WLS-T02
Congratulations! ··············································
Thanks for purchasing the WLS-T02 module – Wireless Location System
Transmitter. This Quick Start will provide related information which needed to
get start with the WLS-T02 module.
What's In the Box! ············································
In addition to this guide, the package includes the following items:
WLS-T02
Technical Support ············································
WLS-T02 Website
http://m2m.icpdas.com/WLS-T02.html
ICP DAS Website
http://www.icpdas.com/
Copyright © 2017 ICP DAS Co., Ltd. All Rights Reserved.
CR-123A 3.0v
Lithium battery
(4SI11G0000009)
E-mail:
Quick Start
Apr 2017, Version 1.0.0
Quick Start
service@icpdas.com
1
Advertisement
Related Manuals for ICP DAS USA WLS-T02
Summary of Contents for ICP DAS USA WLS-T02
- Page 1 Quick Start WLS-T02 Apr 2017, Version 1.0.0 Congratulations! ·············································· Thanks for purchasing the WLS-T02 module – Wireless Location System Transmitter. This Quick Start will provide related information which needed to get start with the WLS-T02 module. What’s In the Box! ············································...
-
Page 2: Preparing The Device
Appearance Description LED Indicator Buzzer Down CR-123A 3.0v battery Preparing the Device Use the Phillips screwdriver to loosen the back cover screws, open the case and place the CR123A 3.0v battery as shown in Figure 1 。 (CAUTION: Do not reverse the installation of the battery, and the battery is a disposable non-rechargeable lithium battery, do not use the charger to charge) Loosen the back cover screws... - Page 3 8 seconds, the module will automatically save and directly enable the setting value, and then leave the "Setting Mode". Then, if WLS-T02 doesn’t enter “long time sleep status”, it will return to the "Running Mode". In the above two modes, pressing different buttons will correspond to different functions, and various functions will be indicated by the different blinking frequency of LED.
- Page 4 LED Pressing the two buttons ▲+▼ blink after 3 second. At this time, together for 3 second will WLS-T02 has entered setting enter setting mode. mode. No pressing Red LED blinks every 3 second. Battery is low power.
- Page 5 ▲: None time sleeping status. If LED and red LED will WLS-T02 doesn’t enter long ▼: Long time blink together for 1 time sleeping status, it will sleeping second. At this time,...
-
Page 6: Start To Use
Start to use Wireless Location System (WLS) includes the modules that RFU-400, WLS-T02, WLS-R01 and WLS software (WLS-analyzer), as show in figure 4. The user needs to check the wireless setting of each module as below. If the user need more detail about parameters of wireless setting, please refer to the user manual of each module. - Page 7 2. WLS-T02： It is not required to adjust the wireless setting of WLS-T02. The default value about RF channel is 4, RF power is F, Node ID is the last two bytes of build-in IEEE address. If the user adjust WLS-R01 2.4GHz RF channel to 4, the WLS-R01 will can receive the wireless package.
