Mounting the Speakers on a Wall

Speakers
Note
Prepare screws (not supplied) that are suitable for the wall material and stability. Depending on the wall material, the wall may be
damaged.
Fasten the screws securely in the wall beam.
Hang the speakers horizontally on the reinforced wall.
Have the installation done by a Sony dealer or licensed contractor and pay special attention to safety during the installation.
Sony shall not be held responsible for accidents or damage caused by improper installation, insufficient wall stability, improper
screw installation, natural disasters, etc.
Prepare screws (not supplied) that are suitable for the wall mounting hole on the rear of the speaker.
1
(a) 4 mm (5/32 in)
(b) More than 30 mm (1 3/16 in)
Hole on the rear of the speaker
(c) 4.2 mm (11/64 in)
(d) 9.6 mm (3/8 in)
Fasten the screw in the wall.
2
