This document is designed to get you started with the HMP400W digital signage player. For more detailed
information, please refer to this SpinetiX wiki page:
Install the player's Wi-Fi antennas which are in the box with
the HMP400W player.
The HMP400W supports both HDMI 2.0 and DisplayPort 1.2. This means that you can connect your player to any display
that has an HDMI or a DisplayPort slot.
Connect via HDMI
To connect the player to your screen via HDMI, you need a display
with an HDMI connector and an HDMI cable (not included).
STEP 1:
Connect one end of the video cable to the HDMI port of your
player.
STEP 2:
Connect the other end of the HDMI cable to the HDMI port
of the display.
The player can be powered over Ethernet or by using an external USB-C power delivery unit.
Via PoE
Simply make sure to connect the Ethernet cable to a PoE port of the
switch and switch on the screen.
Via the external power delivery unit (PDU)
STEP 1:
Connect the USB-C connector to the first USB-C port of your
player - the one next to the HDMI port.
STEP 2:
Connect the PDU into a power outlet.
STEP 3:
Switch on the screen and the LAN-Switch or computer.
1. INSTALL THE PLAYER'S WI-FI ANTENNAS
2. CONNECT YOUR PLAYER TO THE SCREEN
3. CONNECT TO POWER
Get started with the HMP400W player
HOW TO
Set up your HMP400W
a
b
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpinetiX HMP400W
Summary of Contents for SpinetiX HMP400W
- Page 1 HMP400W player. 2. CONNECT YOUR PLAYER TO THE SCREEN The HMP400W supports both HDMI 2.0 and DisplayPort 1.2. This means that you can connect your player to any display that has an HDMI or a DisplayPort slot. Connect via HDMI To connect the player to your screen via HDMI, you need a display with an HDMI connector and an HDMI cable (not included).
- Page 2 STEP 5: Click the “Apply” button and wait for the player to reboot. Special note: The HMP400W can also be connected to the network via Ethernet to provide you with more options. 5. SET UP YOUR PLAYER IN SPINETIX ARYA Go to arya.spinetix.cloud/setup...
- Page 3 Wait for the player to reboot. You can now start using your HMP400W player with SpinetiX ARYA. The live chat within SpinetiX ARYA’s platform and on the SpinetiX Support Wiki is available to you almost around the clock if you need further assistance.
