Summary of Contents for Multitone i-Page IP133
- Page 1 i-Page User Guide 9261-8880 Issue 1...
- Page 2 Compliance Information EU Territories - This product complies with the requirements of the EU Radio & Telecommunications Terminal Equipment Directive 99/5/EC. A complete copy of the associated Declaration of Conformity for this and other Multitone products found Multitone Internet address www.multitone.com.
- Page 3 Important Safety Information The Multitone i-Page IP133 Radio Paging Transcoder equipment, contains a low power (5 Watts) radio transmitter and is intended for use with either an externally mounted dipole antenna, or a “local” unity gain (or less) "desk-top" whip antenna.
- Page 4 Customer assembly guide (9261-8880); 2 metre Ethernet cable; Your i-Page may have been supplied with either Multitone, or Commtech pagers. o Your Multitone pagers are pre programmed to work with the Multitone i-Page, on the radio frequency and with the User numbers as requested in your order.
- Page 5 Configuration of i-Page i-Page must be configured with the following points in mind:- The Transcoder must not be located next to the power supply or aerial – place these items as far away from the Transcoder as possible, to ensure there is no interference.
- Page 6 The power supply can be wall mounted, using an optional mounting bracket. If the power supply is to be fitted on a wall, download the installation guide 9261-8879 from http://www.multitonei-Page.com 9261-8880 Issue 1...
- Page 7 Assembly Place the i-Page unit on a stable surface, within 3 metres of a Mains power socket and 2 metres of a network point. Insert the mains plug (power off) and the locking power connector into the power supply socket (POWER), ensuring that it is fully pushed in.
- Page 8 IP address will be saved. Open your default browser and type http://192.168.1.11 into the top bar. You will see the main screen of Multitone i-Page and can commence programming. There is no default password. Change i-Page IP address to a local network address supplied by your MIS manager.
- Page 9 Select the CLOCK menu and input time, month and day. SUBMIT to save. Paging Setup The PAGING SETUP menu must be configured for your pager type; this is found on the back of Multitone pagers. The Commtech is a POCSAG only pager. System Address – Do not change. ...
- Page 10 Passwords The web interface supports one administration password and one user password. Only one Administrator may be active at any one time and if a second administrator logs on then the first will be logged off. The Web interface can be set to display in any of the available languages.
- Page 11 Adding groups You may create up to 40 groups of pagers, each with up to 96 members. The permitted number of characters for the User and Group name is 50. Select GROUPS. Enter 4 digit Group number. Enter name / description for Group.
- Page 12 Stored Messages A maximum of 32 stored messages of 120 characters may be configured. Select MESSAGES. Enter NEW. Enter message. SUBMIT to save the message. Backup and restore The backup and restore options allow you to save system data and restore it if and when required.
- Page 13 To restore backup system data:- o BROWSE for the file to be restored and select o Select UPLOAD. Do not interrupt the download! Factory reset Proceeding with this action will delete all devices from the database and return all settings to factory values. Take a backup first, if there is any possibility that the existing data is still required.
- Page 14 Paging Users and Groups The PAGING interface allows you to:- Send free format messages to a pager. Send free format messages to a Group. Send pre-set messages to a User or Group. Select a beep code for the message. Select PAGING from the menu.
- Page 15 © Multitone Electronics plc 2011 9261-8880 Issue 1...
