Dialogue Flybook V5 Quick Start Manual

Unpacking Your V5
Unpack the V5 and check for the following items:
V5 Computer
If any item is missing or damaged, repack the V5 and return it to your reseller.
.
Installing the Battery and Connecting the AC Adapter
Using the Battery Lock
There are two
latches for secur-
ing the battery in
place: the bat-
tery lock (B) and
the battery
release (A).
Always close the battery lock after
C :
AUTION
inserting the battery. If the battery lock is not
closed, the battery could fall out when carrying
the computer and cause injury or damage the
battery.
The battery lock must be manually
closed. The battery release is spring
loaded and closes automatically when
you insert the battery.
Flybook V5

Quick Start Guide

Standard battery
Recovery DVDs
and Driver CD
Windows®
Start Here

Installing the Battery

1. Slide the battery lock to the
unlocked position .
2. Align the guides on the sides of the
battery with the guides in the bay
and then install the battery.
3. Slide the battery lock to the locked
position .
AC adapter and power cord
Safety strap TV cable
adapter
User's Manual Guide Guide
User's Manual and
bundled booklets
Connecting the AC Adapter
1. Connect the AC cable (A) to the AC
adapter.
(B)
(A)
2. Connect the other end of the AC
cable (B) to an electrical outlet.
3. Connect the AC adapter (C) to the
AC jack on the computer.
The battery LED lights.
Stylus
Warranty card
(C)
