Viozon ZB-3 Installation Instructions

Scan QR code
get install video
CABLE MANAGEMENT
Remove cable clip (A) from the arm, thread cables, install cable
clip on the arm again.
Note: Open cable clip two sides.
A
Slide the plastic cover on the lower link upwards until it diengages,
then remove (A).Put power and monitor cables into the plastic
cover (B). Then slide the cover downwards until click into place (C).
B
A
ARM ADJUSTMENTS
TENSION ADJUSTMENT
If you feel the pitching angle is too tight or too loose when
adjusting the mount, please adjust the screws.
5MM
5MM
6MM
INSTALLATION HARDWARE
X 1 X 1 X 2
Arm (α)
Pole Arm (β)
X 2
C
Universal Ball Head
X 1 X 2
Ring Fill Light Clip
X 1 X 1
Laptop Plate Tablet Holder
X 1 X 4 X 4
Post Cap Screws (M6x18) Screw Shim
4 / 5 / 6mm X 1
Hex Wrench Microphone Holder
WARNING
X 1
Make sure to read the manual before installation and fully
Parallel Connector
understand how to install, if you have any questions, please visit
our website or contact the televant after-service.
Please use the supporting tools when installing. It is better be
installed by two people. Please be careful.
This product contains small parts, keep these away from children.
X 1
Base Plate
WARRANTY SERVICE
Never worried when you choose viozon products
We offer the best after-sale service to our customer,
it only takes few minutes.
X 1
Phone Holder
Just send you name and order number to
service@vio-zon.com
And then you will get complete service such as installation
guide, technical support, new product reminder, privilege of
X 1
purchasing similar products, promotions and warranty service
Adaptor
FEEDBACK
Share it?
Let us know with a customer review.
X 1
Extension Rod
Accessory
Viozon is focusing on high-standard products, we believe
that customers' feedback drives us upgrading products.
Writing a review which sharing your experience will help
other customers. Also, your review will give us great
encouragement and confidence for future improvement. If
you have any questions, please feel free to contact us
without hesitation.
FOR HELP PLEASE CONTACT US:
Facebook: Viozon service@vio-zon.com
X 1
Microphone Main Stand
from Viozon.
ZB-3
Installation
Instructions
www.vio-zon.com
Scan QR code
to get install video
Scan QR code below for
more products from viozon
