Please refer to the original service manual for:
DVD Mechanism Unit (BRS12D), Order No. PSG1408009AE
Speaker system SB-AKX38PN-K, Order No. PSG1402006CE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 4
1.3. Protection Circuitry ---------------------------------------- 4
1.5. Power Supply using SMPS ----------------------------- 6
1.6. Safety Parts Information --------------------------------- 6
2 Warning -------------------------------------------------------------- 7
2.2. Precaution of Laser Diode------------------------------- 7
(PbF)---------------------------------------------------------- 8
prevention --------------------------------------------------- 9
3 Service Navigation ----------------------------------------------10
PAGE
DVD Stereo System
SA-VKX65GA
Model No.
SA-VKX65GS
Product Color: (K)...Black Type
3.1. Service Information -------------------------------------- 10
4 Specifications ---------------------------------------------------- 11
5.2. Main Unit Key Button Operation---------------------- 13
6 Service Mode ----------------------------------------------------- 14
6.1. Service Mode Table ------------------------------------- 14
6.3. Doctor Mode Table--------------------------------------- 15
6.4. Error Code Table ----------------------------------------- 18
6.5. Self-Diagnostic Mode ----------------------------------- 19
7 Troubleshooting Guide --------------------------------------- 28
7.1. No Power or No Display-------------------------------- 28
7.2. Bluetooth® Pairing Failure----------------------------- 28
7.3. No Key Function------------------------------------------ 28
© Panasonic Corporation 2014. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
PSG1409001CE
PAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-VKX65GA and is the answer not in the manual?

Questions and answers

Sfiso Luhlanga
May 11, 2025

I want a power supply parts for vkx 65 hifi

0
1 comments:
Mr. Anderson
May 20, 2025

The available power supply parts for the Panasonic SA-VKX65GA HiFi include:

- SMPS MODULE (Switch Mode Power Supply Module)
- PW_+5VDVD (5V power supply for DVD section)

These components are part of the main power supply system for the device.

This answer is automatically generated
