Publication No. 1C7839
July 1995
DIAGNOSTICS for the
Kodak X-Omat 180 LP and 180 LPS
PROCESSORS
© E a s t m a n K o d a k C o m p a n y
H127_0010DA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kodak X-Omat 180 LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EASTMAN Kodak X-Omat 180 LP

Summary of Contents for EASTMAN Kodak X-Omat 180 LP

  • Page 1 Publication No. 1C7839 July 1995 DIAGNOSTICS for the Kodak X-Omat 180 LP and 180 LPS PROCESSORS © E a s t m a n K o d a k C o m p a n y H127_0010DA...

  • Page 2: Table Of Contents

    Eastman Kodak Company prior to publication. No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.

  • Page 3: Introduction And Definitions

    Introduction and Definitions Section 1: Introduction and Definitions Introduction • The 500 CIRCUIT BOARD monitors the operation of the Processor and continuously checks for errors. When an error occurs, an error code displays on the DISPLAY PANEL of the PRINTER. •...

  • Page 4: Error And Warning Codes

    DIAGNOSTICS Section 2: Error and Warning Codes Fatal Errors Error Error Possible Code Description Malfunction Action E001 500 Circuit Board 500 CIRCUIT BOARD Install a new 500 CIRCUIT BOARD. Corrupted software on the Download new software or install a new CIRCUIT BOARD U19.

  • Page 5: Non-Fatal Errors

    Error and Warning Codes Non-fatal Errors Error Error Possible Code Description Malfunction Action E032 Developer Tank Fill This error will occur if the DEVELOPER TANK does not fill in 4 minutes in normal operation and 15 minutes in the Tank Fill Mode. This error will occur if the DEVELOPER TANK is empty and the Tank Fill mode is not selected.
  • Page 6 DIAGNOSTICS Error Error Possible Code Description Malfunction Action E033 Fixer Tank Fill This error will occur if the FIXER TANK does not fill in 4 minutes in normal operation and 15 minutes in the Tank Fill Mode. This error will occur if the FIXER TANK is empty and the Tank Fill mode is not selected.
  • Page 7 Error and Warning Codes Error Error Possible Code Description Malfunction Action E034 Unable to Determine The DEVELOPER HEATER and DEVELOPER COOLING SOLENOID will Developer Temperature be disabled when this error exists. DEVELOPER THERMISTOR • Check that the resistance at 25˚C •...
  • Page 8 DIAGNOSTICS Error Error Possible Code Description Malfunction Action E036 Unable to Determine The DRYER HEATER will be disabled when this error occurs. Dryer Temperature • DRYER THERMISTOR is • Check that the resistance at 25˚ open or shorted. (77˚F) is approximately 10K ohms. •...
  • Page 9 Error and Warning Codes Error Error Possible Code Description Malfunction Action See E034 for additional actions. E038 Loss of Developer Cooling No water is supplied to the Check: Ability WASH TANK • SOLENOID L1 (WASH WATER INPUT) • If necessary, clean or replace the SOLENOID.
  • Page 10 DIAGNOSTICS Error Error Possible Code Description Malfunction Action E039 Loss of Fixer Heating The FIXER HEATER HR2 has an internal OVERTEMPERATURE Ability THERMOSTAT. When the HEATER is extremely hot, the OVERTEMPERATURE THERMOSTAT opens. Wait for the HEATER to cool, allowing the THERMOSTAT to reset before measuring the resistance. FIXER HEATER HR2 •...
  • Page 11 Error and Warning Codes Error Error Possible Code Description Malfunction Action E042 Loss of the Accessory CABLE connections are loose. Check: Data Link • The CABLE connections between the Printer and the Processor. E128 Processor Cover Not • COVER open •...

  • Page 12: Warnings

    DIAGNOSTICS Warnings Error Error Possible Code Description Malfunction Action W129 Tank Fill Mode None No action needed. W130 Replenisher Pumps None Using the KEYPAD, select either Automatic Disabled or Flooded Replenishment to enable the REPLENISHMENT PUMPS. W132 Developer Under Set None No action needed.

  • Page 13: Mechanical Diagnostics

    Mechanical Diagnostics Section 3: Mechanical Diagnostics Problem — Transport Malfunctions Rack and Crossover Remedies [1] Check that all RACKS and CROSSOVERS are in the correct position. [2] Check that all RACKS and CROSSOVERS are seated correctly. [3] Check for squareness of CROSSOVER and RACK ASSEMBLIES. [4] Check that all RACKS and CROSSOVERS are cleaned thoroughly.

  • Page 14: Problem - Surface Artifacts Or Abnormal Densities

    DIAGNOSTICS Problem — Surface Artifacts or Abnormal Densities Replenishment Remedies [1] Check that the replenishment rates are set for correct replenishment. Check that: • the replenishment calibration is correct • the TUBING of the REPLENISHMENT SYSTEM is straight and not pinched •...

  • Page 15: Dryer Remedies

    Mechanical Diagnostics [9] Adjust the tension on the RACK CHAIN so that the ROLLERS operate smoothly. Dryer Remedies [1] Remove any dirt from the DRYER AIR TUBES and from within the SLOTS in the DRYER AIR TUBES. Use a BOTTLE BRUSH TL-4833 to clean the AIR TUBES. Rinse the AIR TUBES with water. [2] Check the AIR TUBES are in the correct position.

  • Page 16: Problem - Wet Films

    DIAGNOSTICS Problem — Wet Films Replenishment Remedies [1] Check that the replenishment rates are set for correct replenishment. Check that: • the replenishment calibration is correct • the TUBING of the REPLENISHMENT SYSTEM is straight and not pinched • the REPLENISHMENT PUMP is operating •...

  • Page 17: Problem - Solution Levels

    Mechanical Diagnostics Problem — Solution Levels Replenishment Remedies [1] Check that the replenishment rates are set for correct replenishment. Check that: • the replenishment calibration is correct • the TUBING of the REPLENISHMENT SYSTEM is straight and not pinched • the REPLENISHMENT PUMP is operating. [2] Fill the REPLENISHER TANKS if solution levels are low.
  • Page 18 DIAGNOSTICS July 1995 – 1C7839...

  • Page 19: Publication History

    Publication History Section 4: Publication History Print Date Pub. No. ECO No. Affected Pages File Name Notes July 1995 1C7839 2619-099 All pages dg3198_1_099.doc First printing Sep 1997 1C7839 All pages dg319800.doc First CD-ROM printing. Content is identical to July 1995 version;...
  • Page 20 Kodak and X-Omat are trademarks. HEALTH SCIENCES DIVISION dg319800.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...
