Fame Audio MS 2002 D User Manual page 28

ENGLISH
Operating modes:
The power amplifier MS 2002 D from Fame can be used in different operating modes, which can
be set with the switch on the back of the power amplifier.
Stereo mode:
In stereo mode, both channels of the power amplifier operate independently with a separate
input signal. Two independent loudspeaker boxes are connected to the outputs.
Set the switch to "Stereo" to activate the stereo mode.
Parallel mode:
In parallel mode both channels amplify a signal, which is applied via one of the inputs. Two
independent loudspeaker boxes are connected to the outputs.
The connection of the other input channel can be used to loop the input signal through to another
daisy chaining
power amplifier, so-called . Although the input signals for both channels are now
identical, the loudspeakers can be operated individually using the respective controls of the
channels.
To activate parallel operation, set the switch to "Parallel".
