma3227_6.pdf
6
ma305829.pdf
7
ma305835.pdf
8
ma305837.pdf
9
mb305843.pdf
10/12 2
ma3227_7.pdf
11
Type
Pub No.
1 Required
699611
1 Selective
1C0925
1 Required
1C0941
1 Selective
1C7063
1 Required
5B6773
1 Selective
8B6658
1 Selective
8B7489
1 Required
9B8929
7C8299
1 Required
7C8295
Pub Date
2/93
X-Omat 180 LP Processor
3/94
X-Omat 180 LP Processor
2/94
X-Omat 180 LP Processor
6/94
X-Omat 180 LP Processor
28JUL95
X-Omat 180 LP Processor
29JUN96
X-Omat 180 LP Processor
10MAY97
X-Omat 180 LP and 180 LPS Processors
March 1997
X-Omat 180 LP and 180 LPS Processors
15MAR99
X-Omat 180 LP and 180 LPS Processors
15APR98
X-Omat 180 LP and 180 LPS Processors
Product

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kodak X-Omat 270 RA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EASTMAN Kodak X-Omat 270 RA

Summary of Contents for EASTMAN Kodak X-Omat 270 RA

  • Page 1 Modification Index File Name Type Pub No. Pub Date Product 699611.pdf 1 Required 699611 2/93 X-Omat 180 LP Processor 1c0925.pdf 1 Selective 1C0925 3/94 X-Omat 180 LP Processor 1c0941.pdf 1 Required 1C0941 2/94 X-Omat 180 LP Processor 1c7063.pdf 1 Selective 1C7063 6/94 X-Omat 180 LP Processor...
  • Page 44 See Page 3 for changes to Part Numbers Special Requirements: None Serial Numbers: See Page 3 Installation Time: 1.0 hour Special Tools: 3 CLAMPS TL-2170 Parts Status: Available at Service Parts Management, September 1995 Parts Requirements: See Page 3. HEALTH SCIENCES DIVISION © Eastman Kodak Company...

  • Page 45: Table Of Contents

    Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.

  • Page 46: Serial Numbers And Parts Information

    Serial Numbers and Parts Information Section 1: Serial Numbers and Parts Information Serial Numbers Important Check the Serial No. on the Processor and in the table below. It may not be necessary to do the whole Mod. on your Processor. Processor Action Required: Serial No.

  • Page 47: Preliminary Procedure

    MODIFICATION INSTRUCTIONS, TYPE1 Section 2: Preliminary Procedure [1] De-energize the PROCESSOR. [2] Move the main wall CIRCUIT BREAKER to “OFF”. [3] Lift the TOP COVER. [4] Remove: • DRIVE SIDE PANEL • WET SECTION COVER • EVAPORATION COVERS CONNECTOR EXIT RACK P/J-33 DRYER RACK H127_0136BCA...
  • Page 48 Preliminary Procedure WATER LINE QUICK DISCONNECT H104_0197BCA H104_0197BA [7] Disconnect the water QUICK DISCONNECT from the TANK. EVAPORATION COVERS DETECTOR CROSSOVER DEVELOPER RACK DEVELOPER/FIXER CROSSOVER FIXER RACK WASH FIXER/WASH H104_0072BCE RACK CROSSOVER H104_0072BA [8] Remove: • EXIT RACK • DEVELOPER/FIXER CROSSOVER •...

  • Page 49: Installing The Fittings And Formed Tubing

    MODIFICATION INSTRUCTIONS, TYPE1 Section 3: Installing the FITTINGS and FORMED TUBING Removing the Existing FITTINGS and FORMED TUBING Caution Developer leakage may occur when you remove the HEAT EXCHANGER and FORMED TUBING. [1] Rotate the ELECTRICAL BOX to the open position. Note: Drain this FORMED TUBING CLAMP...
  • Page 50 Installing the Fittings and FORMED Tubing HEAT EXCHANGER O-RING SEAL WASHER FITTING HOSE CLAMP B FORMED TUBING HOSE CLAMP A H127_0204HCA H127_0204HA [3] Remove and keep the other HOSE CLAMP A. [4] Remove and discard: Part Description Qty. HOSE CLAMP B FORMED TUBING FITTING WASHER...

  • Page 51: Installing The New Barbed Fittings

    MODIFICATION INSTRUCTIONS, TYPE1 Installing the New BARBED FITTINGS PROCESSOR HEAT EXCHANGER TANK 0-RING SEAL BARBED FITTING H127_0219BCA H127_0219BA [1] Place the ends of the HEAT EXCHANGER through the holes in the side of the PROCESSOR TANK. [2] Place a new O-RING SEAL on each end of the HEAT EXCHANGER. 28JUL95 –...
  • Page 52 Installing the Fittings and FORMED Tubing Important DO NOT use the existing WASHERS with the new BARBED FITTINGS. HEAT EXCHANGER NOTE: Align the ends of the HEAT EXCHANGER flush with the ends of the BARBED FITTINGS. O-RING SEAL BARBED FITTING HOSE CLAMP B FORMED TUBING H127_0206BCA...

  • Page 53: Installing The New Formed Tubing And New Hose Clamps

    MODIFICATION INSTRUCTIONS, TYPE1 Installing the New FORMED TUBING and New HOSE CLAMPS HEAT EXCHANGER HOSE CLAMP B FORMED TUBING - short HOSE CLAMP B FORMED TUBING - long Existing HOSE CLAMP A (2) H127_0207HCA H127_0207HA Qty. Part No. Description 5B6153 FORMED TUBING - short 5B6152 FORMED TUBING - long...

  • Page 54: Installing The New Springs

    Installing the New SPRINGS Section 4: Installing the New SPRINGS Installing the New SPRINGS in the CROSSOVERS [1] Remove the TROUGHS from the CROSSOVERS. TROUGH H104_0553ACA H104_0553AA [2] Remove and discard the 2 SPRINGS from the DEVELOPER/FIXER CROSSOVER and the FIXER/WASH CROSSOVER.
  • Page 55 MODIFICATION INSTRUCTIONS, TYPE1 Installing the New SPRINGS in the WASH RACK [5] Remove from both the LOWER and UPPER IDLER GEARS on the WASH RACK: 14 BEARINGS • SHOULDER SCREW • BUSHING UPPER IDLER GEAR • IDLER GEAR [6] Remove and discard the 6 SPRINGS from the LOWER IDLER WASH RACK GEAR...

  • Page 56: Installing The New Wash Tank Clip

    Installing the New WASH TANK CLIP Section 5: Installing the New WASH TANK CLIP [1] Remove and discard the existing WASH TANK CLIP. [2] Install the new WASH TANK CLIP. H127_0216GCA WASH TANK CLIP H127_0216GA 5B6773 – 28JUL95...

  • Page 57: Final Steps

    MODIFICATION INSTRUCTIONS, TYPE1 Section 6: Final Steps [1] Install: • WASH RACK • FIXER/WASH CROSSOVER • DEVELOPER/FIXER CROSSOVER • DRYER RACK [2] Connect the water QUICK DISCONNECT to the TANK. [3] Connect the YOKE to the CROSSOVERS. [4] Install: • EXIT RACK –...
  • Page 58 Final Steps MODIFICATION LABEL H127_0218ACA H127_0218AA [10] Circle 6 on the MODIFICATION LABEL. Publication Change Notice Table Affected Print Date Pub. No. ECO No. Pages File Name Notes 28JUL95 5B6773 2592-327 ma3227_6_28jul95.doc New Modification Instructions 5B6773 – 28JUL95...
  • Page 59 Kodak and X-Omat are trademarks. HEALTH SCIENCES DIVISION ma3227_6_28jul95.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
  • Page 60 29JUN96 Supersedes 04AUG95 MODIFICATION INSTRUCTIONS Kodak X-Omat MULTILOADER 300 Service Code: 3058 Modification No. 29 Kodak X-Omat 270 RA PROCESSOR Service Code: 3059 Modification No. 19 Kodak X-Omat 180 LP PROCESSOR Service Code: 3227 Modification No. 7 Type 1 Selective...
  • Page 61 Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 62 Installing the New WASH RACK Section 1: Installing the New WASH RACK [1] De-energize the PROCESSOR or MULTILOADER. [2] Move the main wall CIRCUIT BREAKER to “OFF”. [3] For the 180 LP and 270 RA PROCESSORS only: • Lift the TOP COVER. •...
  • Page 63 MODIFICATION INSTRUCTIONS, TYPE1 Removing the WASH RACK — Figure 2 [5] Disconnect: MULTILOADER 300 Shown • WATER DISCONNECT • YOKE [6] Remove the FIXER/WASH CROSSOVER from the PROCESSOR. [7] Lift the WASH RACK from the PROCESSOR. [8] Check the new RACK for squareness on a flat surface.
  • Page 64 Installing the TUBING ASSEMBLY COVER Section 2: Installing the TUBING ASSEMBLY COVER [1] See Step 13 on Page 4 to determine if Sections 2 and 3 must be done. Cutting the WET SECTION COVER Figure 3 8.6 cm (3 3/8 in. 1/8 in) WET SECTION COVER...
  • Page 65 MODIFICATION INSTRUCTIONS, TYPE1 Section 3: Installing the DOLE VALVE Important ⁄ Because the new WASH RACK requires less water flow, you need to install the new gallon/min DOLE VALVE provided in the Kit. The existing and new DOLE VALVES are not interchangeable. Do not use the existing DOLE VALVE with the new WASH RACK.
  • Page 66 Final Steps Section 4: Final Steps [1] Insert Pages 11 - 15 from these Modification Instructions into the Binder for the PROCESSOR. [2] For the 270 RA PROCESSOR only: (a) Remove the EXIT PANEL. (b) Circle the “19” on the MODIFICATION LABEL. (c) Move the main wall CIRCUIT BREAKER to “ON”.
  • Page 67 MODIFICATION INSTRUCTIONS, TYPE1 [3] For the MULTILOADER 300 only: (a) Circle the “29” on the MODIFICATION LABEL. • On MULTILOADERS Serial No. 1369 and below, see Figure 8. • On MULTILOADERS Serial No. 1370 and above, the MOD LABEL is inside the MAGAZINE DOOR.
  • Page 68 Final Steps [4] For the 180 LP PROCESSOR only: (a) Remove the DRIVE SIDE PANEL. (b) Circle the “7” on the MODIFICATION LABEL. (c) Move the main wall CIRCUIT BREAKER to “ON”. (d) Energize the PROCESSOR. (e) Check that the water flows out of the TUBING BRACKET into the center of the WATER MANIFOLD. If not, bend the TUBING BRACKET.
  • Page 69 MODIFICATION INSTRUCTIONS, TYPE1 29JUN96 – 8B6658...
  • Page 70 Illustrated Parts List for Wash Rack 5B6890 Section 5: Illustrated Parts List for Wash Rack 5B6890 H127_0217DA Item Part No. Description 5B6890 Wash Rack Assembly 5B6590 Roller Assembly 8B6568 Roller Assembly 8B6658 – 29JUN96...
  • Page 71 MODIFICATION INSTRUCTIONS, TYPE1 Wash Rack - Guide Shoe and Drive Gear H127_0212ECA H127_0212EA 29JUN96 – 8B6658...
  • Page 72 Illustrated Parts List for Wash Rack 5B6890 Item Part No. Description 1C4384 Tube - Yoke Supply 1C4385 Hose - Yoke 1C7399 Yoke and Pin Assembly 5B6594 Side Plate - Wash Rack, Non-Drive Side 5B6585 Manifold - Water 458219 Tie Rod 852807 Screw 5B6593...
  • Page 73 MODIFICATION INSTRUCTIONS, TYPE1 Wash Rack - Miscellaneous Parts H127_0213ECA H127_0213EA 29JUN96 – 8B6658...
  • Page 74 Illustrated Parts List for Wash Rack 5B6890 Item Part No. Description Notes 1C4398 Tubing Assembly 852682 Screw 539180 Star Washer 5B6892 Bracket - Tubing Item not used. 502464 1C7366 Shaft 779119 Bearing 5B6589 Spacer 183851 O-Ring 5B6591 Gear 5B6588 Shaft 5B6587 Shaft 5B6590...
  • Page 75 Kodak and X-Omat are trademarks. HEALTH IMAGING ma3058_29_29jun96.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
  • Page 76 MODIFICATION INSTRUCTIONS for the Kodak X-Omat MULTILOADER 300 Service Code: 3058 Modification No. 35 Kodak X-Omat 270 RA PROCESSOR Service Code: 3059 Modification No. 21 Kodak X-Omat 180 LP and 180 LPS PROCESSORS Service Codes: 3227, 3198 Modification No. 8...
  • Page 77 MODIFICATION INSTRUCTIONS, TYPE1 Note Some of the PROCESSORS in the serial number range will already have the plastic SPROCKETS installed. It is not necessary to install the new SPROCKETS from the Kit in these PROCESSORS. Important Use qualified service personnel to install this modification. 01MAY97 –...
  • Page 78 Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 79 MODIFICATION INSTRUCTIONS, TYPE1 Preliminary Steps [1] De-energize the PROCESSOR or MULTILOADER. [2] Move the main wall CIRCUIT BREAKER to “OFF”. [3] For the 180 LP, 180 LPS, and 270 RA PROCESSORS only: • Lift the TOP COVER. • Remove: – NONDRIVE SIDE PANEL –...
  • Page 80 Installing the New DRYER THERMISTOR and OVER-TEMPERATURE THERMOSTAT SCREW DRYER WASHERS SCREW OVER-TEMPERATURE BRACKET WASHERS THERMOSTAT DRYER DRYER OVER-TEMPERATURE BRACKET THERMISTOR THERMOSTAT BRACKET DRYER THERMISTOR H104_0414ECB H104_0414EA Note PROCESSORS can have 1 of 2 styles of BRACKETS. See the figure above that matches your PROCESSOR. [1] Remove the BRACKET(S) for the DRYER THERMISTOR and the DRYER OVER-TEMPERATURE THERMOSTAT from the PROCESSOR.
  • Page 81 MODIFICATION INSTRUCTIONS, TYPE1 [2] Remove the DRYER THERMISTOR and the DRYER OVER-TEMPERATURE THERMOSTAT from the BRACKET(S). [3] Disconnect the wires from the DRYER OVER-TEMPERATURE THERMOSTAT. Discard the THERMOSTAT. [4] Disconnect the DRYER THERMISTOR at the CONNECTOR. To free the wires, cut any TIE WRAPS necessary Discard the THERMISTOR.
  • Page 82 Connecting the New DRYER THERMISTOR [1] Prepare the wires for the new DRYER 4 cm 5 mm THERMISTOR. See Step 1 on Page 5. (1 1/2 in.) (1/4 in.) [2] Twist together each pair of wires, insert into a red wire CLOSED-END SPLICE, and close the SPLICE: •...
  • Page 83 MODIFICATION INSTRUCTIONS, TYPE1 Installing the New Plastic SPROCKETS in a 270 RA PROCESSOR or a MULTILOADER 300 SPROCKET CHAIN SPROCKET CHAIN H104_0504DCA H104_0504DA Note • Some of the PROCESSORS in the serial number range will already have the plastic SPROCKETS installed. It is not necessary to install the new SPROCKETS in these PROCESSORS.
  • Page 84 Installing the New Plastic SPROCKETS in a 180 LP or 180 LPS PROCESSOR SPROCKET CHAIN SPROCKET CHAIN H127_0223DCA H127_0223DA Note • Some of the PROCESSORS in the serial number range will already have the plastic SPROCKETS installed. It is not necessary to install the new SPROCKETS in these PROCESSORS. •...
  • Page 85 MODIFICATION INSTRUCTIONS, TYPE1 Final Steps 270 RA PROCESSORS Figure 1 [1] For the 270 RA PROCESSOR only: (a) Circle the “21” on the MODIFICATION LABEL. Use permanent ink. (b) Install the WET SECTION COVER. MODIFICATION LABEL H104_0554ACA H104_0554AA Circle the “21” on 270 RA PROCESSORS. MULTILOADERS 300 with Serial Figure 2 No.
  • Page 86 180 LP or 180 LPS PROCESSORS Figure 4 [3] For the 180 LP or 180 LPS PROCESSOR only: (a) Remove the DRIVE SIDE PANEL. MODIFICATION LABEL (b) Circle the “8” on the MODIFICATION LABEL. Use permanent ink. H127_0218ACA H127_0218AA Circle the “8” on 180 LP and 180 LPS PROCESSORS.
  • Page 87 Kodak and X-Omat are trademarks. HEALTH IMAGING ma3058_35_01may97.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
  • Page 88 February 1997 MODIFICATION INSTRUCTIONS for the Kodak X-Omat MULTILOADER 300 Modification No. 37 Kodak X-Omat 270 RA PROCESSOR Modification No. 22 Kodak X-Omat 180 LP and 180 LPS PROCESSORS Modification No. 9 Service Codes: 3058, 3059, 3227, 3198 Type 1 Required...
  • Page 89 Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 90 Modification Instructions Checking the Current Operating Software For the Kodak X-Omat 270 RA PROCESSOR and the Kodak X-Omat 270 RA PROCESSOR in a Kodak X-Omat MULTILOADER 300: 1. Check which Version of Operating Software is installed in the PROCESSOR. See the PROCESSOR or MULTILOADER 300 display, or use the PORTABLE COMPUTER.
  • Page 91 Version Kodak X-Omat 270 PROCESSOR 2.57 1C7618 Kodak X-Omat 270 RA PROCESSOR in a Kodak X-Omat MULTILOADER 300 2.57 1C7618 Kodak X-Omat 180 LP PROCESSOR - The BOOTSTRAP PROM must be Version 2.52, Part Number 5B6607 (not included with this Mod).
  • Page 92 Installing the New ROLLERS, BEARINGS, and E-RINGS FIXER/WASH CROSSOVER - Drive Side ROLLER ROLLER SHAFT SHAFT BEARING THRUST WASHER E-RING H127_0127DCB SPRING H127_0127da 9B8929 – March 1997...
  • Page 93 MODIFICATION INSTRUCTIONS, TYPE1 FIXER/WASH CROSSOVER - Non-Drive Side ROLLER ROLLER SHAFT SHAFT BEARING E-RING THRUST WASHER H127_0128DCD SPRING H127_0128DA Refer to the illustrations and install the new parts as follows: 1. Remove the FIXER/WASH CROSSOVER from the PROCESSOR 2. Remove the TROUGH, and save. 3.
  • Page 94 Updating the Parts List 1. Change the Part Numbers for the ROLLERS and the ASSEMBLY in the Parts List for the figures, and also in the Numerical and Alphabetical Lists: Description Old Part No. New Part No. Roller, Drive (black, rubber) [B] 594237 470085 Roller, Driven (phenolic)
  • Page 95 No. 1370 and Above LABEL [2] For all PROCESSORS: H118_0055ACA H118_0055AC (a) Assemble the PROCESSOR. (b) Check for correct operation of the PROCESSOR. Kodak, Ektascan, and X-Omat are trademarks. HEALTH IMAGING ma3058_37_01mar97.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
  • Page 96 30JUL98 MODIFICATION INSTRUCTIONS for the Kodak X-Omat MULTILOADER 300 Service Code: 3058 Modification No. 41/43 Kodak X-Omat 270 RA PROCESSOR Service Code: 3059 Modification No. 23/24 Kodak X-Omat 180 LP/180 LPS PROCESSORS Service Codes: 3227, 3198 Modification No. 10/12 Type 2 Purpose: To upgrade the DRYER RACK with new RACK SIDEPLATES to improve reliability.
  • Page 97 Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 98 Upgrading the DRYER RACK Note • Modification 10 may be installed already on some 180 LP / LPS PROCESSORS. It is still necessary that all of the Steps in these instructions are followed. • All of the Figures are of a 180 LP PROCESSOR. The DRYER RACK in the 270 RA PROCESSOR is similar. Save all of the parts removed except for the parts that are replaced by new parts in the KIT.
  • Page 99 MODIFICATION INSTRUCTIONS, TYPE2 [3] Remove the following from the DRYER RACK: • DRYER COVER • TOP COVER and top GUIDE SHOE, if necessary (parts not shown) • PLENUM • STOP BRACKET • CHAIN COVER (newer RACKS have a larger COVER than shown) AIR TUBES, GUIDE SHOE, and CAPTIVE BRACKETS - Drive Side View Figure 2 2 CAPTIVE...
  • Page 100 [4] Remove: • AIR TUBES • AIR TUBE SPRINGS • bottom GUIDE SHOE • 2 GUIDE SHOE BRACKETS • 2 CAPTIVE BRACKETS, if necessary SIDEPLATES, ROLLERS, and GEARS - Drive Side VIew Figure 3 14 BEARING "F" ROLLER WASHERS GEAR 6 "C"...
  • Page 101 MODIFICATION INSTRUCTIONS, TYPE2 SIDEPLATES, DRIVE CHAIN, and SPROCKETS - Drive Side View Figure 4 2 SIDEPLATES H127_0240ECA H127_0240EA 15MAR99 – 7C8299...
  • Page 102 SIDEPLATES, DRIVE CHAIN, and SQUEEGEE ROLLERS - Drive Side View Figure 5 2 SIDEPLATES CHAIN IDLER SPROCKET H127_0241ECA H127_0241EA Note “J” and “K” ROLLERS may have E-RINGS and not SCREW FASTENERS. 7C8299 – 15MAR99...
  • Page 103 MODIFICATION INSTRUCTIONS, TYPE2 [5] Remove the old SIDEPLATES. See Figures 3, 4, and 5. [6] See Figure 3. Remove and discard: • existing GEAR from the “F” ROLLER (drive side) • existing snap-in GEAR from the “E” ROLLER (drive side) •...
  • Page 104 GUIDE SHOE Figure 6 AIR TUBE bottom "C" ROLLER 2.70 mm (0.105 in.) SCREW H127_0243CCB H127_0243CA [5] See Figure 6. Loosen the SCREWS. [6] Set the distance between the “F” ROLLER and the GUIDE SHOE: (a) Place a 2.70 mm (0.105 in.) FEELER GAUGE between the “F” ROLLER and the long edge of the GUIDE SHOE.
  • Page 105 MODIFICATION INSTRUCTIONS, TYPE2 [10] Check the squareness of the DRYER RACK on a smooth, flat surface. [11] Rotate the DRIVE SHAFT on the DRYER RACK and check for interference. [12] Install the DRYER RACK in the PROCESSOR. Completing the Modification 270 RA PROCESSOR Figure 7 180 LP or 180 LPS PROCESSORS...
  • Page 106 Assembling and Checking PROCESSOR Operation [1] Assemble the PROCESSOR and check for correct operation. [2] Check for correct operation of the DRYER RACK by processing 35.0 x 43.0 cm (14.0 x 17.0 in.) films. Note If the DRYER RACK bottom GUIDE SHOE causes film scratches or stubbing, do the following adjustments: •...
  • Page 107 Kodak and X-Omat are trademarks. Health Imaging mb3058_43_15mar 99.fm EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650...
  • Page 108 • installing new software to eliminate errors caused by mis-adjusted ENTRANCE DETECTOR SWITCHES • installing new STANDOFFS on the PROCESSOR INTERFACE CONNECTOR to minimize communication errors Important Use qualified personnel to install this modification. HEALTH IMAGING © Eastman Kodak Company...
  • Page 109 Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
  • Page 110 Installing the new QUAD POWER SUPPLY Warning Dangerous Voltage [1] De-energize the PROCESSOR. Note If the PROCESSOR has a SORTER, remove the BIN ASSEMBLY. [2] Lift the TOP COVER. [3] Remove: • DRIVE SIDE PANEL • INTERFACE CABLE • NON-DRIVE SIDE PANEL •...
  • Page 111 MODIFICATION INSTRUCTIONS, TYPE1 Important All the old HEATSINK COMPOUND must be removed for correct contact. [7] Clean the old HEATSINK COMPOUND from inside the ELECTRICAL BOX. [8] Apply a thin layer of the new HEATSINK COMPOUND to the surface of the new QUAD POWER SUPPLY. Make sure the surface is covered with the COMPOUND.
  • Page 112 [12] Slide the STRAIN RELIEF forward. [13] Rotate to assemble the BODY onto the CONNECTOR. [14] Tighten the SCREWS for the STRAIN RELIEF. [15] Fasten the new WIRES to the PROCESSOR HARNESS with the TIE WRAPS provided. Removing the Old 240 V AC WIRES and CAPACITOR from the Inside of the ELECTRICAL BOX [1] Locate the following COMPONENTS inside the ELECTRICAL BOX: (See the illustration on Page 3.) •...
  • Page 113 MODIFICATION INSTRUCTIONS, TYPE1 Important The GROUND WIRES, STAR WASHERS, and NUT must be installed in the correct sequence. [4] Install on the GROUNDING STUD: • STAR WASHER • existing yellow/green WIRE • yellow/green GROUND WIRE for CONNECTOR J9 • STAR WASHER •...
  • Page 114 Completing the Modification [1] Circle “11” on the MODIFICATION LABEL. [2] Install: MODIFICATION LABEL • DRIVE SIDE PANEL • NON DRIVE SIDE PANEL • DRYER SIDE PANEL [3] Connect the INTERFACE CABLE for the PRINTER to CONNECTOR P29. [4] Close the TOP COVER. [5] Install the BIN ASSEMBLY if necessary.
  • Page 115 Kodak and X-Omat are trademarks. Health Imaging ma3227_7_15apr98.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
