Viozon 1S Pro Installation Instructions

ARM ADJUSTMENTS
TENSION ADJUSTMENT
If you feel the pitching angle too tight or too loose when
adjusting the mount, please adjust the Screw.
5MM
5MM
6MM
WEIGHT ADJUSTMENT
The load weight of mount is 3.3 to 19.8lb, factory default
settings: 6.6 to 8.8lb, it will decrease gradually when
adjusting the Screw(C) by clockwise rotation, vice versa.
Note: Once you feel the damping of
screw increases or cannot be
rotated, please stop it, avoid of
damaging the mount.
ADJUST SPRING ARM AT
VERTICAL DIRECTION
Place your hand on forearm
and push it hard downwards.
INSTALLATION HARDWARE
X 1 X 1 X 1
Base Stem Rear Arm Forearm
X 1 X 1
Laptop Plate VESA Connector
X 1 X 1
Clip Post Cap
X 6 X 6 4 / 5 / 6mm
Screws(M4) Screws(M5) Hex Wrench
WARRANTY SERVICE
Never worried when you choose viozon products
We offer the best after-sale service to our customer,
it only takes few minutes.
Just send you name and order number to
service@vio-zon.com
And then you will get complete service such as installation
guide, technical support, new product reminder, privilege of
purchasing similar products, promotions and warranty service
from Viozon.
FEEDBACK
Share it?
Let us know with a customer review.
Viozon is focusing on high-standard products, we believe
that customers' feedback drives us upgrading products.
Writing a review which sharing your experience will help
other customers. Also, your review will give us great
encouragement and confidence for future improvement. If
you have any questions, please feel free to contact us
without hesitation.
FOR HELP PLEASE CONTACT US:
Facebook: Viozon service@vio-zon.com www.vio-zon.com
Pro
Scan QR code Scan QR code below for
to get install video more products from viozon
