3.0 mm
11 mm
< 7.5 mm
Figure 7: Vocoder Physical Dimensions
VC-20 AMBE™ Vocoder Board User's Manual
I
NC.
5.5 mm
41612 Connector
100 mm
(bottom view)
(components < 12.5 mm)
(connections < 2 mm)
(side view)
