(110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 06/17/2019
Krystal Clear™
Model 634RC Filter Pump
220 - 240 V~, 50 Hz, 360 W
Hmax 5.0 m, Hmin 0.19 m, IPX4
Max. Water Temperature 35 °C
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may result
in updates to the instruction manual without notice.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong
Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué
dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading
B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
IMPORTANT
SAFETY RULES
Please read, understand, and follow all
instructions carefully before installing
and using this product. Keep for future
reference.
©2019 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/
Gedruckt in China.
110
English
English
GS
110-*GS-R0-2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Krystal Clear 634RC and is the answer not in the manual?

Questions and answers

Related Manuals for Intex Krystal Clear 634RC

Summary of Contents for Intex Krystal Clear 634RC

  • Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...

  • Page 2: Table Of Contents

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English TABLE OF CONTENTS Warnings................3 Parts List & Reference............ 4-5 Setup Instructions............6-9 Operating Instructions............ 10 Operating Time Table............11 Maintenance..............12-13 Pool Care and Chemicals..........13 Long Term Storage............

  • Page 3: Warnings

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • Always supervise children and those with disabilities. •...

  • Page 4: Parts List & Reference

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. DESCRIPTION REF.
  • Page 5 (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. INLET OUTLET NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. REF.

  • Page 6: Setup Instructions

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional) The strainer grid prevents large objects from jamming and/or damaging the filter pump. The plunger valve assembly prevents water from flowing into the filter pump while the filter cartridge is being placed or cleaned.
  • Page 7 (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional) 1. In a counter-clockwise motion unscrew plunger valve union from the inlet threaded air connector (19) (see drawing 5). Be careful not to lose the step rubber washer (11).
  • Page 8 (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English FILTER PUMP HOSE CONNECTION SETUP 1. Remove the Krystal Clear™ filter pump and hoses from the packaging. 2. Place the filter pump in such a manner, that you can easily assemble the hose (8) connections to the plunger valve.
  • Page 9 (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English FILTER PUMP INSTALLATION DISTANCE hoses Electrical device POOL >3.5 m >2m >4 m >3.5m (Generic layout of an electrical device relative to a swimming pool. Illustration not to scale.) According to the International Standard, IEC 60364-7-702, on electrical installation of swimming pools and other basins equipment, the following installation distances must be respected: •...

  • Page 10: Operating Instructions

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English OPERATING INSTRUCTIONS RCD OPERATING INSTRUCTIONS • Plug RCD into power outlet. Press RESET button on the RCD plug. Indicator should be "ON". See FIG. 10. • Press TEST button on the RCD plug. Indicator should be "OFF". See FIG. 11. •...

  • Page 11: Operating Time Table

    Pool and 80% for Easy Set & Oval Pool) Pool Size per day (Gals) (Liters) (Hours) INTEX ABOVE GROUND P OOLS (AGP’s) 18’ x 42” (549cm x 107cm) 4,786 18,115 EASY SET ® POOL 18’ x 48” (549cm x 122cm)

  • Page 12: Maintenance

    C. Screw back the sediment valve (2) in a gentle clockwise motion. Do not over-tighten. 9. Place a new cartridge filter in the housing. Only use the original Intex cartridge for replacement. See “Parts Reference” section for detail. 10. Return the housing cover (4) to its position and in a clockwise direction rescrew the housing collar (1) onto the filter housing.

  • Page 13: Pool Care And Chemicals

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English POOL CARE AND CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water.

  • Page 14: Troubleshooting Guide

    (110GS) MODEL 634RC FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/17/2019 English TROUBLESHOOTING GUIDE TROUBLE CAUSE SOLUTION • The motor is not plugged in. • Filter cord must be plugged into a 3 wire outlet FILTER MOTOR • The GFCI/RCD circuit breaker is that is protected by a Class A Ground Fault FAILS TO START tripped.

  • Page 15: Common Pool Problems

    • The drain valves are loose. • Finger tighten all caps. SEDIMENT ON • Dirt or sand on • Heavy use, getting in and • Use Intex pool vacuum to clean POOL BOTTOM pool floor. out of pool. bottom of pool.

  • Page 16: Limited Warranty

    Other than this warranty, and other legal rights in your country, no further warranties are implied. To the extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or consequential damages arising out of the use of your Krystal Clear™...
