R-net LED
2.4

Battery voltage indicator

The battery voltage indicator does not show exactly how much
charge is left in the battery, but it provides a rough idea to help you
avoid unnecessary stops due to discharged batteries.
The indicator shows a more precise value about 1 minute after you
stop driving and are no longer using any power functions.
NOTICE
Voltage indicator also used as fault indicator
The battery voltage indicator also functions as a fault indicator for the
wheelchair's electronics. See for further information.
16
Joystick panel, R-net LED control panel
The display shows battery status (from
left to right):
Red, Yellow and Green Fully charged
Half charged
Red and Yellow
Charge the
Red
batteries
Figure 11. Battery voltage indicator.
