Audio Pre-amp/AV IN/ Radio

Note
Subwoofer Pre-amp is a non-fading mono
output.
Note
Always run signal wires away from power
cables to reduce the possibility of noise.
FL FR L-IN
RL RR R-IN
V-IN
SUB1 SUB2
RADIO
Audio/vidio Inputs
FM/AM Antenna Jack
Pre-Amp Audio Outputs
(Front/rear speaker outputs
and two subwoofer outputs)
32
Note
If pre-amp outputs are being used exclusively,
turn O the internal amp of the product, to
reduce the possibility of noise entering the
signal chain.
FL FR L-IN
RL RR R-IN
V-IN
SUB1 SUB2
RADIO
