Round Ladder Handle
Installation Manual
Measurements
CODE
701DHH2R1001XXX
701DHH2R1002XXX
701DHH2R1003XXX
701DHH2R1004XXX
100
C-C
Components
2
Material
H
400
SUS 304
SUS 304
500
600
SUS 304
SUS 304
800
Ø12×2
3
4
5
6
6
8
7
10
9
1
C-C
300
350
400
600
#
Name
1
Exterior Handle
2
Interior Handle
3
Metal Washer dia32mm
4
Plastic Washer
5
Gasket
6
Collar
7
Set Screw M6×6mm
8
Screw M8×50mm
9
Screw M8×80mm
Allen Key 3mm
10
90
30
Qty
1
1
4
2
4
2
4
2
2
1
Advertisement
Related Manuals for Richelieu 701DHH2R1001 Series
Summary of Contents for Richelieu 701DHH2R1001 Series
- Page 1 Round Ladder Handle Installation Manual Measurements CODE Material 701DHH2R1001XXX SUS 304 701DHH2R1002XXX SUS 304 701DHH2R1003XXX SUS 304 701DHH2R1004XXX SUS 304 Ø12×2 Components Name Exterior Handle Interior Handle Metal Washer dia32mm Plastic Washer Gasket Collar Set Screw M6×6mm Screw M8×50mm Screw M8×80mm Allen Key 3mm...
- Page 2 Round Ladder Handle Installation Manual Install the exterior handle as shown with one gasket and metal washer on each side of the glass. * Philips screwdriver not included * Use the 45mm screw for glass doors 8-12mm thick * Use the 80mm screw for wood doors 35-50mm thick 8 or 9 Install the interior handle onto the collars.
