Publication No. 1C7836
February 1996
Supersedes July 1995
INSTALLATION INSTRUCTIONS for the
Kodak X-Omat 180 LP and 180 LPS
PROCESSORS
© Eastma n Ko d a k Co mp a ny
H127_0010DA
