Page 1 User’s Guide ARMOR G5 AX6000 Multi-Gigabit Security WiFi Router Model: NBG7815 Version 1.00 Edition 2, 08/2020 Default Login Details LAN IP Address http://zyxelwifi.com http://zyxelwifi.net Copyright © 2020 Zyxel Communications Corporation...
Page 2 IMPO RT ANT ! READ C AREFUL L Y BEFO RE USE. KEEP T HIS G UIDE FO R FUT URE REFERENC E. Screenshots and graphics in this book may differ slightly from your product due to differences in your product firmware or your computer operating system.
Page 3: Do C Um E Nt C O Nve Ntio Ns
Do c um e nt C o nve ntio ns Wa rning s a nd No te s These are how warnings and notes are shown in this guide. Wa rning s te ll yo u a b o ut thing s tha t c o uld ha rm yo u o r yo ur de vic e . Note: Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations.
Page 4: Table Of Contents
Contents Overview C o nte nts O ve rvie w Use r’s G uide ............................10 Introduction ............................11 Wizard ..............................17 The Web Configurator ......................... 27 NBG7815 Modes ........................... 35 Standard Mode ............................ 37 ................................39 Bridge Mode ............................40 Tutorials ..............................
Page 5: Table Of Contents
Table of Contents T a b le o f C o nte nts Do c um e nt C o nve ntio ns ........................3 C o nte nts O ve rvie w ..........................4 T a b le o f C o nte nts ..........................5 Pa rt I: Use r’s G uide ..................
Page 6 Table of Contents 4.2 Modes .............................. 35 C ha pte r 5 Sta nda rd Mo de ..........................37 5.1 Overview ............................37 5.2 What You Can Do .......................... 37 5.3 Standard Mode Status Screen ...................... 37 ................................39 C ha pte r 6 Bridg e Mo de ............................40 6.1 Overview ............................
Page 7 Table of Contents 8.3.1 OpenVPN Server Screen ...................... 62 8.3.2 OpenVPN Account Screen ....................64 8.3.3 OpenVPN Client Screen ....................... 66 8.4 USB Application ..........................68 8.4.1 SAMBA Server Screen ......................68 8.4.2 FTP Server Screen ........................70 8.4.3 USB Media Sharing Screen ....................72 8.5 Access Your Shared Files From a Computer ................
Page 8 Table of Contents C ha pte r 11 L AN ..............................116 11.1 Overview ............................. 116 11.2 What You Can Do ........................116 11.3 What You Need To Know ......................116 11.4 LAN IP Screen ..........................117 11.4.1 Static DHCP Table-Add/Edit Rule Screen ............... 120 11.4.2 Configure LAN Screen in Bridge Mode ................
Page 9 Table of Contents Appendix B Setting Up Your Computer’s IP Address..............156 Appendix C Common Services ..................... 175 Appendix D Legal Information ...................... 178 Inde x ..............................184 NBG7815 User’s Guide...
Page 10: Use R's G Uide
A RT Use r’s G uide...
Page 11: Introduction
Intro duc tio n 1.1 O ve rvie w This chapter introduces the main features and applications of the NBG7815, also called ARMOR G5. It has four 1 Gbps Ethernet LAN ports, one 10G multi-gigabit LAN port, and one 2.5G/1G WAN port.
Page 12: Ways To Manage The Nbg7815
Chapter 1 Introduction Internet Access Application: Wired Connection Fig ure 1 • . Wireless clients can connect to the NBG7815 to access network resources. You can use WPS Wire le ss (Wi-Fi Protected Setup) to create an instant network connection with another WPS-compatible device.
Page 13: Good Habits For Managing The Nbg7815
Chapter 1 Introduction 1.4 G o o d Ha b its fo r Ma na g ing the NBG 7815 Do the following things regularly to make the NBG7815 more secure and to manage the NBG7815 more effectively. • Change the password. Use a password that’s not easy to guess and that consists of different types of characters, such as numbers and letters.
Page 14: Leds
Chapter 1 Introduction Make sure the power LED is on (not blinking). Open the Web Configurator. Click > > , and the press the WPS button. Se tting s WiFi Press the WPS button on another WPS-enabled device within range of the NBG7815. Note: You must activate WPS in the NBG7815 and in another wireless device within two minutes of each other.
Page 15: Desk Mounting
Chapter 1 Introduction Table 1 Front Panel LED (continued) C O L O R ST AT US DESC RIPT IO N Amber Blinking (Slow) The NBG7815 is upgrading firmware. Blinking (Fast) The NBG7815 is resetting. Purple Blinking WPS configuration is in process. Purple Blinking The NBG7815 is receiving power and ready for use.
Page 16 Chapter 1 Introduction Select a position free of obstructions on a wall strong enough to hold the weight of the device. Mark two holes on the wall at the appropriate distance apart for the screws. Be c a re ful to a vo id da m a g ing pipe s o r c a b le s lo c a te d inside the wa ll whe n drilling ho le s fo r the sc re ws.
Page 17: Wizard
Wiza rd 2.1 O ve rvie w In this chapter, you will learn how to: • Go through NBG7815 (ARMOR G5) wizard steps • Configure basic settings for your WiFi • Create a myZyxel Cloud account. 2.2 Ac c e ssing the Wiza rd Launch your web browser and type "http://zyxelwifi.com"...
Page 18 Chapter 2 Wizard The following screen shows if you are connected to the Internet. Click to go to the next step in the Ne xt wizard. The following screen shows if you are not connected to the Internet. Note: You may need to turn off your network firewall if access to the Internet from the NBG7815 is blocked.
Page 19 Chapter 2 Wizard Enter 1-128 single-byte printable ASCII characters but not "''<>^$& as your 2.4G / 5G WiFi Na m e WiFi . Select the check box if you want to use the same name for Pa sswo rd Ke e p 2.4G & 5G na m e the sa m e your 2.4G and 5G WiFi.
Page 20 Chapter 2 Wizard Wait a moment for your WiFi settings to be applied to your NBG7815. The following screen shows if you have set up your WiFi name and password successfully. Click Ne xt go to the next step in the wizard. NBG7815 User’s Guide...
Page 21 Chapter 2 Wizard Wait a moment for the NBG7815 to check if your device is updated with the latest firmware. If not, your NBG7815 will automatically update the firmware. NBG7815 User’s Guide...
Page 22 Chapter 2 Wizard You need to create a myZyxel Cloud account to log into the NBG7815. Click to go to the next step Ne xt in the wizard. A pop up message shows. Click to be redirected to the registration website of myZyxel Cloud. NBG7815 User’s Guide...
Page 23 Chapter 2 Wizard Enter your if you already have a myZyxel Cloud account. If not, you can create one Em a il Pa sswo rd by clicking . You can also click the Facbook or Google icon to create an account with your Sig n Up Facebook or Google account.
Page 24 Chapter 2 Wizard 10 The legal page shows after you log in. Select the check box I unde rsta nd a nd a g re e the Zyxe l C lo ud and then click T e rm s o f Use C o nfirm NBG7815 User’s Guide...
Page 25 Chapter 2 Wizard 11 The following page asks for your authorization to use your account. Click to finish registering Autho rize your myZyxel Cloud account. You will be directed back to the NBG7815 web configurator. 12 Wait a moment for your NBG7815 to link to your myZyxel Cloud account. NBG7815 User’s Guide...
Page 26 Chapter 2 Wizard 13 You can create a local password to access the NBG7815 directly. You can choose to log in with your myZyxel Cloud account or your local password the next time you log in. Note: You can change your local password in >...
Page 27: The Web Configurator
HA PTER T he We b C o nfig ura to r 3.1 O ve rvie w This chapter describes how to access the NBG7815 Web Configurator and provides an overview of its screens. The Web Configurator is an HTML-based management interface that allows easy system setup and management via Internet browser.
Page 28 Chapter 3 The Web Configurator The NBG7815 screen displays allowing you to monitor your NBG7815. It shows if the NBG7815 is O ve rvie w online, and how many wireless clients are currently connected to your device, as well as their upstream/ downstream data rates.
Page 29 Chapter 3 The Web Configurator Overview (Standard Mode) Fig ure 8 NBG7815 User’s Guide...
Page 30: Navigation Panel
Chapter 3 The Web Configurator Overview (Bridge Mode) Fig ure 9 3.3 Na vig a tio n Pa ne l Use the submenus on the navigation panel to configure NBG7815 features. Your navigation panel varies depending on the mode of your NBG7815. Chapter 5 on page 37 for more information on Standard Mode.
Page 31: Standard Mode Navigation Panel
Chapter 3 The Web Configurator 3.3.1 Sta nda rd Mo de Na vig a tio n Pa ne l Navigation Panel (Standard Mode) Fig ure 10 The following table describes the submenus. Table 3 Settings > System > Status (Standard Mode) L INK T AB FUNC T IO N...
Page 32 Chapter 3 The Web Configurator Table 3 Settings > System > Status (Standard Mode) (continued) L INK T AB FUNC T IO N OpenVPN Client Use this screen to: • View basic information about OpenVPN Server accounts that you are connected to •...
Page 33: Bridge Mode Navigation Panel
Chapter 3 The Web Configurator Table 3 Settings > System > Status (Standard Mode) (continued) L INK T AB FUNC T IO N System Status Use this screen to view the basic information of the NBG7815 General Use this screen to change password or to set the timeout period of the Setting management session.
Page 34 Chapter 3 The Web Configurator Table 4 Settings > System > Status (Bridge Mode) (continued) L INK T AB FUNC T IO N USB Application SAMBA Use this screen • Set up file-sharing via the NBG7815 using Windows Explorer or the workgroup name •...
Page 35: Nbg7815 Modes
Chapter 4 NBG7815 Modes HA PTER NBG 7815 Mo de s 4.1 O ve rvie w This chapter introduces the different operating modes available on your NBG7815. Or simply how the NBG7815 is being used in the network. 4.2 Mo de s This refers to the operating mode of the NBG7815, which can act in: •...
Page 36 Chapter 4 NBG7815 Modes Bridge Mode Example Fig ure 13 For more information on changing the mode of your NBG7815, refer to Section 13.7 on page 140. Note: Choose your device mode carefully to avoid having to change it later. When changing to another mode, the IP address of the NBG7815 changes.
Page 37: Standard Mode
Chapter 5 Standard Mode HA PTER Sta nda rd Mo de 5.1 O ve rvie w The NBG7815 is set to standard (router) mode by default. Routers are used to connect the local network to another network (for example, the Internet). In the figure below, the NBG7815 connects the local network ( ) to the Internet.
Page 38 Chapter 5 Standard Mode Settings > System > Status (Standard Mode) Fig ure 15 The following table describes the labels shown in the screen. Sta tus Table 5 Settings > System > Status (Standard Mode) L ABEL DESC RIPT IO N System Model Name This is the model name of your device.
Page 39 Chapter 5 Table 5 Settings > System > Status (Standard Mode) (continued) L ABEL DESC RIPT IO N IP Address This shows the WAN port’s IP address. IP Subnet Mask This shows the WAN port’s subnet mask. Gateway This shows the WAN port’s gateway IP address. IPv6 Address This shows the current IPv6 address of the NBG7815.
Page 40: Bridge Mode
Chapter 6 Bridge Mode HA PTER Bridg e Mo de 6.1 O ve rvie w Use your NBG7815 as a bridge if you already have a router or gateway on your network. In this mode your NBG7815 bridges a wired network (LAN) and wireless LAN (WLAN) in the same subnet. See the figure below for an example.
Page 41: Accessing The Web Configurator In Bridge Mode
Chapter 6 Bridge Mode To use your NBG7815 as a bridge, go to and select Se tting s > Syste m > O pe ra ting Mo de Bridg e Mo de Changing to Bridge mode Fig ure 17 Note: You have to log in to the Web Configurator again when you change modes. As soon as you do, your NBG7815 is already in Bridge mode.
Page 42: Bridge Mode Status Screen
Chapter 6 Bridge Mode 6.4 Bridg e Mo de Sta tus Sc re e n Click > > to open the status screen. Se tting s Syste m Sta tus Settings > System > Status (Bridge Mode) Fig ure 19 The following table describes the labels shown in the screen.
Page 43: Tutorials
HA PTER T uto ria ls 7.1 O ve rvie w This chapter provides tutorials for setting up your NBG7815. • Run a Speed Test • Configure the NBG7815’s WiFi Networks • Enable or Disable a WiFi Network • Add Clients to a Profile •...
Page 44: Configure The Nbg7815'S Wifi Networks
Chapter 7 Tutorials Click the tab to view a summary of the tests made. Click to delete all records. Spe e d T e st Histo ry C le a r 7.3 C o nfig ure the NBG 7815’s WiFi Ne two rks In the NBG7815 you can configure independent wireless networks with different privileges.
Page 45 Chapter 7 Tutorials Select to activate a WiFi Network. Enter the clients use to connect Ena b le 2.4G / 5G Na m e Pa sswo rd to the WiFi network. You can configure two different WiFi Names for the 2.4G and 5G networks.
Page 46 Chapter 7 Tutorials NBG7815 User’s Guide...
Page 47: Enable Or Disable A Wifi Network
Chapter 7 Tutorials 7.4 Ena b le o r Disa b le a WiFi Ne two rk After the NBG7815 is set up, you can use separate WiFi networks for your clients. The WiFi settings will be applied to all clients in the same network. Note: This is not available if you are using bridge mode.
Page 48: Add Clients To A Profile
Chapter 7 Tutorials 7.5 Add C lie nts to a Pro file Profiling clients allows you to easily block/allow Internet access or set a schedule for all client devices in the same profile. Note: This is not available if you are using bridge mode. Click the icon on the top-left corner ( ), and click...
Page 49: Set A Profile's Wifi Schedule
Chapter 7 Tutorials 7.6 Se t a Pro file ’s WiFi Sc he dule When you create or edit a profile, you can schedule the NBG7815 to automatically disable or enable WiFi access during a certain period of time for clients in that profile. Note: This is not available if you are using bridge mode.
Page 50 Chapter 7 Tutorials Click the start time cell and drag down to the end time to set up your schedule. NBG7815 User’s Guide...
Page 51: Pause Or Resume Internet Access On A Profile
Chapter 7 Tutorials 7.7 Pa use o r Re sum e Inte rne t Ac c e ss o n a Pro file You may want to manually block a profile of client devices from accessing the Internet immediately and resume it later. Note: This is not available if you are using bridge mode.
Page 52: Change Your Nbg7815 Operating Mode
Chapter 7 Tutorials 7.9 C ha ng e Yo ur NBG 7815 O pe ra ting Mo de The operating mode refers to how the NBG7815 is being used in the network. The NBG7815 has two operating modes: • This is the NBG7815’s default mode. In this mode, the NBG7815 routes traffic between a Sta nda rd: local network and another network such as the Internet.
Page 53: Configure A Port Forwarding Rule
Chapter 7 Tutorials 7.10 C o nfig ure a Po rt Fo rwa rding Rule If you want to forward incoming packets to a specific or appropriate IP address in the private network using ports, set a port forwarding rule. Note: This is not available if you are using bridge mode.
Page 54 Chapter 7 Tutorials Select in the field. Ena b le Ena b le Po rt Fo rwa rding Click to create a port forwarding rule. Add a service name, a port number or a range of ports Add Rule to define the service to be forwarded, specify the transport layer protocol used for the service, and the IP address of a device on your local network that will receive the packets from the port(s).
Page 55 Chapter 7 Tutorials NBG7815 User’s Guide...
Page 56: T E C Hnic A L Re Fe Re Nc E
A RT T e c hnic a l Re fe re nc e...
Page 57: Applications
HA PTER Applic a tio ns 8.1 O ve rvie w This chapter shows you how to configure parental control, OpenVPN, USB media sharing and file sharing. 8.1.1 Wha t Yo u C a n Do • Use the screens to enable parental control, configure the parental control rules and Pa re nta l C o ntro l schedules, and send e-mail notifications.
Page 58: Before You Begin
Chapter 8 Applications protocol is supported on Microsoft Windows, Linux Samba and other operating systems (refer to your systems specifications for CIFS compatibility). Sa m b a SMB is a client-server protocol used by Microsoft Windows systems for sharing files, printers, and so on. Samba is a free SMB server that runs on most Unix and Unix-like systems.
Page 59 Chapter 8 Applications Parental Control > Device Fig ure 20 The following table describes the fields in this screen. Table 8 Parental Control L ABEL DESC RIPT IO N Sort By Choose to sort the order of your devices by T ype Na m e Connect to...
Page 60 Chapter 8 Applications Edit Device Detail Fig ure 21 Table 9 Edit Device Detail L ABEL DESC RIPT IO N Device Name Enter a name for the device to which this rule applies. Type Choose the type of device to which this rule applies. Apply Click to save your settings back to the NBG7815.
Page 61 Chapter 8 Applications Add New Profile Fig ure 22 The following table describes the fields in this screen. Table 10 Add New Profile L ABEL DESC RIPT IO N Profile Name Enter a name for this rule. Select All Click then deselect the blocks you don’t want or click on blocks Se le c t All separately to specify days and times to turn the Wireless LAN on or off.
Page 62: Openvpn Server/Client
Chapter 8 Applications 8.2.1.3 Pro file Sc re e n Use this screen to edit or delete an existing rule. Click > to show the following Pa re nta l C o ntro l Pro file screen. Parental Control > Profile Fig ure 23 The following table describes the fields in this screen.
Page 63 Chapter 8 Applications Example of NBG7815 Acting As VPN Server Fig ure 24 Note: You have to enable DDNS in > > screen before you can Se tting s Inte rne t Dyna m ic DNS create an OpenVPN account. See Section 9.8 on page 96 for more information on Dynamic DNS.
Page 64: Openvpn Account Screen
Chapter 8 Applications Table 12 OpenVPN Server L ABEL DESC RIPT IO N Server Port The default server port number is 1194. You can change it if needed. However, clients connected to this OpenVPN Server account will have to use the same port number in order to access the server account.
Page 65 Chapter 8 Applications The following table describes the fields in this screen. Table 13 OpenVPN Account L ABEL DESC RIPT IO N OpenVPN Account List This is the rule index number. Username This field displays a name to identify this rule. Password This field displays a combination of characters and numbers clients need to connect to an account.
Page 66: Openvpn Client Screen
Chapter 8 Applications Table 14 OpenVPN Account List-Add Rule L ABEL DESC RIPT IO N Apply Click to save your changes back to the NBG7815. Apply Cancel Click to exist this screen without saving. C a nc e l 8.3.3 O pe nVPN C lie nt Sc re e n Use the in this screen to view the basic information of the OpenVPN Server O pe nVPN Se rve r L ist...
Page 67 Chapter 8 Applications Table 15 OpenVPN Client L ABEL DESC RIPT IO N Active Slide the switch to the right ( ) to activate your connection to an OpenVPN Server account. Actions Click the icons under to delete or edit an existing OpenVPN Server account Ac tio ns settings.
Page 68: Usb Application
Chapter 8 Applications Table 16 OpenVPN Server List-Add Rule L ABEL DESC RIPT IO N Apply Click to save your changes back to the NBG7815. Apply Cancel Click to exist this screen without saving. C a nc e l 8.4 USB Applic a tio n 8.4.1 SAMBA Se rve r Sc re e n Use this screen to set up file-sharing via the NBG7815 using Windows Explorer or the workgroup name.
Page 69 Chapter 8 Applications Table 17 USB Application > SAMBA (continued) L ABEL DESC RIPT IO N Work Group You can add the NBG7815 to an existing or a new workgroup on your network. Enter the name of the workgroup which your NBG7815 automatically joins. You can set the NBG7815’s workgroup name to be exactly the same as the workgroup name to which your computer belongs to.
Page 70: Ftp Server Screen
Chapter 8 Applications USB Application > SAMBA > Add Rule Fig ure 32 The following table describes the labels in this screen. Table 18 USB Application > SAMBA > Add Rule L ABEL DESC RIPT IO N Status Select to enable the account. Ena b le Select to disable the account.
Page 71 Chapter 8 Applications USB Application > FTP Fig ure 33 The following table describes the labels in this screen. Table 19 Expert Mode > Applications > File Sharing > FTP L ABEL DESC RIPT IO N Enable FTP Select this to enable the FTP server on the NBG7815 for file sharing using FTP. Port You may change the server port number for FTP if needed, however you must use the same port number in order to use that service for file sharing.
Page 72: Usb Media Sharing Screen
Chapter 8 Applications USB Application > FTP > Add Rule Fig ure 34 The following table describes the labels in this screen. Table 20 USB Application > FTP > Add Rule L ABEL DESC RIPT IO N Status Select to enable the account. Ena b le Select to disable the account.
Page 73 Chapter 8 Applications The media server feature lets anyone on your network play video, music, and photos from the USB storage device connected to your NBG7815 without having to copy them to another computer. The NBG7815 can function as a DLNA-compliant media server, where the NBG7815 streams files to DLNA- compliant media clients like Windows Media Player.
Page 74: Access Your Shared Files From A Computer
Chapter 8 Applications The following table describes the labels in this screen. Table 21 USB Application > USB Media Sharing L ABEL DESC RIPT IO N USB Media Sharing Media Server Choose to have the NBG7815 function as a DLNA-compliant media server. Ena b le (DLNA) Setup Otherwise, choose...
Page 75: Using Ftp Program
Chapter 8 Applications Once you access via your NBG7815, you do not have to relogin unless you restart your computer. usb 1 8.5.2 Using FT P Pro g ra m Here is how to use an FTP program to access a file storage device connected to the NBG7815’s USB port.
Page 76 Chapter 8 Applications You can click the icon to edit or delete the rules. Edit De le te FTP Setup Fig ure 38 Open FileZilla, enter the IP address of the NBG7815 (the default IP address is 192.168.123.1), the Ho st , and the number 21, and then click .
Page 77 Chapter 8 Applications Once you log in the USB device displays in the folder. usb 1 NBG7815 User’s Guide...
Page 78: Wan
HA PTER 9.1 O ve rvie w This chapter discusses the NBG7815’s screens. Use these screens to configure your NBG7815 for Internet access. A WAN (Wide Area Network) connection is an outside connection to another network or the Internet. It connects your private networks such as a LAN (Local Area Network) and other networks, so that a computer in one location can communicate with computers in other locations.
Page 79: What You Need To Know
Chapter 9 WAN 9.3 Wha t Yo u Ne e d T o Kno w The information in this section can help you configure the screens for your WAN connection, as well as enable/disable some advanced features of your NBG7815. 9.3.1 C o nfig uring Yo ur Inte rne t C o nne c tio n Enc a psula tio n Me tho d Encapsulation is used to include data from an upper layer protocol into a lower layer protocol.
Page 80: Internet Connection Screen
Chapter 9 WAN Auto - IP C ha ng e When the NBG7815 gets a WAN IP address or a DNS server IP address which is in the same subnet as the LAN IP address 192.168.123.1, Auto-IP-Change allows the NBG7815 to change its LAN IP address to 10.0.0.1 automatically.
Page 81 Chapter 9 WAN Settings > Internet > Internet Connection: IPoE (IPv4 Only) Fig ure 42 The following table describes the labels in this screen. Table 22 Network > WAN > Internet Connection: IPoE Encapsulation L ABEL DESC RIPT IO N Internet Connection Internet Service You must choose the...
Page 82 Chapter 9 WAN Table 22 Network > WAN > Internet Connection: IPoE Encapsulation (continued) L ABEL DESC RIPT IO N Static IP Select this option If the ISP assigned a fixed IP address. IP Address Enter your WAN IP address in this field if you selected Sta tic IP Addre ss IP Subnet Mask Enter the...
Page 83: Pppoe Encapsulation
Chapter 9 WAN Table 22 Network > WAN > Internet Connection: IPoE Encapsulation (continued) L ABEL DESC RIPT IO N First DNS Server Select and enter the IPv6 DNS server address assigned by the ISP to have the Use r- De fine d NBG7815 use the IPv6 DNS server addresses you configure manually.
Page 84 Chapter 9 WAN This screen displays when you select encapsulation. PPPo E Settings > Internet > Internet Connection: PPPoE (IPv4 Only) Fig ure 43 The following table describes the labels in this screen. Table 23 Network > WAN > Internet Connection: PPPoE Encapsulation L ABEL DESC RIPT IO N Internet Connection...
Page 85 Chapter 9 WAN Table 23 Network > WAN > Internet Connection: PPPoE Encapsulation (continued) L ABEL DESC RIPT IO N IPv4 / IPv6 Select if you want the NBG7815 to run IPv4 only. IPv4 O nly Select to allow the NBG7815 to run IPv4 and IPv6 at the same time. Dua l Sta c k PPPoE Username Type the user name given to you by your ISP.
Page 86: Pptp Encapsulation
Chapter 9 WAN Table 23 Network > WAN > Internet Connection: PPPoE Encapsulation (continued) L ABEL DESC RIPT IO N LAN & WAN Subnet Conflict Automatically Select this option to have the NBG7815 change its LAN IP address to 10.0.0.1 or 192.168.123.1 change the LAN IP accordingly when the NBG7815 gets a dynamic WAN IP address in the same subnet as the LAN IP address.
Page 87 Chapter 9 WAN Settings > Internet > Internet Connection: PPTP (IPv4 Only) Fig ure 44 The following table describes the labels in this screen. Table 24 Network > WAN > Internet Connection: PPTP Encapsulation L ABEL DESC RIPT IO N Internet Connection Internet Service Select...
Page 88 Chapter 9 WAN Table 24 Network > WAN > Internet Connection: PPTP Encapsulation (continued) L ABEL DESC RIPT IO N PPTP Encryption Type Use the drop-down list box to select the type of Microsoft Point-to-Point Encryption (MPPE). Options are: - This ISP account adjusts the encryption type automatically. Auto - This ISP account does not use MPPE.
Page 89: Nat & Port Forwarding Screen
Chapter 9 WAN 9.5 NAT & Po rt Fo rwa rding Sc re e n Use Port Forwarding to forward incoming service requests from the Internet to the server(s) on your local network. Port forwarding is commonly used when you want to host online gaming, P2P file sharing, or other servers on your network.
Page 90 Chapter 9 WAN Use this screen to enable NAT, set a default server and view the summary table of your NBG7815’s port forwarding settings. Click > > to show the following screen. Se tting s Inte rne t NAT & Po rt Fo rwa rding Settings >...
Page 91: Add Port Forwarding Rule Screen
Chapter 9 WAN Table 25 Expert Mode > WAN > NAT > General (continued) L ABEL DESC RIPT IO N Server IP Address This field displays the internal IP address of the server. Internal Port This is the port number used to connect to this service using the server's internal IP address on the LAN.
Page 92: Passthrough Screen
Chapter 9 WAN The following table describes the labels in this screen. Table 26 Add Port Forwarding Rule L ABEL DESC RIPT IO N Service Name Select a pre-defined service from the drop-down list box. The pre-defined service port number(s) and protocol will be displayed in the port forwarding summary table. Otherwise, select to manually enter the port number/range and select Use r- De fine...
Page 93 Chapter 9 WAN Settings > Internet > Passthrough Fig ure 48 The following table describes the labels in this screen. Table 27 Settings > Internet > Passthrough L ABEL DESC RIPT IO N ALG Setup Select to allow TCP packets with a specified port destination to pass through. Ena b le H.323 Select...
Page 94: Port Trigger Screen
Chapter 9 WAN Table 27 Settings > Internet > Passthrough (continued) L ABEL DESC RIPT IO N IPSEC Select to allow VPN clients to make outbound IPSec connections. It is required in Ena b le order to connect to a IPSec VPN account. If is disabled, then when a client sends a IPSEC request to a VPN server, the server will reply to the NBG7815 and the NBG7815 will drop the...
Page 95: Add Port Trigger Rule Screen
Chapter 9 WAN Jane requests a file from the Real Audio server (port 7070). Port 7070 is a “trigger” port and causes the Zyxel Device to record Jane’s computer IP address. The Zyxel Device associates Jane's computer IP address with the "open" port range of 6970-7170. The Real Audio server responds using a port number ranging between 6970-7170.
Page 96: Dynamic Dns Screen
Chapter 9 WAN Add Port Trigger Rule Fig ure 51 Table 29 Add Port Trigger Rule L ABEL DESC RIPT IO N Name Type a unique name (up to 15 characters) for identification purposes. All characters are permitted - including spaces. Incoming Port Incoming is a port (or a range of ports) that a server on the WAN uses when it sends out a particular service.
Page 97: Upnp Screen
Chapter 9 WAN Settings> Internet > Dynamic DNS Fig ure 52 The following table describes the labels in this screen. Table 30 Settings > Internet > Dynamic DNS L ABEL DESC RIPT IO N Dynamic DNS Setup Dynamic DNS Select to use dynamic DNS.
Page 98: Turning On Upnp In Windows 7 Example
Chapter 9 WAN Use this screen to enable UPnP on your NBG7815. Click > > to display the following Se tting s Inte rne t UPnP screen. Settings > Internet > UPnP Fig ure 53 Table 31 Settings > Internet > UPnP L ABEL DESC RIPT IO N UPnP Setup...
Page 99 Chapter 9 WAN Click C ha ng e Adva nc e d Sha ring Se tting s NBG7815 User’s Guide...
Page 100 Chapter 9 WAN Select and click . Network discovery allows your computer to T urn o n ne two rk disc o ve ry Sa ve C ha ng e s find other computers and devices on the network and other computers on the network to find your computer.
Page 101: Turning On Upnp In Windows 10 Example
Chapter 9 WAN 9.9.2 T urning o n UPnP in Windo ws 10 Exa m ple This section shows you how to use the UPnP feature in Windows 10. UPnP server is installed in Windows 10. Activate UPnP on the NBG7815 in >...
Page 102 Chapter 9 WAN Click Ne two rk a nd Sha ring C e nte r Click C ha ng e a dva nc e d sha ring se tting s NBG7815 User’s Guide...
Page 103 Chapter 9 WAN Under , select and click . Network discovery allows your Do m a in T urn o n ne two rk disc o ve ry Sa ve C ha ng e s computer to find other computers and devices on the network and other computers on the network to find your computer.
Page 104: Wireless Lan
HA PTER Wire le ss L AN 10.1 O ve rvie w This chapter discusses how to configure the wireless network settings in your NBG7815. The NBG7815 can service both 2.4GHz and 5GHz networks at the same time. You can have different wireless setup and settings for 2.4GHz and 5GHz wireless LANs.
Page 105: What You Should Know
Chapter 10 Wireless LAN • Use the screen to quickly set up a wireless network with strong security without having to configure security settings manually (Section 10.5 on page 113). • Use the screen to set the times your wireless LAN is turned on and off (Section 10.6 on Sc he duling page...
Page 106 Chapter 10 Wireless LAN Use r Authe ntic a tio n You can make every user log in to the wireless network before they can use it. This is called user authentication. However, every wireless client in the wireless network has to support IEEE 802.1x to do this.
Page 107 Chapter 10 Wireless LAN Guest Wireless LAN Network Fig ure 55 G ue st WL AN Ba ndwidth The Guest WLAN Bandwidth function allows you to restrict the maximum bandwidth for the guest wireless network. Additionally, you can also define bandwidth for your home or office network. An example is shown in the next figure to define maximum bandwidth for your networks ( is Guest WLAN is a home or company network.)
Page 108: Main Wifi Screen
Chapter 10 Wireless LAN 10.2 Ma in WiFi Sc re e n Use this screen to configure the SSID and wireless security of the NBG7815’s default wireless LAN. Note: If you are configuring the NBG7815 from a computer connected to the wireless LAN and you change the NBG7815’s SSID, channel or security settings, you will lose your wireless connection when you press to confirm.
Page 109 Chapter 10 Wireless LAN Settings > WiFi > Main WiFi Fig ure 57 NBG7815 User’s Guide...
Page 110 Chapter 10 Wireless LAN The following table describes the labels in this screen. Table 32 Settings > WiFi > Main WiFi L ABEL DESC RIPT IO N Main WiFi Enable Main WiFi Select to activate the 2.4GHz and/or 5GHz wireless LAN. Select to turn it off.
Page 111: Guest Wifi Screen
Chapter 10 Wireless LAN Table 32 Settings > WiFi > Main WiFi L ABEL DESC RIPT IO N Apply Click to save your changes back to the NBG7815. Apply Cancel Click to reload the previous configuration for this screen. C a nc e l 10.3 G ue st WiFi Sc re e n This screen allows you to enable and configure guest wireless network settings on the NBG7815.
Page 112: Mac Filter Screen
Chapter 10 Wireless LAN 10.4 MAC Filte r Sc re e n The MAC filter screen allows you to give exclusive access to devices ( ) or exclude devices from Allo w accessing the NBG7815 ( ). Every Ethernet device has a unique MAC (Media Access Control) De ny address.
Page 113: Add Mac Address Screen
Chapter 10 Wireless LAN 10.4.1 Add MAC Addre ss Sc re e n Use this screen to configure the MAC address you want to add to the MAC address list. Click > Se tting s > > to show the following screen. WiFi MAC Filte r Settings >...
Page 114 Chapter 10 Wireless LAN Settings > WiFi > WPS Fig ure 61 The following table describes the labels in this screen. Table 36 Settings > WiFi > WPS L ABEL DESC RIPT IO N WiFi WPS Status Select to turn on the WPS feature. Otherwise, select Ena b le Disa b le Push Button...
Page 115: Scheduling Screen
Chapter 10 Wireless LAN 10.6 Sc he duling Sc re e n Use this screen to set the times your wireless LAN is turned on and off. Wireless LAN scheduling is disabled by default. The wireless LAN can be scheduled to turn on or off on certain days and at certain times. The y-axis shows the time period in days.
Page 116: Lan
HA PTER L AN 11.1 O ve rvie w This chapter describes how to configure LAN settings. A Local Area Network (LAN) is a shared communication system to which many computers are connected. A LAN is a computer network limited to the immediate area, usually the same building or floor of a building.
Page 117: Lan Ip Screen
Chapter 11 LAN LAN and WAN IP Addresses Fig ure 64 The LAN parameters of the NBG7815 are preset in the factory with the following values: • IPv4 address of 192.168.123.1 with subnet mask of 255.255.255.0 (24 bits) • DHCP server enabled with 128 client IPv4 addresses starting from 192.168.123.33. These parameters should work for the majority of installations.
Page 118 Chapter 11 LAN Settings > LAN > LAN IP (Standard Mode) Fig ure 65 NBG7815 User’s Guide...
Page 119 Chapter 11 LAN Settings > LAN > LAN IP (Bridge Mode) Fig ure 66 The following table describes the labels in this screen. Table 38 Settings > LAN > LAN IP L ABEL DESC RIPT IO N LAN IP Rule IP Address Type the IP address of your NBG7815 in dotted decimal notation.
Page 120: Static Dhcp Table-Add/Edit Rule Screen
Chapter 11 LAN Table 38 Settings > LAN > LAN IP (continued) L ABEL DESC RIPT IO N DHCP Pool Size This field specifies the size, or count of the IP address pool for LAN. DNS Server DNS Servers Assigned by DHCP Server First DNS Server Select if your ISP dynamically assigns DNS server information (and the...
Page 121 Chapter 11 LAN Settings > LAN > LAN IP > Add Rule Fig ure 67 Settings > LAN > LAN IP > Edit Fig ure 68 The following table describes the labels in these screens. Table 39 Settings > LAN > LAN IP > Add Rule/Edit L ABEL DESC RIPT IO N Device LIst...
Page 122: Configure Lan Screen In Bridge Mode
Chapter 11 LAN 11.4.2 C o nfig ure L AN Sc re e n in Bridg e Mo de Use this section to configure your LAN settings while in Bridg e Mo de Click to show the following screen. Se tting s > L AN > L AN IP Note: If you change the IP address of the NBG7815 in the screen below, you will need to log into the NBG7815 again using the new IP address.
Page 123: Ipv6 Lan Screen
Chapter 11 LAN The table below describes the labels in the screen. Table 40 Settings > LAN > LAN IP L ABEL DESC RIPT IO N IP Address setting Obtain an IP Address When you enable this, the NBG7815 gets its IP address from the network’s DHCP server Automatically (DHCP) (for example, your ISP).
Page 124 Chapter 11 LAN Settings > LAN > IPv6 LAN Fig ure 70 The following table describes the labels in this screen. Table 41 Settings > Expert Mode > LAN > IPv6 LAN L ABEL DESC RIPT IO N LAN IPv6 Address Assignment Enable_DHCPv6-PD Select this option to use DHCPv6 prefix delegation.
Page 125 Chapter 11 LAN Table 41 Settings > Expert Mode > LAN > IPv6 LAN (continued) L ABEL DESC RIPT IO N IPv6 Address range Enter the end of the range of IP address that this address object represents. (End) IPv6 Lifetime Enter the IPv6 lifetime in the LAN.
Page 126: Security
HA PTER Se c urity 12.1 O ve rvie w Use these screens to enable and configure the firewall that protects your NBG7815 and your LAN from unwanted or malicious traffic. Enable the firewall to protect your LAN computers from attacks by hackers on the Internet and control access between the LAN and WAN.
Page 127: Ipv4 Firewall Screen
Chapter 12 Security Ab o ut the NBG 7815 Fire wa ll The NBG7815’s firewall feature physically separates the LAN and the WAN and acts as a secure gateway for all data passing between the networks. It is a stateful inspection firewall and is designed to protect against Denial of Service attacks when activated (click the tab under and then click the...
Page 128 Chapter 12 Security Settings > Firewall > IPv4 Firewall Fig ure 72 The following table describes the labels in this screen. Table 42 Settings > Firewall > IPv4 Firewall L ABEL DESC RIPT IO N ICMP Internet Control Message Protocol is a message control and error-reporting protocol between a host server and a gateway to the Internet.
Page 129: Ipv4 Firewall-Add Rule Screen
Chapter 12 Security Table 42 Settings > Firewall > IPv4 Firewall (continued) L ABEL DESC RIPT IO N Dest IP Address This is the IP address of the computer to which traffic for the application or service is entering. Source IP Address This is the IP address of the computer from which traffic for the application or service is initialized.
Page 130: Ipv6 Firewall Screen
Chapter 12 Security The following table describes the labels in this screen. Table 43 Settings > Firewall > IPv4 Firewall > Add Rule L ABEL DESC RIPT IO N Service Name Enter a name that identifies or describes the firewall rule. MAC Address Enter the MAC address of the computer for which the firewall rule applies.
Page 131: Ipv6 Firewall-Add Rule Screen
Chapter 12 Security The following table describes the labels in this screen. Table 44 Settings > Firewall > IPv6 Firewall L ABEL DESC RIPT IO N Configuration Simple Security Select to enabled simple security on your NBG7815. Ena b le Rule Status Select to enabled rule status on your NBG7815.
Page 132 Chapter 12 Security Settings > Firewall > IPv6 Firewall > Add Rule Fig ure 75 The following table describes the labels in this screen. Table 45 Settings > Firewall > IPv4 Firewall > Add Rule L ABEL DESC RIPT IO N Service Name Enter a name that identifies or describes the firewall rule.
Page 133: System
HA PTER Syste m 13.1 O ve rvie w This chapter provides information on checking the NBG7815's status and logs, configuring basic and remote management settings, using maintenance and firmware upgrade tools, and changing the operating mode. 13.2 Wha t Yo u C a n Do •...
Page 134 Chapter 13 System Settings > System > Status (Standard Mode) Fig ure 76 NBG7815 User’s Guide...
Page 135 Chapter 13 System Settings > System > Status (Bridge Mode) Fig ure 77 The following table describes the labels in this screen. Table 46 Settings > System > Status L ABEL DESC RIPT IO N System Model Name This is the model name of your device. Firmware Version This is the firmware version.
Page 136: General Setting Screen
Chapter 13 System Table 46 Settings > System > Status (continued) L ABEL DESC RIPT IO N DHCP Server This shows whether the NBG7815 acts as a DHCP Server and provides LAN IP addresses to its clients or not. IPv6 Address This shows the current LAN IPv6 address of the NBG7815.
Page 137 Chapter 13 System Settings > System > General Setting (Bridge Mode) Fig ure 79 The following table describes the labels in this screen. Table 47 Settings > System > General Setting L ABEL DESC RIPT IO N System Settings System Name System Name is a unique name to identify the NBG7815 in an Ethernet network.
Page 138: Remote Access Screen
Chapter 13 System 13.5 Re m o te Ac c e ss Sc re e n Use this screen to change your NBG7815’s remote management settings. You can use HTTPS or Wake on LAN to access and manage the NBG7815. Wake On LAN (WoL) allows you to remotely turn on a device on the network, such as a computer, storage device or media server.
Page 139: Maintenance Screen
Chapter 13 System Settings > System > Remote Access (Bridge Mode) Fig ure 81 The following table describes the labels in this screen. Table 48 Settings > System > Remote Access L ABEL DESC RIPT IO N HTTPS Server Port You may change the server port number for a service if needed, however you must use the same port number in order to use that service for remote management.
Page 140: Operating Mode Screen
Chapter 13 System O nline Firm wa re Find firmware at www.zyxel.com in a file that uses the version number and project code with a “*.bin” extension, e.g., “V1.00(ABCS.0)C0.bin”. The upload process uses HTTP (Hypertext Transfer Protocol) and may take up to two minutes. After a successful upload, the system will reboot. Syste m Re sta rt System restart allows you to reboot the NBG7815 without turning the power off.
Page 141 Chapter 13 System Sta nda rd (Ro ute r) A router connects your local network with another network, such as the Internet. The router has two IP addresses, the LAN IP address and the WAN IP address. LAN and WAN IP Addresses in Standard Mode Fig ure 83 Bridg e A bridge enabled all Ethernet ports to be bridged together and be in the same subnet.
Page 142: Logs Screen
Chapter 13 System Settings > System > Operating Mode Fig ure 85 The following table describes the labels in this screen. Table 49 Settings > System > Operation Mode L ABEL DESC RIPT IO N Standard Mode Select if your device routes traffic between a local network and Sta nda rd Mo de another network such as the Internet.
Page 143 Chapter 13 System Click to save your settings. Click to discard all changes. Apply C a nc e l Click > > to show the following screen. Se tting s Syste m L o g s Settings > System > Logs Fig ure 86 NBG7815 User’s Guide...
Page 144: Troubleshooting
HA PTER T ro ub le sho o ting 14.1 O ve rvie w This chapter offers some suggestions to solve problems you might encounter. The potential problems are divided into the following categories. • Power, Hardware Connections, and LEDs •...
Page 145: Nbg7815 Access And Login
Chapter 14 Troubleshooting 14.3 NBG 7815 Ac c e ss a nd L o g in I don’t know the IP address of my NBG7815. • The default IP address of the NBG7815 in . If the NBG7815 obtains a Sta nda rd Mo de 192.168.123.1 WAN IP address in the same subnet as the LAN IP address 192.168.123.1, the default LAN IP address will...
Page 146: Internet Access
Chapter 14 Troubleshooting Adva nc e d Sug g e stio ns • Try to access the NBG7815 using another service, such as Telnet. If you can access the NBG7815, check the remote management settings and firewall rules to find out why the NBG7815 does not respond to HTTP.
Page 147: Resetting The Nbg7815 To Its Factory Defaults
Chapter 14 Troubleshooting • If the problem continues, contact your ISP. The Internet connection is slow or intermittent. • There might be a lot of traffic on the network. Look at the LEDs, and check Section 1.7 on page 14. If the NBG7815 is sending or receiving a lot of information, try closing some programs that use the Internet, especially peer-to-peer applications.
Page 148 Chapter 14 Troubleshooting • Make sure the wireless LAN is enabled on the NBG7815. • Make sure the wireless adapter on your computer is working properly. • Make sure the wireless adapter installed on your computer is IEEE 802.11 compatible and supports the same wireless standard as the NBG7815.
Page 149: Usb Device Problems
Chapter 14 Troubleshooting 14.7 USB De vic e Pro b le m s I cannot access or see a USB device that is connected to the NBG7815. • Disconnect the problematic USB device, then reconnect it to the NBG7815. • Ensure that the USB device has power. •...
Page 150: Appendix A Customer Support
C o rpo ra te He a dq ua rte rs (Wo rldwide ) T a iwa n • Zyxel Communications Corporation • http://www.zyxel.com Asia C hina • Zyxel Communications (Shanghai) Corp. Zyxel Communications (Beijing) Corp. Zyxel Communications (Tianjin) Corp. • https://www.zyxel.com/cn/zh/ India • Zyxel Technology India Pvt Ltd •...
Page 151 • Zyxel Communications Corporation • https://www.zyxel.com/tw/zh/ T ha ila nd • Zyxel Thailand Co., Ltd. • https://www.zyxel.com/th/th/ Vie tna m • Zyxel Communications Corporation-Vietnam Office • https://www.zyxel.com/vn/vi Euro pe Be la rus • Zyxel BY • https://www.zyxel.by Be lg ium •...
Page 152 Appendix A Customer Support • https://www.zyxel.com/be/fr/ Bulg a ria • Zyxel България • https://www.zyxel.com/bg/bg/ C ze c h Re pub lic • Zyxel Communications Czech s.r.o • https://www.zyxel.com/cz/cs/ De nm a rk • Zyxel Communications A/S • https://www.zyxel.com/dk/da/ Esto nia •...
Page 153 Ro m a nia • Zyxel Romania • https://www.zyxel.com/ro/ro Russia • Zyxel Russia • https://www.zyxel.com/ru/ru/ Slo va kia • Zyxel Communications Czech s.r.o. organizacna zlozka • https://www.zyxel.com/sk/sk/ Spa in • Zyxel Communications ES Ltd. • https://www.zyxel.com/es/es/ Swe de n • Zyxel Communications •...
Page 154 Appendix A Customer Support T urke y • Zyxel Turkey A.S. • https://www.zyxel.com/tr/tr/ • Zyxel Communications UK Ltd. • https://www.zyxel.com/uk/en/ Ukra ine • Zyxel Ukraine • http://www.ua.zyxel.com So uth Am e ric a Arg e ntina • Zyxel Communications Corporation •...
Page 155 Appendix A Customer Support Middle Ea st • Zyxel Communications Corporation • https://www.zyxel.com/me/en/ No rth Am e ric a • Zyxel Communications, Inc. - North America Headquarters • https://www.zyxel.com/us/en/ O c e a nia Austra lia • Zyxel Communications Corporation •...
Page 156 PPEN DIX Se tting Up Yo ur C o m pute r’s IP Addre ss Note: Your specific NBG7815 may not support all of the operating systems described in this appendix. See the product specifications for more information about which operating systems are supported.
