Superior Series
Assembly Instructions
IMPORTANT
Please read these instructions carefully before beginning to assemble this structure.
Save instructions for future reference.
9601 Newton Ave S- Suite A
Bloomington, MN 55431
800-852-3443
Page 2 - LIMITED WARRANTY
Page 2 - SAFETY GUIDELINES
Page 3 - BILL OF MATERIALS EZ5006
Page 4 - BILL OF MATERIALS EZ5012
Page 5 - BILL OF MATERIALS EZ5018
Page 6 - BILL OF MATERIALS EZ5024
Page 7 - ANCHORING LAYOUT
Page 8 - DOOR FRAME ASSEMBLY EZ2011
Page 9 - DOOR FRAME ASSEMBLY EZ2011
Page 10 - INTERIOR FRAME ASSEMBLY EZ2013
Page 11 - END FRAME ASSEMBLY EZ2012
Page 12 - END FRAME ASSEMBLY EZ2012
Page 13 - CONNECTING THE FRAMES
Page 14 - CONNECTING THE FRAMES
Page 15 - CONNECTING THE FRAMES
Page 16 - SLIDE SIDE INSTALLATION EZ2014
Page 17 - SLIDE SIDE INSTALLATION EZ2014
Page 18 - SLIDE SIDE INSTALLATION EZ2014
Page 19 - END FRAME POLY INSTALLATION EZ2015
Page 21 - ROOF POLY INSTALLATION EZ2015
Page 21 - LEVELING THE DOOR HEADER
Page 22 - OPTIONAL BENCHING PACKAGE INSTALLATION
Revision: AE-201007
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Poly-Tex Superior EZ5006
Summary of Contents for Poly-Tex Superior EZ5006
- Page 1 Superior Series Assembly Instructions Page 2 - LIMITED WARRANTY Page 2 - SAFETY GUIDELINES Page 3 - BILL OF MATERIALS EZ5006 Page 4 - BILL OF MATERIALS EZ5012 Page 5 - BILL OF MATERIALS EZ5018 Page 6 - BILL OF MATERIALS EZ5024 Page 7 - ANCHORING LAYOUT Page 8 - DOOR FRAME ASSEMBLY EZ2011 Page 9 - DOOR FRAME ASSEMBLY EZ2011...
-
Page 2: Limited Warranty
PLEASE READ THE INSTALLATION INSTRUCTIONS CAREFULLY BEFORE BEGINNING TO ASSEMBLE THE STRUCTURE. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a period of (1) year from date of invoice. This warranty is... - Page 3 BILL OF MATERIALS EZ5006 EZ5006 - SUPERIOR 10 x 6 w/ CLEAR ROOF, CLEAR ENDS, ONE DOOR BILL OF MATERIALS ITEM CODE DESCRIPTION EZ2011 END PKG, DOOR, EZ EZ2012 END PKG, NO DOOR, EZ EZ2014 FRAME CONNECTOR PKG, EZ EZ2015 COVER PKG, EZ REV: AE-201007...
- Page 4 BILL OF MATERIALS EZ5012 EZ5012 - SUPERIOR 10 x 12 w/ CLEAR ROOF, CLEAR ENDS, ONE DOOR BILL OF MATERIALS ITEM CODE DESCRIPTION EZ2011 END PKG, DOOR, EZ EZ2012 END PKG, NO DOOR, EZ EZ2013 INTERIOR FRAME PKG, EZ EZ2014 FRAME CONNECTOR PKG, EZ EZ2015 COVER PKG, EZ...
- Page 5 BILL OF MATERIALS EZ5018 EZ5018 - SUPERIOR 10 x 18 w/ CLEAR ROOF, CLEAR ENDS, ONE DOOR BILL OF MATERIALS ITEM CODE DESCRIPTION EZ2011 END PKG, DOOR, EZ EZ2012 END PKG, NO DOOR, EZ EZ2013 INTERIOR FRAME PKG, EZ EZ2014 FRAME CONNECTOR PKG, EZ EZ2015 COVER PKG, EZ...
- Page 6 BILL OF MATERIALS EZ5024 EZ5024 - SUPERIOR 10 x 24 w/ CLEAR ROOF, CLEAR ENDS, ONE DOOR BILL OF MATERIALS ITEM CODE DESCRIPTION EZ2011 END PKG, DOOR, EZ EZ2012 END PKG, NO DOOR, EZ EZ2013 INTERIOR FRAME PKG, EZ EZ2014 FRAME CONNECTOR PKG, EZ EZ2015 COVER PKG, EZ...
- Page 7 ANCHORING LAYOUT 1. Prepare a hard level foundation for your product. The product must be built on a solid level surface in order to perform properly. We recommend 12'-0" using concrete or wood deck as base. 2. Prepare for assembly of this product by gathering the following tools: step ladder, rubber mallet, wire cutters, safety glasses, and gloves.
- Page 8 DOOR FRAME ASSEMBLY EZ2011 BILL OF MATERIALS ITEM CODE DESCRIPTION PEAK EZ1003 BENCH FRAME, DOOR END, LH SUBASSEMBLY EZ1005 BENCH FRAME, DOOR END, RH EZ1107 THRESHOLD, DOOR EZ1110 HEADER, DOOR EZ1124 PEAK, END EZ1126 PEAK SUPPORT, END, LH EZ1128 PEAK SUPPORT, END, RH EZ1131 JAMB, DOOR, LATCH SIDE 1.
- Page 9 DOOR FRAME ASSEMBLY EZ2011 BILL OF MATERIALS ITEM CODE DESCRIPTION DOOR FRAME EZ1003 BENCH FRAME, DOOR END, LH PEAK / HEADER SUBASSEMBLY EZ1005 BENCH FRAME, DOOR END, RH EZ1107 THRESHOLD, DOOR SUBASSEMBLY EZ1110 HEADER, DOOR EZ1124 PEAK, END EZ1126 PEAK SUPPORT, END, LH EZ1128 PEAK SUPPORT, END, RH EZ1131...
- Page 10 INTERIOR FRAME ASSEMBLY EZ2013 (FOR ALL SIZES 10' X 12' AND GREATER) BILL OF MATERIALS ITEM CODE DESCRIPTION GMSA50 DIVIDER, GM2000 EZ1122 PEAK, INTERIOR INTERMEDIATE NB1901 WING NUT, 3/8" ZP FRAME NB1923 WASHER, FLAT, NYLON SUBASSEMBLY EZ1008 LOWER FRAME INTERMEDIATE EZ1103 TUBE, 1.250 SQ x 14GA, 79 IN EZ1119...
- Page 11 END FRAME ASSEMBLY EZ2012 BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1004 BENCH FRAME, REAR END, LH PEAK EZ1006 BENCH FRAME, REAR END, RH SUBASSEMBLY EZ1101 TUBE, 1.250 SQ x 14GA, 55.5 IN EZ1104 WLDMT, HEADER, 79 IN EZ1114 REAR BASE EZ1124 PEAK, END EZ1126...
- Page 12 END FRAME ASSEMBLY EZ2012 BILL OF MATERIALS ITEM CODE DESCRIPTION END FRAME EZ1004 BENCH FRAME, REAR END, LH SUBASSEMBLY PEAK / HEADER EZ1006 BENCH FRAME, REAR END, RH SUBASSEMBLY EZ1101 TUBE, 1.250 SQ x 14GA, 55.5 IN EZ1104 WLDMT, HEADER, 79 IN EZ1114 REAR BASE EZ1124...
- Page 13 CONNECTING THE FRAMES BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE INTERMEDIATE GM4000 PURLIN, BASKET, 73 1/2" FRAME GMSA52 SLIDE BAR, GM 2000 SUBASSEMBLY SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) SS1005 3'-0" x 55 1/4" 8MM CLR PCSS NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5 DOOR FRAME...
- Page 14 CONNECTING THE FRAMES BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE GM4000 PURLIN, BASKET, 73 1/2" GMSA52 SLIDE BAR, GM 2000 SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) DETAIL C SS1005 3'-0" x 55 1/4" 8MM CLR PCSS (2 PLACES) NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5...
- Page 15 CONNECTING THE FRAMES BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE GM4000 PURLIN, BASKET, 73 1/2" GMSA52 SLIDE BAR, GM 2000 SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) SS1005 3'-0" x 55 1/4" 8MM CLR PCSS NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5 NB1860...
- Page 16 SLIDE SIDE INSTALLATION BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE GM4000 PURLIN, BASKET, 73 1/2" GMSA52 SLIDE BAR, GM 2000 SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) SS1005 3'-0" x 55 1/4" 8MM CLR PCSS NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5 NB1860...
- Page 17 SLIDE SIDE INSTALLATION BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE GM4000 PURLIN, BASKET, 73 1/2" GMSA52 SLIDE BAR, GM 2000 SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) SS1005 3'-0" x 55 1/4" 8MM CLR PCSS NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5 NB1860...
- Page 18 SLIDE SIDE INSTALLATION BILL OF MATERIALS ITEM CODE DESCRIPTION EZ1100 X-BRACE GM4000 PURLIN, BASKET, 73 1/2" 1/4" Carriage Bolt GMSA52 SLIDE BAR, GM 2000 (NB1820) SA4013 ASSY, S.A. BOTTOM RAIL, 74" SA4018 ASSY, S.A. TOP RAIL, 74" (BROWN) SS1005 3'-0" x 55 1/4" 8MM CLR PCSS NB1820 CARRIAGE BOLT, 1/4"x 3/4", G5 NB1860...
- Page 19 END FRAME POLY INSTALLATION BILL OF MATERIALS ITEM CODE DESCRIPTION BM5052 10' x 14' CLEAR END POLY BM5068 16' x 26' CLEAR ROOF -24' BM Wiggle Wire EZ2015 - COVER PKG, EZ 1. Lay out Wiggle Wire pieces at the base of the end frames. Unroll End Poly Sheets (BM5052) near each end frame. Center the poly in front of the frame.
- Page 20 ROOF POLY INSTALLATION BILL OF MATERIALS ITEM CODE DESCRIPTION BM5052 10' x 14' CLEAR END POLY BM5068 16' x 26' CLEAR ROOF -24' BM Wiggle Wire HELPFUL HINT: If poly covering is installed on a cool day, the poly may expand as the temperature warms causing the film to loosen. It may be necessary to re-tension the poly again at a later date.
- Page 21 LEVELING THE DOOR HEADER Stake Pads - BMS1119 1. Use (2) Stake Pads (BMS1119) to shim under the door posts, as required, to level the door header. BMS1119 included in Door Frame Assembly (EZ2011) REV: AE-201007...
- Page 22 OPTIONAL BENCHING PACKAGE INSTALLATION (NOT INCLUDED, SOLD SEPARATELY) BILL OF MATERIALS ITEM CODE DESCRIPTION EZ2413 EZ MART REMOVABLE BENCH FRAME DETAIL AC EZ1144 - REMOVABLE BENCH SUPPORT PKG, EZ 1. At each intermediate frame, add the Removable Bench Frame (EZ2413) by inserting the top portion of the wire into the frame hole, then lowering the frame until the stabilization clip engages the frame.
