dido.dmg.it
Home
Visual & Media Systems
2" RAFFAELLO Display
Contents
Safety and usage cautions
Mounting
POSITION & DIRECTION Input Wiring
Firmware
Updated to EN81-28:2018 regulation.
Safety and usage cautions
Before installing our products, we recommend you to consult the section about safety and usage cautions at the link below.
Mounting
Flush Mounting (back mounting)
2" RAFFAELLO Display
Advertisement
Table of Contents
Related Manuals for DMG RAFFAELLO
Summary of Contents for DMG RAFFAELLO
- Page 1 Home Visual & Media Systems 2″ RAFFAELLO Display 2″ RAFFAELLO Display Contents Safety and usage cautions Mounting Wiring Instructions POSITION & DIRECTION Input Wiring SERVICE MESSAGE Wiring Settings Datasheet Raffaello 2" Video Tutorial Firmware Updated to EN81-28:2018 regulation. Safety and usage cautions Before installing our products, we recommend you to consult the section about safety and usage cautions at the link below.
- Page 2 With welded pins on 1,5÷2 mm pushbutton panel With D13 Screen (frontal mounting) Frontal mounted on 0,7/3 mm pushbutton panel...
- Page 3 With DZ1 Screen (frontal mounting) Frontal mounted on 0,7/3 mm pushbutton panel...
- Page 4 Wiring Instructions POSITION & DIRECTION Input Wiring Pitagora 4.0 CAN serial protocol FLOOR...
- Page 5 3-wires serial Encoder DEUM For more details please refer to the Encoder DEUM support page. CAN serial protocol...
- Page 6 3-wires serial Other Controllers Proprietary CAN protocol...
- Page 7 1 Wire / Floor 10 floors max. 1 Wire / Segment...
- Page 8 29 floors max. (-9, 0, 19) Gray / Binary 72 floors max. (-9, 0, 62) TKE/MEA/Autinor...
- Page 9 SERVICE MESSAGE Wiring Parallel display CAN serial display (*)
- Page 10 INPUTS Parallel CANBUS Serial / 1 wire per floor / segment Input Gray / Binary / Pos.Sensor • • TKE / MEA / Autinor / CAN DMG Options Interface Arrow Configuration Direction / Next Dir. • Options Car at Floor No / Yes •...
- Page 11 MENU MENU ITEM AVAILABLE CHOICES INPUTS First Visualization Blank / Zero • Common Selection Negative / Positive • Arrow Type Fixed arrows / Scrolling arrows • Enable AUX Signals 10 + 0 / 6 + 4 • Input Filtering 0 ... 20 •...
- Page 12 1) – Direction arrows (default) 2) – Next direction arrows (instructions below) Next Direction Arrows enabled from input Arrows light up only on the position indicators with the “NEXT DIRECTION” input powered. If the DEUM Encoder is used, please refer to the relevant manual Next Direction Arrows locally programmed Through the addressing procedure one can permanently assign to each indicator the information of the floor on which it is mounted;...
- Page 13 If the DEUM Encoder is used, please refer to the relevant manual Set up CAN BUS protocol trasmission speed Intermediate floors visualization...
- Page 14 Set up floors OFFSET Set up first visualization 1) – It does not display any numbers 2) – Lowest floor Set up Parallel position common input Set up scrolling arrows...
- Page 15 1) – Fixed arrows 2) – Scrolling arrows Enable auxiliary signals a) – 10 Floor parallel inputs (X01÷X10) + 0 AUX Signals b) – 6 Floor parallel inputs (X01÷X06) + 4 AUX Signals (X07÷X10) Set up the display delay of floor change The display delay helps avoiding visualization errors during floor change.
- Page 16 “Energy saving” mode to reduce consumption when idle. Set up Font Set up flat Style Color...
- Page 17 Set up gradient Style Color Show/Hide position Show/Hide arrows Set up Symbols position Landscape orientation modes only.
- Page 18 If “Yes”, the symbols will stay in fixed positions independently of the arrow status. Signalizations (visualization) 1) – Fixed or blinking signalizations (input from controller). 2) – Fixed signalizations. Set up Viewing mode of signalization Set up display orientation...
- Page 19 Set up service message inputs Set up auxiliary signal Restore the factory settings The display original factory settings will be restored and configurations will be deleted. Floor customizations 1) Car at floor...
- Page 20 2) Set up Floor Numbers / Letters Datasheet Raffaello 2″ 62×68 mm (STD) Dimensions 62×76 mm (DZ1) 55×68 mm (D1) Screen 40,8×30,6 mm / 320×240 pixel Power supply (position input) 12÷24V DC ±10% Absorption 12V DC: Max 49mA • 24V DC: Max 36mA Indicators inputs 12÷24V DC ±10%...
