Lincoln PowerLuber C Series Instructions

Model 1210
PowerLuber Battery Charger
Series "C"
INSTRUCTIONS FOR CHARGER AND BATTERIES
This manual contains important safety and operating instruction for Lin-
coln Model 1210 Battery Charger.
1. Before using this battery charger, read all instructions and cautionary
markings on Battery Charger, Battery Pack, and product using bat-
tery.
2. CAUTION: To reduce the risk of injury, the Lincoln Model 1210
Charger should only be used to charge Lincoln battery pack Model
1201. Other types of batteries may burst causing personal injury and
damage. Do not charge Lincoln Model 1201 Battery Packs with any
other charger.
3. Do not expose charger to moisture (rain, snow or frost).
4. Do not abuse cord. Never carry charger by cord or yank it to discon-
nect from receptacle. Pull by plug rather than cord when disconnect-
ing charger. Replace damaged or worn power cord and strain re-
liever immediately. DO NOT ATTEMPT TO REPAIR POWER CORD.
5. Make sure cord is located so that it will not be stepped on, tripped
over, or otherwise subjected to damage or stress.
6. Do not use an extension cord unless absolutely necessary. Use of im-
proper extension cord could result in a risk of fire and electric shock.
If an extension cord must be used, make sure:
A That the extension cord is properly wired and in good electrical condi-
tion.
B Wire Size of cord is at least as specified in following chart:
LENGTH OF CORD IN FEET (M) 25 (7.5) 50 (15) 100 (30) 150 (45)
AWG SIZE OF CORD (mm²)
C If an extension cord is to be used outdoors it must be marked with the
suffix W-A following the cord type
designations. For example -SJTW-A to indicate it is acceptable for
outdoor use.
7. Do not operate charger if it has received a sharp blow, been dropped,
or otherwise damaged in any way, take it to a qualified serviceman.
8. Do not disassemble charger or battery pack. Take it to a qualified
serviceman when service or repair is required. Incorrect reassembly
may result in risk of electrical shock or fire.
9. Unplug charger from outlet before attempting any maintenance or
cleaning to reduce risk of electric shock.
10. Charge the battery pack in a well ventilated place, do not cover the
charger and battery with a cloth, etc., while charging.
11. Do not store the charger or battery packs in locations
(such as a metal tool shed, or a car in the summer) where the tem-
perature may reach or exceed 122° F
(50° C) , which can lead to deterioration of the storage battery.
12. Do not charge battery pack when the temperature is BELOW 32°
F (0° C)or ABOVE 104° F (40° C). This is very important for proper
operation.
13. Do not incinerate battery pack It can explode in a fire.
14. Do not short across the terminals of the battery pack. EXTREMELY
HIGH TEMPERATURES COULD CAUSE PERSONAL INJURY OR
FIRE.
15. Charging time will be approximate 1 hour after the initial charge.
* New batteries are shipped in an uncharged state and the initial charge
will require 12 hours before use.
Americas:
One Lincoln Way
St. Louis, MO 63120-1578
USA
Phone +1.314.679.4200
Fax +1.800.424.5359
Form 404075
SAVE THESE INSTRUCTIONS
18 (1) 18 (1) 18 (1) 16 (1.5)
© Indicates change
Europe/Africa:
Heinrich-Hertz-Str 2-8
D-69183 Walldorf
Germany
Phone +49.6227.33.0
Fax +49.6227.33.259
16. When green light comes on indicating charge is complete, remove bat-
tery from charger. Do not leave battery plugged into charger for an
extended period of time after charge is complete.
17. Dispose of expended batteries properly. The Lincoln Model 1201
Battery Pack contains rechargeable, nickel-cadmium batteries. These
batteries must be recycled or disposed of properly. Drop off expend-
ed battery packs at your local replacement battery retailer, or your
recycling center.
Users in the United States NOTE:
Applicable fees for the collection and recycling of these batteries have
been paid to the RBRCTM. For further information, call 1-800-8BATTERY.
Product Specifications
Input Voltage
Output
Time to Charge
1201 Battery:
Cord Length
Weight
Indicator Lights
Red and Green Light On
When plugging in charger both the red & green light will come on for 2
seconds.
Green Light Flashes
1. Ready to charge but no battery in charger
2. Charger does not recognize the battery because it is to hot to charge.
Once battery cools to an acceptable level charge will begin
Red Light On - Battery is being charged
Green Light On - Battery is fully charged
Red and Green Lights Alternate Flashing
When battery voltage is below 9 VDC the battery will be evaluated. This
can last up to 5 minutes.
Red Light Flashes
Replace Battery pack. Unplug the charger if the red light continues to
flash after the defective battery is removed. Replace the defective bat-
tery do not attempt to charge it again.
1210 Battery
Charger
A
sia/Pacific:
No. 3 Tampines Central 1
#04-05, Abacus Plaza.
Singapore 529540
Tel +65.6588.0188
Fax +65.6588.3438
120 VAC/60 Hz
@ 375MA
14.5 Volts
@ 1.5 Amps
1 Hour Approx.
6 ft (2 m)
1 lb. (0.45 Kg)
1201
Battery
© Copyright 2010
Printed in USA
