- Page 1 CHEST FREEZER INSTRUCTION MANUAL Model No.: EACF05000W EACF07000W EACF09000W EACF14100W...
-
Page 2: Main Technical Parameters
Main Technical Parameters Model 14cf chest freezer Door color WHITE Effective volume (fridge/freezer/variable temperature chamber temperature) 14.1 (cu.ft.) Climate type Rated voltage/frequency (V/Hz) 115V/60Hz Rated current (A) 1.49 Power consumption (kw.h /24h) 0.786 Total power input of defrost (W) Fridge lamp (W) Cooling capacity (Kg/24h) Refrigerant（R600a) 100g... - Page 3 Ⅱ.Product parts lists and explosive views 14cf chest freezer NO． NAME PART CODE QUANTITY Door 890214374 GE1814.20.1 Gasket 890254358 GC1908.20-1 Hinge set 890210768 GC1811.1.2 Compressor room cover 890039294 G1008.1-1 Compressor Traverse 890056456 G1111.1.3 Fixed caster 890037860 G1002.1.3 Wheel 890037858 G1002.1.2 Hole cover 890037430 G1001.1.1.3-6...
-
Page 4: Cooling System
Cooling system 1． Schematic diagram... - Page 5 2． Cooling control rules The compressor is controlled by the thermostat to be switched on/off. The chest freezer internal temperature is detected by the temperature induced tube, based on which the compressor is controlled to be switched on/off, thus maintaining the temperature within the normal operating temperature range.
-
Page 6: Control System
Control System 1． Schematic diagram 2． Components control rules Compressor ⚫ Make sure to wait for at least 5 minutes before you energize again the compressor that gets switched off. ⚫ The compressor will get switched on when the fridge temperature rises to the turn-on temperature (T ⚫... - Page 7 3. Setting the temperature control • Your freezer has one control for regulating the temperature. The temperature control is located on the bottom of the freezer compartment. • The temperature control in the freezer will control the actual cooling cycle . The achieved temperatures can vary according to the conditions of use of the appliance, such as: place of the appliance, ambient temperature, and frequency of lid opening, extent of filling with food of the freezer.
-
Page 8: Repair Guide
3. Twist the water conduit until the arrow points downward. After defrosting is done, make sure there is no more water coming out before out the water conduit in place and make the arrow point upward. 5.Device operation rules 5.1 Compressor 5.1.1 Compressor will not be started again until five minutes after it is shut down. - Page 9 1. Replacing the thermostat, thermostat box, and indicator light, etc. Screw off the ventilating hood screws, remove the upper screws of the thermostat box cover, then remove the lower screws of the thermostat box cover, and unplug the lamp wire terminal. Press the buckle on the left side of the thermostat box using the thumb to remove the thermostat box, use the tool to push out the temperature control knob, remove the thermostat fixing nut, and replace the indicator light, thermostat, and thermostat box, etc.
-
Page 10: Changing The Door Gasket
the upper side of the hood into the hole on the cabinet shell, and finally fix the four screws of the hood. 2. Changing the door gasket Tear off the door gasket corner from one side, remove the door gasket in the desired direction, and replace it with a new one, paying attention that the side with hole should be placed at the lower side;...
