Using Your Humidifier - Honeywell HWC775 Series Owner's Manual

FILLING / REFILLING
NOTE: Tank should be carried using two hands; one hand on the Tank Handle and the other supporting
the bottom of the tank.
Kaz USA, Inc. will not accept responsibility for property damage caused by water spillage.
This humidifier holds 1.5 gallons (5.6L) of water (Tank and Reservoir combined).
Filling
1
1. Remove Water Tank and turn upside down. Remove Tank Cap by turning counter clockwise (left). Fill Tank
with cool water. DO NOT fill with warm or hot water.
2. Replace Tank Cap by turning clockwise (right), aligning arrow to lock symbol. Be sure Gasket is in place.
3. Place Tank on Base. Water will drain from the Tank into the Reservoir when the Plunger is engaged.

USING YOUR HUMIDIFIER

HWC775 Manual Control
1. Power: Press Power Button
Unit defaults to cool mist, high output setting.
Press Power Button
If humidifier was programmed before turning off, previous
settings will be remembered. Unplugging the humidifier resets to
default settings.
2. Mist Temperature: Press Cool
between cool and warm mist output settings.
The Mist Output LEDs and light around the Mist Temperature
buttons will be blue when unit is in cool mist mode and orange
when in warm mist mode.
NOTE: Cool mist is immediate but please allow 5 minutes or
more for water to boil to produce warm mist. It is normal to
hear the sound of the water boiling occasionally as more water
drains into the Boiling Chamber.
3. Mist Output Level: Press the desired Mist Temperature button to
toggle through low, medium and high (1, 2 or 3 LEDs) mist output settings.
The higher the output setting, the more moisture enters the air.
The lower the output setting, the longer the run time before needing to be refilled.
4. Reset: The Reset Light has several functions. See next section for details.
2
to turn on.
again to turn off.
or Warm
3
Temperature
buttons to toggle
5
Mist Output
Level
Mist
Power
Reset
HWC775
Manual Control
