MEASURING AND SWITCHING DEVICE
ROSSMA IIOT-AMS ANALOG
OPERATION MANUAL
ROSSMA IIOT-AMS Analog is used for autonomous data measurement from control and
measuring devices with current interface 4-20mA and/or with resistive interfaces of pt1000,
Ni1000, TK5000 type with subsequent transmission of received data in LoRaWAN and/or NBiOT
network.
The ROSSMA IIOT-AMS Analog switching device provides non-volatile operation of control and
measuring devices.
www.rossma.ru
Advertisement
Table of Contents
Related Manuals for ROSSMA IIOT-AMS
Summary of Contents for ROSSMA IIOT-AMS
- Page 1 ROSSMA IIOT-AMS ANALOG OPERATION MANUAL ROSSMA IIOT-AMS Analog is used for autonomous data measurement from control and measuring devices with current interface 4-20mA and/or with resistive interfaces of pt1000, Ni1000, TK5000 type with subsequent transmission of received data in LoRaWAN and/or NBiOT network.
- Page 2 ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL DATA ON THE DOCUMENT Title Measuring and switching device ROSSMA IIOT-AMS Analog Document type Operation manual Document code MAN-RIAA-01 Last revision number and date 08.08.2019 THIS DOCUMENT IS VALID FOR THE FOLLOWING DEVICES LINE NAME...
-
Page 3: Table Of Contents
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL CONTENTS INTRODUCTION ..............................3 DESCRIPTION AND OPERATION PRINCIPLE ....................4 SWITCHING DEVICE DESCRIPTION ..........................4 DATA COLLECTION AND TRANSMISSION ALGORITHM ..................... 5 FUNCTIONALITY ................................ 5 MARKING .................................. 6 DATA ON CERTIFICATION ............................7 TECHNICAL CHARACTERISTICS ........................8 WORKING WITH THE SWITCHING DEVICE .................... -
Page 4: Introduction
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL INTRODUCTION This manual applies to ROSSMA IIOT-AMS ANALOG measuring and switching device (hereinafter switching device) and defines installation and connection procedure, as well as control commands and functional description. The manual is intended for specialists familiar with the installation rules in the field of various electronic and electrical equipment. -
Page 5: Description And Operation Principle
DC source with a voltage of 3 to 5 The power cell of the ROSSMA IIOT-AMS ANALOG switching device is a 14000 mAh battery designed for up to 10 years of service life when measuring instrument readings and transmitting data once a day. -
Page 6: Data Collection And Transmission Algorithm
Data read frequency 1 time/min. 1 time/2min. 1 time/10min. 1 time/hour When connecting passive CMD Autonomous operation time of ROSSMA IIOT-AMS Analog 90 days 180 days 300 days 3 years When connecting active CMD Autonomous operation time of ROSSMA IIOT-AMS Analog... -
Page 7: Marking
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL • Luminance sensors; • Humidity sensors; • Current and voltage/battery sensors. The switching device is class A device (LoRaWAN classification) and provides the following ̆ functionality: • Support of both active and passive control and measuring devices;... -
Page 8: Data On Certification
OPERATION MANUAL LWANEX66X1420V30A83CCBRU LPWAN standard: LW – LoRaWAN, NB – NbiOT, 6LP-6LoWPAN, LWNB - both standards. Switching device model ROSSMA IIOT-AMS: AN-Analog, MB-Modbus, MU-Modbus Utility, Pulse-P0, DC-Dry Contact, LD-Leak Detector, SD-Smoke Detector, AB-Alarm Button, CN-Can, UC-Universal Controller. Degree of enclosure protection: IP56-0056, EX IP66-EX66, EX IP68- EX68,etc. -
Page 9: Technical Characteristics
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL 2. TECHNICAL CHARACTERISTICS THE MAIN Analog inputs (current, resistive): Single-channel 1 Multichannel Up to 8 - on-request (default 3) Current loop 4-20 mA or resistance pt1000, connection interface Ni1000, TK5000 Operation temperature range -55…+85°С Built-in temperature sensor... - Page 10 The housing can be completed with a plate with for DIN rail adapter(it is specified when ordering). The ROSSMA IIOT-AMS ANALOG (single channel) housing provides attachment directly to the instrument using a coupling with НЭВ 20х1,5 fitting.
-
Page 11: Working With The Switching Device
The maximum connected quantity of devices with output interfacw current loop 4- 20mA or resistive pt1000, Ni1000, TK5000 on ROSSMA IIOT-AMS ANALOG (multichannel) is no more than 3 (three). On request, the switching device can be equipped with a number of terminals for connection and simultaneous operation of up to 8 CMD. -
Page 12: Initial Start-Up
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL INITIAL START-UP The switching device has a special "Warehouse" mode designed for storage and transportation. In this mode, the switching device does not regularly transfer data to the network. The switching device must be taken out of Warehouse mode before it can be used. To switch from Warehouse mode to Active mode, install the jumper on both terminals On. -
Page 13: Communications Protocol
Bytes 7-8: 0x0E01 - Supply voltage in mV (0xE01 = 3585 = 3.585V) Byte 9: 0x14 - Temperature in degrees (0x14 = 20 = 20 degrees C) Data package format for ROSSMA IIOT-AMS ANALOG switching device (single channel): The total amount of the transferred package = 6 10 byte (Example DD02EE0EA608CA0E0114): Byte 0: 0xDD - package type. -
Page 14: Switching Device Configuration And Programming
ROSSMA IIOT-AMS ANALOG/ OPERATION MANUAL 0x0104 - Switching device type 0x0200 - Software version 0x0301 - Device version SWITCHING DEVICE CONFIGURATION AND PROGRAMMING The switching device is supplied with built-in firmware that enables the switching device to operate with the characteristics specified in this document. The switching device is programmed using a special input for the programmer. -
Page 15: Storage And Transportation Rules
OPERATION MANUAL 5. STORAGE AND TRANSPORTATION RULES ROSSMA IIOT-AMS switching devices shall be stored in the factory package in heated rooms at temperature from 5 ° С to 40 ° С and with relative humidity not more than 85%. The switching devices can be transported in covered cargo compartments of all types for any distances at temperature from -40 °... -
Page 16: Delivery Set
6. DELIVERY SET The standard delivery set of ROSSMA IIOT-AMS Analog switching device includes: • ROSSMA IIOT-AMS Analog switching device in factory packaging - 1 pc. • Sealed outlet installed in the switching device housing - 1 pc. • Certificate - 1 pc. -
Page 17: Warranty
- Switching devices with traces of oxidation or other signs of liquids ingress into the device housing. If a warranty case occurs, contact the service center of the ROSSMA manufacturer at: 614064, Perm, Chkalova Str., 9 Lit. "И". Phone: 7 (342) 233-93-99. - Page 18 Operation manual LLC ROSSMA 2019. www.rossma.ru...
