Poly-Tex FieldPro Gothic High Tunnel 20 Installation Instructions Manual

Advertisement

Quick Links

1
Installation Instructions
PO Box 458 • 27725 Danville Ave. • Castle Rock, MN 55010 • poly-tex.com
U.S. & Canada Toll Free 800-852-3443 • (651) 463-7009 • fax (651) 463-2479
Rev AK-210121

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FieldPro Gothic High Tunnel 20 and is the answer not in the manual?

Questions and answers

Summary of Contents for Poly-Tex FieldPro Gothic High Tunnel 20

  • Page 1 Installation Instructions PO Box 458 • 27725 Danville Ave. • Castle Rock, MN 55010 • poly-tex.com U.S. & Canada Toll Free 800-852-3443 • (651) 463-7009 • fax (651) 463-2479 Rev AK-210121...
  • Page 2: Table Of Contents

    Introduction Thank you for purchasing a FieldPro Gothic High Tunnel Greenhouse. Where this icon appears you will be alerted to The FieldPro has been carefully engineered to provide years of faithful a useful installation tip or an optional way of service.
  • Page 3: Safety Guidelines

    ASSEMBLE THE STRUCTURE. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Poly-Tex does not warrant that this structure or foundation will comply with local or state building codes. There is no guarantee of the load capacity of the structure for snow, wind,...
  • Page 4: Limited Warranty

    Poly-Tex, Inc. Limited Warranty Poly-Tex, Inc. warrants its products to be free from defects in material and workmanship for a period of (1) year from date of invoice. This warranty is provided to the original purchaser of the product and is not transferable.
  • Page 5: Overview Of Fieldpro

    Overview of FieldPro 20 and 24 Truss Purlin Peak Section Purlin Cross Connector Peak Purlin U-Channel Middle Section Wiggle Wire Channel Peak Brace Straight Side Peak Brace Steel Flat 1.66 U-Clamp “L” Bracket Bracket 2 U-Clamp Ground Stake/Stand Diagonal Brace All Lumber Corner (by others)
  • Page 6: Gothic 20 Main Components Identification

    Gothic 20 Main Components Identification HP3541 HP3542 HT Peak Section (Gothic 20') HT Middle Section (Gothic 20') RR2109 9'-8" R.F. U-Channel w/Swage HP3340 9'-8" Truss Purlin w/Swage-Red HP3503 HT Peak Brace 111" HP3506 Diagonal Brace 78" GS2404 GS2405 (6 ft. spacing) Ground Stake 36"...
  • Page 7: Gothic 24 Main Components Identification

    Gothic 24 Main Components Identification HP3544 HT Peak Section (Gothic 24') HP3545 HT Middle Section (Gothic 24') RR2109 9'-8" R.F. U-Channel w/Swage HP3340 9'-8" Truss Purlin w/Swage-Red HP3503 HT Peak Brace 111" HP3506 Diagonal Brace 78" GS2404 GS2405 (6 ft. spacing) Ground Stake 36"...
  • Page 8: Standard Fittings And Hardware

    Standard Fittings and Hardware FT4042 FT2079 FT2113 FT2057 FT2104 FT2117 KH1000 Cross Connector Long Speed 1-1/4 UNI-Clamp 2 U-Clamp 1.66 U-Clamp R.F. End Strap Purlin Hook (2 ) ( 1.66 ) Fastener DR7033 DR7032 FT1990 FT4053 Steel Flat Bracket Steel Corner Bracket R.F.
  • Page 9: Building Site Layout

    Building Site Layout Using the 3:4:5 Triangle Method to “Square Up” Your Building Site The “3:4:5 Triangle Method” of laying out a building site produces 90º corners as shown in the diagram. It forces your foundation layout to C = 5 ft. be a perfect rectangle instead of a parallelogram.
  • Page 10: Layout Of Ground Support Locations

    Layout of Ground Support Locations Instructions on pages 10–13 apply to 20 & 24 FieldPro Models Ground Stake/Stand Spacing 20'-0" or 24'-0"...
  • Page 11: Ground Stake Installation Options

    Ground Stake Installation Options Ground Stake Ground Stand Ground Stake GS2404 GS2405 GS2404 Driven Ground Stake Ground Stand in Compacted Soil Ground Stake in Concrete Pier Option #1 Option #2 Option #3 See page 12 for Ground Stake installation details. See page 12 for Ground Stand installation details.
  • Page 12: Ground Stake And Ground Stand Installation

    Ground Stake and Ground Stand Installation Driven Ground Stake Ground stakes are driven To save time, you can into the ground using the prep all the stakes Driving Tool Driving Tool (HT1000) ahead of time. HT1000 Note: until the top of the If the top of the stake ground stake is 12 above Ground Stake GS2404...
  • Page 13: Ground Stake Installation In Concrete Pier

    Ground Stake Installation in Concrete Pier Ground Stake in Concrete Pier To save time, you can prep all the stakes ahead of time. Ground Stake, Footing Centerline Ground Stake (GS2404) Place a mark 6 from top of stake. Masons Line Maximum Top of Install 1 self-drilling...
  • Page 14: Building Side Sub-Assembly

    Building Side Sub-Assembly Instructions on this page apply to 20 & 24 FieldPro Models Instructions on this page apply to 20 & 24 FieldPro Models Straight Side Mid-Section can be preassembled to save time. It is recommended that the side sub-assemblies be assembled on a flat surface so parts will be aligned properly.
  • Page 15: Building Main Frame Sections

    Building Main Frame Sections Instructions on this page apply to 20 & 24 FieldPro Models Insert each Side Assembly into Peak Section. Choose a flat surface when assembling these components, to ensure that all parts are properly aligned. See Detail A. Detail A Secure frame sections together using 1/4...
  • Page 16: Erecting Main Frame Sections

    Erecting Main Frame Sections Instructions on this page apply to 20 & 24 FieldPro Models Main Frame Install the first three assembled Frame Sections by inserting the Frame Sections into the ground stake/stand until they rest on the leveling screw(s) previously installed in each ground stake/stand.
  • Page 17: Adding Diagonal Braces

    Adding Diagonal Braces Instructions on this page apply to 20 & 24 FieldPro Models Important: Make sure screws and ends of carriage bolts do not face outwards to avoid damage to poly covering. All components attached to Long Speed Hooks must be mounted Note: The Main Frames can be installed on Attach HT Peak Brace (HP3503) between points on the outside of the tabs.
  • Page 18: Side Purlin Installation

    Side Purlin Installation Instructions on this page apply to 20 & 24 FieldPro Models Cross Connector FT4042 Truss Purlin (hardware included) HP3340 Round Black Plug RS5000 Detail A Center Cross Connectors View A at mark(s) previously placed Mark on the Frame sections. See page 14.
  • Page 19: Adding Main Frames And Side Purlins

    Adding Main Frames and Extending Side Purlins Instructions on this page apply to 20 & 24 FieldPro Models Cross Connector FT4042 (hardware included) Truss Purlin HP3340 Purlin Fastener KH1000 1/4 -14 x 1 Self-Drilling Screws (NB1809) 1/4 -14 x 1 Cut o Purlin Self-Drilling Screws end flush and...
  • Page 20: Peak Purlin Installation

    Peak Purlin Installation – Part 1 Instructions on this page apply to 20 & 24 FieldPro Models Peak Purlin Detail B RR2109 1 x 1- 1/2 Rectangular Black Plug FB2527 1-1/4 Uni Pipe Clamp FT2113 (hardware included) R.F. End Strap FT2117 (1.66 ) Stop Tab FT2570 Peak Purlin End...
  • Page 21 Peak Purlin Installation – Part 2 Instructions on this page apply to 20 & 24 FieldPro Models Insert additional Peak Purlin (RR2109) sections onto the After the last Peak Purlin section has been installed, trim the swaged end of the previous Peak Purlin until you reach the Purlin end flush with the End Frame.
  • Page 22: Truss Frame Assembly

    Truss Frame Assembly – Locating Band Braces Instructions on this page apply to 20 & 24 FieldPro Models Note: The lower Band Braces FT4054 can be held in place The FieldPro 20 and 24 optional Truss Frame Assem- temporarily with a self-drilling screw, See Detail A. blies share several main components.
  • Page 23 Truss Frame Assembly – Attaching Truss Chords & Struts Instructions on this page apply to 20 & 24 FieldPro Models Assemble the Chord Sections on a flat surface. Make Important: sure that the tabs on each end are facing the same HT1028 Strut (23-5/8 ) Components attached to direction.
  • Page 24: Installing Wood Side Rails

    Detail 6 Shown from inside of structure POLY-TEX recommends the following lumber* • Treated 2 x 6 material for the lower rails Perimeter distance plus 10% – 12n lengths minimum • Owners choice of 2 x 4 or 2 x 6 material for other rail locations Perimeter distance plus 10% –...
  • Page 25 Wood Side Rail Fastening Details Instructions on this page apply to 20 & 24 FieldPro Models 1/4 - 14 x 1 1/4 - 14 x1 Self-Drilling Screws 1/4 -14 x1 1.66 U-Clamp Self-Drilling Screw NB1809 Self-Drilling Screw FT2104 NB1809 NB1809 2 U-Clamp FT2057 1-1/2 Woodtite...
  • Page 26: Plain End Wall Wiggle Wire Base Material Installation

    Plain End Wall Wiggle Wire Base Installation Instructions on this page apply to 20 & 24 FieldPro Models Attach Wiggle Wire Base to the outside of the bottom Wood Base Rail flush with the top. Section B-B shows proper screw usage. Install Wiggle Wire Base to End Frame starting at the bottom of the Wood Rail on each side.
  • Page 27: Plain End Wall Poly Installation

    Plain End Wall Poly Installation Instructions on this page apply to 20 & 24 FieldPro Models Positioning the Poly Begin to install the Wiggle Wire all around the End Frame and across the You will need some help with this step. After all the Wiggle Wire Lower Wood Rail.
  • Page 28: Open Doorway - Part 1 And Part 2

    Open Doorway – Part 1 – Adding Wood Instructions on this page apply to 20 & 24 FieldPro Models Wiggle Wire Base attached to frame. Notes: See pages 24 and 25 for details about adding wood components and hardware details. Attach Wiggle Wire Base to the outside of the bottom Wood Base Rail flush with the top.
  • Page 29 Open Doorway – Part 2 – Installing Poly Instructions on this page apply to 20 & 24 FieldPro Models Positioning the Poly Install Wiggle Wire all around the End Frame, across the Lower Wood Rail You will need some help with this step. After all the Wiggle Wire and around door opening.
  • Page 30: Wiggle Wire Installation

    Wiggle Wire Installation Consider having one person tension the Poly Film while a second person inserts the Wiggle Wire. See Detail 1 on pages 32 and 33. Wiggle Wire Poly Film Wiggle Wire Base Carefully begin to fold the Poly Film into the Insert one end of the Wiggle Wire as shown Bend the Wiggle Wire up just enough to Wiggle Wire base while keeping a constant...
  • Page 31: Installation Of Roof Poly - General Instructions

    Installation of Roof Poly – General Instructions Instructions on this page apply to 20 & 24 FieldPro Models General Notes: • These instructions pertain to both Roof Poly installations and explain the best method for initial placement of the Poly. •...
  • Page 32: Installing Roof Poly On Fieldpro With Roll-Up Side Curtain

    Installing Roof Poly on FieldPro with Roll-Up Side Curtain Note: These instructions are for a FieldPro that will Instructions on this page apply to 20 & 24 FieldPro Models feature the Roll-Up Poly Curtain. See page 33 for the Ground-to-Ground Roof Poly Installation. Once the Poly is in position, place a couple of temporary sections of Wiggle Wire between Point and Point...
  • Page 33: Installing Ground-To-Ground Roof Poly

    Installing Ground-to-Ground Roof Poly Instructions on this page apply to 20 & 24 FieldPro Models Temporary Wiggle Wire Pieces Once the Poly is in position, place a couple of temporary sections of Wiggle Wire between Point and Point to help prevent the Poly from shifting while the Wiggle Wire is installed on the first side.
  • Page 34: Optional Door Kit W/ Metal Frame Installation

    Optional Door Kit Components and Hardware Items shown on this page apply to 20 & 24 FieldPro Models PT2521 RC1316 FT2071 RC1303 FT4053 FT1990 U-Bracket (1.66 ) 10 Bungee Ball Roll-Up Door Cradle Roll-Up Door 'J ' Hook U-Joint w/Bolts R.F.
  • Page 35 Door Kit Installation – Part 1 L-Bracket 3/8 x 3 Grade 5 Carriage Bolt NB1841 U-Bracket FT1990 3/8 Lock Washer NB1864 FT4053 3/8 Hex Nut NB1874 1/4 -14 x 1 Self-Drilling Screws Detail C NB1809 Detail B Door Jamb Extension HT1080 Detail A Note:...
  • Page 36 Door Kit Installation – Part 2 Instructions on this page apply to 20 & 24 FieldPro Models Metal Frame/Header Measure the distance from the Metal Door Jamb to the End Frame for upper Wiggle Wire and lower wood* side rails. Attach Base the wood rails using the “L”...
  • Page 37 Door Kit Installation – Part 3 Instructions on this page apply to 20 & 24 FieldPro Models 20 & 24 models both use Door Kit (HT1013) Bungee Cord wraps around Refer to the door kit for contents. threaded carriage bolt Reinforced Poly Door (8n x 8n) Lay out the Reinforced Poly Door on a flat surface.
  • Page 38: Optional Roll-Up Curtain Installation

    Optional Roll-Up Side Curtain Components and Hardware Roll-Up Unit Bracket RC1330 Tube Clip RS5049 NS104 with S Hook Cradle, Short, Roll-Up 1.315 1/4" Nylon Rope 18600 MV1000 RC1311 w/S-Hook RC1010 WIGGLWIRE - 43.000 HT Gearbox Vertical (70") Wiggle Wire HT1002 WWBASE9 8' - 11"...
  • Page 39 Roll-Up Curtain Installation – Part 1 Instructions on this page apply to 20 & 24 FieldPro Models Important Note: The Roof Poly and End Frame Poly (not shown) are installed before installing the Roll-Up Side Curtain. See page 32 for how to install the Roof Poly with the Roll-Up Side Curtain option.
  • Page 40 Roll-Up Curtain Installation – Part 2 Instructions on this page apply to 20 & 24 FieldPro Models Top edge of Poly Curtain To install the Vertical Tube (HT10020) that Top of Wood Rail supports the Roll-Up Unit (MV1000), drill a 5 diameter hole that is 8...
  • Page 41 Roll-Up Curtain Retainer Installation Instructions on this page apply to 20 & 24 FieldPro Models Raise the Poly Curtain by turning the crank handle on the Roll-Up Unit counterclock- wise until the curtain is about halfway up. Measure over 24 from the end of the lower side rail.
