ELECTRIC MODEL

UAL-

SKU #

MODEL #

50100

2EC-1.5HP

51300-50

2EC-2B/50

50800

2EC-3B

51800

2GC-5.5H

51400

2GC-11H

54800

2GC-11P

PARTS LIST MANUAL

MODELS 2EC AND 2GC

GASOLINE MODEL

ISC

ONCRETE

POWER OPTION

ELECTRIC MOTOR 1.5HP 60Hz 1-PHASE 115/230V

ELECTRIC MOTOR 2HP 50Hz 1-PHASE 110/220V

ELECTRIC MOTOR 3HP 60Hz 1-PHASE 230V

HONDA GASOLINE ENGINE MODEL GXV160

HONDA GASOLINE ENGINE MODEL GXV340

HONDA PROPANE ENGINE MODEL GXV340 115V STARTER

PROPANE MODEL

LOOR

RINDERS

E-2ECGC-PL-0711A

REVISED STARTING

SERIAL # 110710019

Printed in USA

JWA

Page 1

Table of Contents

Need help?

Do you have a question about the 2EC and is the answer not in the manual?

Questions and answers

Summary of Contents for Edco 2EC

Page 1 E-2ECGC-PL-0711A REVISED STARTING SERIAL # 110710019 PARTS LIST MANUAL MODELS 2EC AND 2GC ELECTRIC MODEL GASOLINE MODEL PROPANE MODEL UAL- ONCRETE LOOR RINDERS SKU # MODEL # POWER OPTION 50100 2EC-1.5HP ELECTRIC MOTOR 1.5HP 60Hz 1-PHASE 115/230V 51300-50 2EC-2B/50 ELECTRIC MOTOR 2HP 50Hz 1-PHASE 110/220V...
Page 2 Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,...
Page 3 E-2ECGC-PL-0711A READ AND UNDERSTAND THE OPERATORS INSTRUCTION MANUAL THOROUGHLY BEFORE ATTEMPTING TO OPERATE THIS EQUIPMENT. Death or serious injury could occur if this machine is used improperly. SAFETY • Do not disconnect power by pulling cord. To disconnect, grasp SAFETY MESSAGES the plug, not the cord.
Page 4: Table Of Contents
E-2ECGC-PL-0711A PARTS LIST MANUAL MODELS 2EC AND 2GC UAL- ONCRETE LOOR RINDERS TABLE OF CONTENTS Section Page Number Safety Messages and General Instructions ....... 2 How To Order Replacement Parts .
Page 6 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING ITEM # PART # DESCRIPTION QTY. 77022 MAIN FRAME & GEAR CASE, 2-EC/GC 77007 COVER, GEAR CASE, 2-EC/GC 10005 PLUG, HOLE 7/8” BRIGHT ZINC 10602 WASHER, FLAT 1/4 SAE ZINC 10038 WASHER, LOCK 1/4 ZINC 10018 SCREW, CAP 1/4-20 X 3/4 77008...
Page 7: Illustration 2: Skirt, Vacuum Port & Water Hook-Up Grouping
E-2ECGC-PL-0711A ILLUSTRATION 2: SKIRT, VACUUM PORT & WATER HOOK-UP GROUPING Printed in USA ©2011 Page 6...
Page 8 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 2: SKIRT, VACUUM PORT & WATER HOOK-UP GROUPING ITEM # PART # DESCRIPTION QTY. 77001 SKIRT GUARD, 2-EC/GC 10806 SCREW, CAP 5/16-18 X 1 10801 WASHER, LOCK 5/16 ZINC 10213 WASHER, FLAT 5/16 SAE ZINC 77112 PANEL, VACUUM PORT 2”, 2-EC/GC 10113...
Page 9: Illustration 3: Multi-Accessory Disc Assembly
E-2ECGC-PL-0711A ILLUSTRATION 3: MULTI-ACCESSORY DISC ASSEMBLY ITEM # PART # DESCRIPTION QTY.* 8888 DISC ASSEMBLY COMPLETE, RIGHT-HAND (ITEMS 1 THRU 8) 9999 DISC ASSEMBLY COMPLETE, LEFT-HAND (ITEMS 1 THRU 8) MULTI-ACCESSORY DISC ONLY 77088 R.H. FOR 8888 ASSEMBLY 77099 L.H. FOR 9999 ASSEMBLY 77020 RING, HUB CARRIER, 6-HOLE 10112...
Page 10: Illustration 4: Tool Box & Multi-Disc Accessories
E-2ECGC-PL-0711A ILLUSTRATION 4: TOOL BOX & MULTI-DISC ACCESSORIES ITEM # PART # DESCRIPTION QTY. 12004 TOOL BOX W/ HAMMER & PUNCH, BLACK 12005 TOOL BOX W/ HAMMER & PUNCH, RED 12001 TOOL BOX, BLACK (DYMA-SERTS™) 12002 TOOL BOX, RED (STRIP-SERTS™) 12003 HAMMER, BALL PEIN 16 OZ.
Page 11: Illustration 5: Dyma-Sert™& Pcdyma-Sert™Assemblies
E-2ECGC-PL-0711A ILLUSTRATION 5: DYMA-SERT™ & PCDYMA-SERT™ ASSEMBLIES ITEM # PART # DESCRIPTION QTY.* DYMA-SERT™ (SOLD SEPARATELY): 19110 EG-1X, 30-40 GRIT (GENERAL PURPOSE) 19130 EG-2X, 30-40 GRIT (ABRASIVE CONCRETE) 19180 EG-3X, 30-40 GRIT (EPOXY MORTARS) 19250 EG-5X, 50 GRIT (TERRAZZO) 19260 EG-7X, 80 GRIT (TERRAZZO) 19270 EG-9X, 120 GRIT (TERRAZZO)
Page 12: Illustration 6: Strip-Sert™Assembly
E-2ECGC-PL-0711A ILLUSTRATION 6: STRIP-SERT™ ASSEMBLY ITEM # PART # DESCRIPTION QTY. 12400 STRIP-SERT ASSY. WITH PRO TUNGSERT 12401 STRIP-SERT ASSY. WITHOUT PRO TUNGSERT 12404 TUNGSERT HOLDER BOX, STRIP-SERT 12405 SCREW, SKT.HD.CAP 1/2-13 X 3.5,GR.5 12403 TUNGSERT BLOCK, STRIP-SERT 12406 SPRING, COMP. .765”OD X 1.25”FL 10155 NUT, HEX NYLON LOCK 1/2-13 11573...
Page 13: Illustration 7: Optional Pad Driver Assembly
E-2ECGC-PL-0711A ILLUSTRATION 7: OPTIONAL PAD DRIVER DISC ASSEMBLY ITEM # PART # DESCRIPTION QTY.* 76040 PAD DRIVER DISC ASSEMBLY (INCLUDES ITEMS 2 THRU 5) 76042 HUB STUD, PAD DRIVER (GRINDER) 76041 DISC ONLY 11”, PAD DRIVER 10312 WASHER, FLAT 1/2 SAE ZINC 10304 SCREW, CAP 1/2-20 X 1 13013...
Page 14: Illustration 8: Optional Surfacer Disc Assembly
ILLUSTRATION 8: OPTIONAL SURFACER DISC ASSEMBLY E-2ECGC-PL-0711A ITEM # PART # DESCRIPTION QTY.* ITEM # PART # DESCRIPTION QTY.* DISC ASSEMBLY COMPLETE, R.H. 10801 WASHER, LOCK 5/16 ZINC 2222 W/ STEEL CUTTERS. 10048 SCREW, CAP 5/16-24 X 3/4 2222C W/ CARBIDE CUTTERS 1-21 77074 HOLDER, CUTTER SHAFT...
Page 16 Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,...
Page 17 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 9: MOTOR & BELT DRIVE GROUPING FOR 1.5 HP UNITS ITEM # PART # DESCRIPTION QTY. 76027 MOTOR, BALDOR 1.5HP-1P-60HZ-115/230V-1725RPM BALDOR SPEC. 36F57-385 (7/8” SHAFT) REPLACEMENT PARTS: 77039 CAPACITOR, START, BALDOR, 850-950MFD 115V 16101 RESET BUTTON, BALDOR TPCRT31CA 76002 SWITCH, TOGGLE DPDT (SCREW TERM.) 16070...
Page 18 E-2ECGC-PL-0711A ILLUSTRATION 10: MOTOR & BELT DRIVE GROUPING FOR 2HP 50Hz & 3HP 60Hz UNITS Printed in USA ©2011 Page 16...
Page 19 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 10: MOTOR & BELT DRIVE GROUPING FOR 2HP 50Hz & 3HP 60Hz UNITS ITEM # PART # DESCRIPTION QTY. 16019 MOTOR, BALDOR 2HP-1PH-50HZ-110/220V-20/10A BALDOR CAT. #L3605T-50 REPLACEMENT PARTS: CAPACITOR, START, 645-774MFD 125V 40051 16164 CAPACITOR, RUN, 40MFD 370V 16003 MOTOR, BALDOR 3HP-1PH 60HZ-230V-14A BALDOR CAT.
Page 21 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 11: ENGINE & BELT DRIVE GROUPING FOR HONDA GX160 ITEM # PART # DESCRIPTION QTY. 76020 ENGINE, HONDA GXV160UH2-N12 WITH STANDARD DUAL ELEMENT AIR CLEANER 15180 MANUAL CHOKE KIT FOR HONDA GXV160 (INCLUDES ITEMS 3 THRU 9) 15182 BRKT., CHOKE CONTROL, GXV160 15181...
Page 23 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 12: ENGINE & BELT DRIVE GROUPING FOR HONDA GX340 ITEM # PART # DESCRIPTION QTY. ENGINE 76004 HONDA GASOLINE MODEL (SHOWN) GXV340UT2-DX3 15012 HONDA PROPANE MODEL (ILLUS. 13) GXV340UT2-DP23 15190 MANUAL CHOKE KIT - GASOLINE ENGINE ONLY (INCLUDES ITEMS 3 THRU 10) 15183 LEVER, CHOKE CONTROL, GXV340...
Page 24: Illustration 13: Propane Grouping
E-2ECGC-PL-0711A ILLUSTRATION 13: PROPANE GROUPING Printed in USA ©2011 Page 22...
Page 25 E-2ECGC-PL-0711A PARTS LISTING - ILLUSTRATION 13 : PROPANE GROUPING ITEM # PART # DESCRIPTION QTY. 15012 ENGINE, HONDA PROPANE MODEL GXV340T2-DP23 (SEE ILLUS. 12) 15126 STARTER KIT, ELECTRIC 120 VOLT AC (INCLUDES POWER CORD - NOT SHOWN) 11634 SCREW, CAP M6 X 1.0P X 20MM 10038 WASHER, LOCK 1/4 ZINC 10031...
Page 26 E-2ECGC-PL-0711A ILLUSTRATION 14: OPTIONAL WEIGHT BLOCKS & TRAY ITEM # PART # DESCRIPTION QTY. 77049 WT-55 WEIGHT 55 LBS.(25 KG) 1 OR 2 77050 WT-1 WEIGHT HOLDING TRAY Printed in USA ©2011 Page 24...
Page 29: Notes
E-2ECGC-PL-0711A ILLUSTRATION 17: MOTOR WIRING DIAGRAM FOR 1.5 HP BALDOR BALDOR SPEC. NO. 36F57-385 1.5 H.P., 1 PHASE, 60 HERTZ, 1725 RPM, 115/230 VOLT, 19/9.5 FULL LOAD AMPS Printed in USA ©2011 Page 27...
Page 30 E-2ECGC-PL-0711A ILLUSTRATION 18: MOTOR WIRING DIAGRAM FOR 1.5 HP LEESON LEESON CAT. NO. 132189 1.5 H.P., 1 PHASE, 60 HERTZ, 1740 RPM, 115/230 VOLT, 20/10 FULL LOAD AMPS Printed in USA ©2011 Page 28...
Page 31 E-2ECGC-PL-0711A ILLUSTRATION 19: MOTOR WIRING DIAGRAM FOR 2 & 3 HP BALDOR BALDOR CAT. NO. L3605T-50 BALDOR CAT. NO. L3609T 2.0 H.P., 1 PHASE, 50 HERTZ, 1425 RPM, 3.0 H.P., 1 PHASE, 60 HERTZ, 1725 RPM, 110/220 VOLT, 20/10 FULL LOAD AMPS 115/230 VOLT, 28/14 FULL LOAD AMPS (230V, 14A RECOMMENDED) Printed in USA...
Page 32 Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,...
