INTRODUCTION Thank you for purchasing VKAR product.This manual contains instructions on operating and maintaining the Bison .Please take a monent to read through this manual to familiarze yourself with this model. FEATURES Bright LED light. Secure wheelie bar set. All rubber covered bearing throughout.
Page 3
IMPORTANT INFORMATION The Bison is a powerful RC car that will bring much enjoyment.Howewever,improper use can cause damage and bodily injuries.Please read the following information carefully to avoid casualties. WARNING: This model can be operated with Ni-MH or Lithium Polymer batteries.
PARTS NAME LED Light Front Bumper Shock Hub Carrier Steer Block Front Shock Stay Wheel Hex Hub Turnbuckle (Camber Link) Suspension Arm Turnbuckle (toe Link) Steering Servo Body Mount Bracket Receiver Support Bracket Power Switch Battery Electronic Speed Control Center Shaft Motor Chassis Motor Mount...
Page 7
SETUP 【BEGIN TO USE THE NEW ESC】 1. Connect the ESC, motor, receiver, battery and servo according to the following diagram “ +” and “ -” wires of the ESC are connected with the battery pack, and #A, #B and #C are connected with the motor wires.
SETUP 3. The LED Status in Normal Running a) When the throttle stick is in the neutral range, neither the Red LED nor the Green LED lights up. b) When the car moves forward, the Red LED solidly lights; the Green LED also lights up when the throttle stick is at the top position (100% throttle).
Page 11
Rear Driver Shaft Assembly M2.5x8 5x10x4mm M3x3mm 5x10x4mm 3.5mm Adjusting the Slipper clutch NOTE: the slipper clutch adjustment too loose or tight may result in damsge the gear during racing. TIPS: The slipper clutch adjstment short cut Use 1.5mm hex key,Insert the hold as the picture below. Grasp the both sides of rear wheels,rotate in the same direction.
Steering Assembly 4.0mm 5x8x2.5mm 5x8x2.5mm M3x20mm M3x20mm 5x8x2.5mm 5x8x2.5mm M3.0mm M3x8mm M3.0mm M3x10mm M3.0mm M3x10mm NOTE: M3.0mm Rotating the nut to seek suitable degree of tightness. Motor Mount Assembly NOTE: Rotating the nut to seek suitable degree of tightness. M3x15 NOTE: Look out the interval between motor gear and spur gear...
Shock Assembly Shock Aaaembling Steps: 1.Fill shock body with 4/5 silicone fluid(purchase seperately),pump the shock shaft up and down to remove any air bubbles. 2.Wait the air bubbles pumped out,then pull down the shock shaft to the bottom,fill the silicone fluid up to 2 mm,after that ,tighten the shock head 1. 3.Install the spring,shock assembling finished.
SPARE PARTS ET1001 ET1002 ET1003 ET1004 ET1005 ET1006 Left Right Left Right Front Front Rear ET1007 ET1008 ES1022 ET1010 ET1011 ET1012 Rear Front Rear ET1014 ET1015 ET1016 ET1017 ET1018 ET1013 Left M3x15 Right M3x8 M3x8 2X16.8 ET1020 ET1021 ET1022 ET1023 ET1024 ET1019 M3x8...
Bill Of Material Number Name Dosage Number Name Specification Dosage Number Name Specification Dosage Specification Hydraulic top button Lower Deck-F Saver Spring Hydraulic ball head covered Box Post Saver Spring Universal _Ball Screw M3x1 Servo Saver-B Nylon Nut Front Suspension Arm Servo Saver-A Shock_picston Rear Suspension Arm...
